Case 610 Agricultural Crawler Tractor Parts Catalog

$ 55

Case 610 Agricultural Crawler Tractor Parts Catalog

Format: PDF (Printable Document)

File Language: English

File Pages: 42

File Size: 294.94 MB (Speed Download Link)

Brand: Case

Model: 610 Agricultural Crawler Tractor

Part No: 1028

Type of Document: Parts Catalog

Categories: ,

Description

Case 610 Agricultural Crawler Tractor Parts Catalog

Case 610 Agricultural Crawler Tractor Index:

TUBE ASS’Y, pump to tank
CONNECTOR, male, 3/4 MP to 1″ JIC
CLAMP, tube
HHCS 5/16-24 NF x 3/4
WASHER, med. sec. lock
NUT, reg. SF hex (5/16-24 NF)
BRACKET, tube support
CLAMP, tube
HHCS 5/16-24 NF x 1 1/2
WASHER, med. sec. lock
NUT, reg. hex (5/16-24 NF)

Pull-Behind Hydraulic System
ELBOW, 90°, male, 3/4 JIC to 1/2 NP
ELBOW, 90°, male, 5/8 JIC to 1/2 NP
TUBE ASS’Y, valve to quick disconnect
HOSE ASS’Y, to quick disconnect
CONNECTOR, socket
SOCKET, break-away
SPRING, coupling piston
RETAINER, seal
BODY, female break-away coupling socket
SEAL, break-away coupling piston
SEAL, “O”-ring
SLEEVE, break-away coupling socket body retainer
SPRING, coupling socket body retaining sleeve
RING, snap, coupling socket rubber retainer
BALL, break-away coupling socket locking
SPACER, control

Hydraulic System
ELBOW, extra long 5/8 JIC
ELBOW, male 5/8 JIC
TUBE ASS’Y, from hydraulic valve
TUBE ASS’Y, to breakaway couplings
COUPLING, pipe well drillers
CLAMP, tube
HHCS 3/8-16 UNC x 1
WASHER, med. sec. lock
NUT, reg. SF hex
BRACKET, L.H.
BRACKET, R.H.
HHCS 3/8-16 NC x 1
WASHER, med. sec. lock
NUT, reg. hex
ADAPTER, 1/2 JIC to 3/8-16 NC
SOCKET, break-away
SPRING, coupling piston
RETAINER, seal
PISTON, break-away coupling socket
BODY, female break-away coupling socket
SEAL, break-away coupling piston
SEAL, “O”-ring
SLEEVE, break-away coupling socket body ball
SPRING, socket body retaining sleeve
RING, snap
BALL, socket locking
SPACER, control
PLUG, break-away dust and more
