Description
Case 810 Agricultural Crawler Tractor Parts Catalog
Case 810 Agricultural Crawler Tractor Index:
R15926 RADIATOR ASS’Y
R12542 TANK & CORE ASS’Y, top
A10259 CAP – radiator
RESERVED
R14419 TANK & COOLER ASS’Y, bottom
R12743 SHROUD – fan
73604 CLIP – shroud bottom
73605 SCREW – shroud
9–4 LOCKWASHER
73597 WASHER – core
73598 GASKET – core
13–514 BOLT – hex, 5/16–18 NC x 7/8
13–512 BOLT – hex, 5/16–18 NC x 3/4
13–504 NUT – hex (5/16–18 NC)
12–109 WASHER – lock
R15972 PLUG – pipe, 1/4 NP
80780 WASHER – vibration
WASHER – special
14–836 HHCS 1/2–20 NF x 2–1/4 (R14356 mtg.)
13–950 NUT – lock (1/2–20 NF)
R13380 BRACKET – radiator support R.H.
R13381 BRACKET – radiator support L.H.
13–311 HHCS 3/8–16 NC x 3/4 (R13380 & R13381 mtg.)
14–836 HHCS 5/16–24 NF x 3/4 (71204 mtg.)
12–134 WASHER – med. sec. lock
13–504 NUT – reg. SF hex (5/16–24 NF)
R12538 BAFFLE ASS’Y – radiator bottom
R12539 BAFFLE ASS’Y – radiator bottom
R19024 HOSE – outlet
R19023 HOSE – radiator inlet
A10200 CLAMP – hose
A19762 CLOCK – radiator drain
R14780 GROMMET – radiator filler neck
