Flexicoil 50 Series Air Cart Assembly Instructions
Flexicoil 50 Series Air Cart Index:
Section – Title . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page
1 – SAFETY AND GENERAL ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Assembly Safety Practices
General Assembly Information
Bolt Torque Information
2 – AIR CART ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Getting Started
Remove the Auger Components (Optional)
Remove the Tow Between Front Hitch from Its Shipping Location (Shipping Frames
Configured for International Shipping Only)
Remove the Tow Between Rear Hitch from Its Shipping Location (Shipping Frames
Configured for International Shipping Only)
Install the Rear Axle Housings (Single Wheels Only)
Install the Rear Axle Housings (Dual Wheels Only)
Install the Drive Sprockets (Mechanical Drive Carts Only)
Install the Wheel and Hub on the Front Dual Caster (Tow Behind Only)
Install the Front Hitch (Tow Between Only) (Shipping Frames Configured for
International Shipping Only)
Install the Single Rear Wheels
Install the Dual Rear Wheels
Move the Air Cart off the Shipping Frame
Route the Clutch and Shaft Sensor Wires
Install the Rear Hitch (Tow Between Only) (Shipping Frames Configured for International
Shipping Only)
Install the Tank Ladder and Upper Handrail
Mechanical Drive Assembly (Mechanical Carts Only)
Install the Meter Rollers
Double Shoot Option
Transition Plugs, Transition Seals and Run Caps
Install the Auger and Auger Hydraulics (Optional)
Battery Installation (Variable Drive Carts Only)
Transport Lighting
Package the Shipping Frame for Return Credit
Field Tow Hitch Assembly (Tow Behind Only)
3 – POST-ASSEMBLY CHECKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
