Kongskilde Vibro-Till 2800 Field Cultivator Index:

1 601140769 Hitch – Cat 2/3 Combination Double Clevis
2 601232080 2800 Series Hitch Weldment
3 601232028 2800 Series Top Link Assembly (Items 4 to 9)
4 601232027 2800 Series Top Link Weldment
5 601242378 Adjustment Casting – 1″ ACME
6 601242342 Adjustment Slider – 1″ ACME
7 601242356 Wheel Adjustment – Threaded Weldment – 1″ ACME
8 600383051 Roll Pin 10mm x 40mm
9 600383050 Pin 3/8″ Tab Lock
10 Bolt 3/4″ x 6-1/2 Gr. 8 Plated
11 Locknut 3/4″ Stover
12 600383111 Pin 1″ x 5-3/4″ – 145mm
13 600383117 Ring Cotter Pin 1″
14 600383121 Pin 1-1/4″ x 3-3/4″ – 95mm
15 600383013 Roll Pin 3/8″ x 2-1/2″
16 605030046 Jack 2TM-15-0
17 600461011 A.S.A.E. 20,000# Safety Chain Assembly
18 Carriage Bolt 1/4″ x 1″
19 Locknut 1/4″
20 600470047 Hose Clamp 1/2″
21 600470007 Hose Clamp 3/8″
22 601242323 Hose Holder Tower
23 Bolt 1/2″ x 1-1/2″ Gr. 8 Plated
24 Locknut 1/2″ Stover
25 Washer 1-1/4″
26 Washer 1

1 601232150 2800 Centre Frame Weldment – 3M
2 601232087 2800 Centre Front Frame Weldment
3 601232115 2800 Top Frame Weldment – 2 pcs.
4 601232139 2800 Fold Plate Weldment – 3M
5 601232102 Hinge Pin Weldment
6 600383013 Roll Pin 3/8″ x 2-1/2″
7 600383118 Cylinder Pin 1″ x 4-7/8″ (123mm)
8 600383117 Ring CotterPin 1″
9 Bolt 5/8″ x 5-1/2″ Gr. 8 Plated
10 Bolt 5/8″ x 6″ Gr. 8 Plated
11 Locknut 5/8″ – Stover
12 Washer 5/8″ Plated
13 600383122 Wing Lock Pin Assembly with Lynch Pin
14 Lynch Pin Included with Item 13
15 600383109 Cylinder Base Pin 1″ x 3-3/4″ (95mm)
16 Bolt 5/8″ x 6-1/2″ Gr. 8 Plated
17 Carriage Bolt 1/4″ x 1″
18 Locknut 1/4″
19 600470047 Hose Clamp 1/2″
20 600470007 Hose Clamp 3/8″
21 600373070 U-Bolt 1/2″ x 2-9/16″ x 3-3/4″ Plated
22 600381050 Washer 1/2″ Plated
23 600366030 Locknut 1/2″ – Stover
24 601140765 Heavy Duty Rear Jack Assembly – Option
25 601232133 2800 Centre Connection Plate
26 Bolt 3/4″ x 2-1/2″ Gr. 8 Plated
27 Locknut 3/4″ – Stover
28 Washer 1″ and more
