Description

Atlas Copco Diamec U6 PHC Parts Catalog

Atlas Copco Diamec U6 PHC Index:

Contents
Diamec U6 8
Carrier complete. 3719 0013 68. 8
Turn table kit. 3719 0002 07. 10
Feed frame holder assembly. 3719 0002 00. 12
Positioner assembly . 3719 0006 42. 14
Positioner assembly fitting kit. 3719 0006 46. 16
Cylinder . 3719 0000 47. 18
Skid frame. 3719 0001 60. 20
Backstay leg. 3719 0002 19. 22
Feed frame . 24
Feed frame complete 850 mm. 3719 0061 30. 24
Feed frame 850 assembly. 3719 0001 22. 26
Feed frame fitting kit 850 mm. 3719 0005 99. 28
Feed cylinder 850 mm. 3719 0001 40. 30
Packing kit, feed cylinder 850 mm. 3719 0007 90. 32
Overhauling kit, feed cylinder 850 mm. 3719 0004 06. 34
Hose ladder assembly 850 mm. 3719 0006 45. 36
Hose ladder 850 mm hose kit A-N. 3719 0006 09. 38
Hose ladder fitting kit 850 mm. 3719 0006 14. 40
Guard assembly 850 mm A-N. 3719 0006 49. 42
Guard assembly 850 mm B-H. 3719 0011 82. 44
Feed frame complete 1800 mm. 3719 0061 32. 46
Feed frame 1800 assembly. 3719 0000 22. 48
Feed frame fitting kit 1800 mm. 3719 0006 29. 50
Cylinder 1800 mm . 3719 0000 00. 52
Packing kit, feed cylinder 1800 mm. 3719 0003 75. 54
Overhauling kit, feed cylinder 1800 mm. 3719 0004 05. 56
Hose ladder assembly 1800 mm. 3719 0007 56. 58
Hose ladder 1800 mm hose kit . 3719 0007 54. 60
Hose ladder fitting kit 1800 mm. 3719 0007 53. 62
Guard assembly 1800 mm . 3719 0002 58. 64
Feed frame complete 1800 mm DH. 3719 0061 33. 66
Feed frame 1800 DH assembly. . . . . . . . . . . . . . . . . . . . . . . . . 3719 0003 44. 68
Cylinder 1800 mm DH. 3719 0002 88. 70
Packing kit, feed cylinder 1800 mm DH. 3719 0005 37. 72
Overhauling kit, feed cylinder 1800 mm DH. 3719 0004 02. 74
Hose ladder assembly 1800 mm DH. . . . . . . . . . . . . . . . . . . . . 3719 0052 34. 76
Hose ladder 1800 mm DH V14 hose kit. 3719 0049 51. 78
Guard assembly 1800 mm DH. 3719 0011 20. 80

Hose ladder 850-1800 mm B-H hose kit. 3719 0060 97. 82
Cradle assembly cast.. 3719 0061 21. 84
Rod holder assembly. 3719 0001 12. 86
Rod holder insert. 3719 0000 96. 88
Rod holder fitting kit. 3719 0006 03. 90
Gas spring kit. 3719 0000 88. 92
E-stop kit. 3719 0019 61. 94
Top pulley. 3719 0001 93. 96
Standard wall bracket assembly. 3719 0002 17. 98
Rotation unit 100
Rotation unit A-N Basic 60cc complete. 3719 0068 62. 100
Rotation unit A-N Basic 60 cc. 3719 0068 61. 102
Rotation unit A-N Basic 80 cc complete. 3719 0068 53. 106
Rotation unit A-N, Basic 80 cc. 3719 0068 52. 108
Overhaul kit bushing rotation unit A-N. 3719 0068 63. 112
Packing kit bushing rotation unit A-N. . . . . . . . . . . . . . . . . . . . . 3719 0068 64. 114
Upgrade kit bushing rotation unit A-N. 3719 0068 65. 116
Rotation unit B-H Basic 100 cc complete . 3719 0066 91. 120
Rotation unit B-H, Basic 100 cc. . . . . . . . . . . . . . . . . . . . . . . . . 3719 0066 92. 122
Rotation unit B-H Basic 160 cc complete . 3719 0064 78. 128
Rotation unit B-H, Basic 160 cc. . . . . . . . . . . . . . . . . . . . . . . . . 3719 0064 79. 130
Control system 136
Hydraulic pilot system STD. 3719 0006 16. 136
Pilot panel PHC U6. 3719 0006 17. 138
Hydraulic pilot system DH. 3719 0008 33. 142
Pilot panel PHC U6 DH. 3719 0011 39. 144
Joystick 4-ports. 3719 0008 47. 148
Joystick 2-ports. 3719 0008 48. 150
Valve assembly U6 PHC. 3719 0008 39. 152
PU – Rig hose kit. 3719 0006 07. 158
Water control kit, PHC. 3719 0037 69. 160
Winch 162
W-L winch 1300 kit, JIC. 3719 0015 31. 162
Wire Line DH hoist assembly . 3719 0063 62. 164
W/L 1000 hose kit. 3719 0006 08. 168
Top pulley. 3719 0001 71. 170
Option . 172
Bracing device (support jacks). 3719 0027 94. 172
Keyhole wall bracket A-N rotation . 3719 0002 18. 174
Keyhole wall bracket B-H rotation . 3719 0067 71. 176
5
Contents
© 2010 Atlas Copco Craelius AB | 6991 5084 62 | 2010-08-26
Water collector. 3719 0032 45. 178
Bracket for casing clamp. 3719 0006 23. 180
Wireline sheave for steep uphole. 3719 0003 93. 182
Wheel kit rig . 3719 0041 71. 184
Dimension rel. kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186
A jaw & guide kit 43mm, A-N rot. . 3719 0052 80. 186
A jaw & guide kit 44mm, A-N rot. . 3719 0068 30. 188
Jaw & guide kit 45mm, A-N rot.. 3719 0052 81. 190
Jaw & guide kit 50mm, A-N rot.. 3719 0052 82. 192
B jaw & guide kit 53mm, A-N rot. . 3719 0052 83. 194
B jaw & guide kit 55mm, A-N rot. . 3719 0052 84. 196
Jaw & guide kit 64mm, A-N rot.. 3719 0062 05. 198
N Jaw & guide kit 70mm, A-N rot.. 3719 0052 85. 200
B jaw & guide kit 54mm, N-H rot. Unit . 3719 0053 81. 202
N jaw & guide kit 70mm, N-H rot. Unit . 3719 0053 83. 204
H jaw & guide kit 89mm, N-H rot. Unit . 3719 0053 84. 206

Atlas Copco
