Atlas Copco L1C DH Rocket Boomer Parts Catalog

Atlas Copco L1C DH Rocket Boomer Index:

Detaljnr
Description Benämning See page
Se sida
Remarks
Anmärkning
– DRILL RIG BORRAGGREGAT 9
– – COUNTERWEIGHT – MOTVIKT 11
– – WARNING SIGNS – VARNINGSSKYLTAR 13
– – – SIGN SET – – SKYLTSATS 17
– – LABEL LIST – DEKALLISTA 19
– – CABIN COMPLETE – HYTT KOMPLETT 23
5112 3068 79 – – WINDSHIELD WIP. – – VINDRUTETORKARE 27 REAR WINDOW
3217 9731 10 – – – MOTOR UNIT – – – MOTORENHET 29
– – – COVER – – KÅPA 31
5112 3068 18 – – DOOR STOP – – DÖRRSTOPP 33
5112 3200 60 – – LOCK – – LÅS 35
5112 3069 80 – – WINDSHIELD WIP. – – VINDRUTETORKARE 37
5112 3068 81 – – WINDSCREEN WASH – – VINDRUTESPOLARE 39
5112 3081 75 – – DOOR – – DÖRR 41
5112 3081 76 – – DOOR – – DÖRR 43
– – WINDOW – FÖNSTER 47
5112 0000 44 – EL.EQUIPMENT – ELUTRUSTNING 49
5112 0000 46 – – PLINTH MODULE – – PLINTMODUL 53
– – – PLINTH MODULE – – PLINTMODUL 55
5112 0000 09 – – PLINTH MODULE – – PLINTMODUL 57
– – – EL.EQUIPMENT – – ELUTRUSTNING 59
5112 3143 72 – – – JUNCTION BOX – – – KOPPLINGSLÅDA 61
– – – COVER COMPL. – – LOCK KOMPL. 63
– – – WIRING – – KABLAGE 65 DT06-2S-E0008 + 3M CABLE
– – – – CONNECTOR – – – KONTAKTDON 67 DEUTSCH DT06-2S-E0008
9106 1803 21 – WATER TANK – VATTENTANK 69
5112 3068 86 – – WATER TANK – – VATTENTANK 71

– – DRIVERS PANEL – FÖRARPANEL 73 BVX STD.
COMPLETE
– – – EL.EQUIPMENT – – ELUTRUSTNING 75
– – – – PANEL – – – PANEL 77
5112 3146 48 – – – – IGNITION LOCK – – – – TÄNDNINGSLÅS 79
– – – – PLINTH MODULE – – – PLINTMODUL 81 DRIVERS PANEL
– – DRIVERS C.COMPL – FÖRARSTOL KOMPL 83 M/L 2
5112 3078 70 – – DRIVERS CHAIR – – FÖRARSTOL 85 WITH SAFETYBELT
– – OPERATOR UNIT – OPERATÖRSENHET 87 OP. CHAIR HOLD +
5112 3127 60 – – CHAIR COMPL. – – STOL KOMPL. 89
5112 3300 19 – – PANEL HOLDER – – PANELFÄSTE 91
– – CAN HOLDER – BURKHÅLLARE 93
5112 3061 89 – CAB ATTACHMENT – HYTTFÄSTE 95
5112 3207 65 – AIR CONDITIONER – KLIMATANLÄGGN. 99 AIR.CON/HEATIN
– – – AIR COND.UNIT – – KLIMATOR 101
5112 3204 57 – – – CONTROLPANEL – – – KONTROLLPANEL 103
– – – CONDENSER – – KONDENSOR 105 M/L 2
– – – PUMP SET – – PUMPSATS 107
3177 3092 48 – – – DIRECTION VALVE – – – RIKTNINGSVENTIL 109
– – – EL.EQUIPMENT – – ELUTRUSTNING 111
– – – COMPRESSOR SET – – KOMPRESSORSATS 113
3216 8073 01 – – – COMPRESSOR – – – KOMPRESSOR 115 AIR CONDITION
– – HOSE SET – SLANGSATS 117
– – DRILL BIT BOX – KRONLÅDA 119
– – MAN.GREASE SYST – MAN.FETTSMÖRJN. 123
– – – DRUM PUMP – – FATPUMP 125
– – – HOSE SET – – SLANGSATS 127
9106 1671 42 – FIRE SUPPR.SYST – ELDBEKÄMPN.SYST 129
– – – FIRE EXTING.SET – – ELDSLÄCKN.SATS 133
