Atlas Copco ROC 642HC-10 Hydraulic Crawler Drill Parts Catalog
Atlas Copco ROC 642HC-10 Hydraulic Crawler Drill Index:
CONTENTS
Cab assembly 3216 8123 60
Cab 32168123 eo
cab platform 3216 8å856å.
Drilling controls 3214305060
Protective screen 3216 8367 60..
Rear control panel 3216 6535 61..
Rear control panel, compt. 3222208963.
Boom system 3214 2004 61
Boom eying cylinder 3216 390000
Conditioning unit assembly 3216 8601 61 .
Conditioning unit 3214 6757 00
Electrical components 3222 2709 60
Electric cables 3222 2709 60..
Electric cables 3216 8482 60.
Electrical box, cab 3216 846380.
Diesel box, compl. 3216 7448 82
Control box 3216 848880 …
Junction box 32164313 81 . : :
Hydraulic sßem, traction 3216 5162 60 .
Hydraulic system, traction control 3216 7350 60
Pilot valve 3216 717280
Hydraulic system, control panel 3216 7351 60.
Hydraulic sy<em, drilling controls 3216 7354 60.
Valve block, feed regulation 3214 7675 80.
Hydraulic sßem, rear control panel 3216 7355 60.
Hydraulic system, control panel 3216 7355 61.
Hydraulic system, cab 3216 733260 .
Hydraulic system, double positioning 3216 8114 60
Hydraulic system. boom 3216 7352 60.
OPTIONAL EQUIPMENT
Exhaust cover 32222443 60 .
Platesstickersset, compl. 32ii 1939 60, 3222 1940 60.3222 1941 60, “22 042 60, 3222 1943 60,
3222 1944 60.3222 2576 61.3222 2577 61 , 3222 2578 61 , 3222 2579 61 , 3222 2580 61
Seat support. adjustable 3216 8202 60.
Noise insulated windows 3216 8358 60
Tinted windows 3216 835B 62
