Atlas Copco Roc F9 CR Drilling Rig Parts Catalog
Atlas Copco Roc F9 CR Drilling Rig Index:
Table of Content / Innehållsförteckning
1. DRILL CARRIAGE / BORRVAGN …………………………………………………. 5
2. DRIVE UNIT / DRIVENHET ………………………………………………………… 71
3. BOOM SYSTEM / BOMSYSTEM ………………………………………………. 133
4. FEED / MATARE ……………………………………………………………………… 169
5. CABIN COMPLETE / HYTT KOMPLETT ……………………………………. 243
6. AIR CONDITIONER / KLIMATANLÄGGN. ……………………………………311
7. DCT EQUIPMENT / DCT UTRUSTNING …………………………………….. 333
8. SIGN SET / SKYLTSATS ………………………………………………………….. 349
9. HYDR. RESERVOIR / HYDRAULTANK ……………………………………… 357
10. HYDR. SYSTEM / HYDRAULSYSTEM ………………………………………. 365
11. AIR SYSTEM / LUFTSYSTEM ………………………………………………….. 497
12. HOSE SET COMPL. / SLANGSATS KOMPL ……………………………… 565
13. ELECTR. SYSTEM / ELSYSTEM ……………………………………………… 579
14. CABLE SET / KABELSATS ……………………………………………………… 667
15. OPTION / OPTION ………………………………………………………………….. 671
16. CROSS REFERENCE LIST ……………………………………………………….. 735
