Description
Atlas Copco ROC L6 Drilling Rig Parts Catalog
Atlas Copco ROC L6 Drilling Rig Index:
Table of Content / Innehållsförteckning
1. DRILL CARRIAGE / BORRVAGN …………………………………………………. 5
2. DRIVE UNIT / DRIVENHET ………………………………………………………… 55
3. BOOM SYSTEM / BOMSYSTEM ………………………………………………. 133
4. FEED / MATARE ……………………………………………………………………… 173
5. ROTATION UNIT / ROTATIONSENHET ……………………………………… 253
6. CABIN / HYTT …………………………………………………………………………. 269
7. AIR CONDITIONER / KLIMATANLÄGGN. ………………………………….. 329
8. DUST COLLECTOR / DAMMAVSKILJARE ………………………………… 369
9. SIGN SET / SKYLTSATS ………………………………………………………….. 391
10. HYDR. RESERVOIR / HYDRAULTANK ……………………………………… 401
11. HYDR. SYSTEM / HYDRAULSYSTEM ………………………………………. 409
12. AIR SYSTEM / LUFTSYSTEM ………………………………………………….. 525
13. HOSE SET COMPL. / SLANGSATS KOMPL ……………………………… 583
14. ELECTR. SYSTEM / ELSYSTEM ……………………………………………… 595
15. CABLE SET / KABELSATS ……………………………………………………… 667
16. OPTION / OPTION ………………………………………………………………….. 671
17.CROSS REFERENCE LIST ………………………………………………………… 783
