Atlas Copco ROC L8 Drilling Rig Parts Catalog
Atlas Copco ROC L8 Drilling Rig Index:
LIST OF CONTENTS
Part no
Detaljnr
Description Benämning See page
Se sida
Remarks
Anmärkning
– DRILL CARRIAGE BORRVAGN 7
3222 3060 41 – WAGON FRAME – VAGNSRAM 9
8232 3000 86 – – HYDR. CYLINDER – – HYDRAULCYLINDER 13
3222 3178 49 – – ATTACHM.COMPLET – – FÄSTE KOMPLETT 15
3222 3160 56 – – TOOL BOX – – VERKTYGSLÅDA 17
3222 2362 66 – TRACK FRAME – BANDRAM 19 SINGLE GROUSER
3222 2362 88 – – TRACK FRAME – – BANDRAM 21 RIGHT COMPLETE
3216 7199 80 – – – BANDPULLEY – – – BANDRULLE 25
3216 7201 81 – – – FRONT WHEEL – – – FRAMHJUL 27
3222 2378 80 – – – TRACK CHAIN – – – LARVBAND 29
3222 2362 67 – TRACK FRAME – BANDRAM 31 TRIPLE GROUSER
3222 0114 88 – – TRACK FRAME – – BANDRAM 33 RIGHT, COMPLETE
3216 7199 80 – – – BANDPULLEY – – – BANDRULLE 25
3216 7201 81 – – – FRONT WHEEL – – – FRAMHJUL 27
3216 7197 80 – – – TRACK CHAIN – – – LARVBAND 37
3222 3093 72 – BODY – KAROSS 39
3222 3059 53 – – BODY FRAME – – KAROSSRAM 41
3222 3093 73 – – BODY – – KAROSS 43
3214 8734 00 – – – DRIVING MIRROR – – – BACKSPEGEL 47
