Bobcat 853 Loader Service Manual (SN 510375001-510399999)

Format: PDF (Printable Document)

File Language: English

File Pages: 398

File Size: 10.41 MB (Speed Download Link)

Brand: Bobcat

Model: 853 Loader

Book No: 6720755

Serial No: SN 510375001-510399999

Type of Document: Service Manual

Categories: ,

$ 45

Share:

Bobcat 853 Loader Service Manual (SN 510375001-510399999)

An 853 is an older skid-steer, but it still earns its keep pushing dirt, running an auger, feeding bales, and loading trucks. The service manual is what you reach for when the drive gets weak, a function quits, or you're halfway through a teardown and need the right sequence. Around my place, it comes out on Friday night when I've got one weekend to get the machine back in the pen and working by Monday.

What this manual helps you do

  • Diagnose weak drive, slow hydraulics, or no-move conditions using the proper test ports and pressure checks
  • Trace electrical issues like no-start, dead gauges, or safety interlock problems with wiring diagrams and step-by-step tests
  • Follow teardown and reassembly procedures for pumps, drive motors, cylinders, and linkage so parts go back in the right order
  • Check and adjust control linkages, chains, brakes, and hydraulic settings after repairs so the loader drives straight and lifts right
  • Replace engine and hydraulic components with the right sequences, seal directions, and torque references already laid out

Who this is for

This is for an 853 owner-operator, small contractor, farm shop, or rental fleet mechanic who is actually wrenching on the machine. If you just want to learn what the switches do or basic maintenance intervals, you need the operator's handbook instead, not this manual.

FAQ

Q: Is this a searchable PDF with readable wiring diagrams?

A: Yes, it's a PDF manual, and these are normally searchable with zoomable wiring and hydraulic schematics.

Q: Will this cover my 853 if my serial number is between 510375001 and 510399999?

A: Yes, this manual is matched to that exact serial number range and its configuration.

Q: Is this the right document if I'm doing real repairs, not just checking fluids?

A: Yes, this is the workshop service manual, meant for diagnostics, teardown, and reassembly work.

Bottom line: If your 853's serial number falls in 510375001-510399999 and you plan to do your own repairs, this is the manual you want. If you just need operating tips, it's the wrong book.
