On a job, an E35 is your trench and footing machine, digging utilities, stump work, and tight-access stuff where a big excavator won't fit. The service manual is what you grab when the machine's down, the dealer's booked out, and you'd rather spend a night in the shop than lose a day on the job. Around my shop, I use this kind of manual when I'm chasing hydraulic issues, wiring gremlins, or putting an engine or swing motor back together and I don't want to guess.
What this manual helps you do
- Trace hydraulic circuits so you can troubleshoot weak functions, drift, or no-move conditions
- Check and set diagnostic pressures on the excavator's hydraulic and hydrostatic systems
- Follow step-by-step teardown and reassembly for components like cylinders, drive motors, and final drives
- Diagnose electrical problems using wiring diagrams and test procedures for sensors, switches, and controllers
- Replace and adjust major assemblies like boom/stick pins, slew components, and control linkages with the right sequences
Who this is for
This is for anyone running or fixing a Bobcat E35 excavator in the serial range B3K811001 to B3K899999: small contractors, owner-operators, field techs, and shop mechanics. If you just want basic controls, capacities, or daily service points, you want the operator's handbook instead, not this manual.
FAQ
Q: Is this a searchable PDF and are the wiring diagrams readable?
A: Yes, these manuals are usually searchable PDFs, and the wiring diagrams are laid out so you can zoom in and follow circuits clearly on screen or printed.
Q: How do I know if it covers my exact E35?
A: Check your machine's serial plate. If it falls between B3K811001 and B3K899999, this is the right manual. If not, you need the manual for your exact serial range.
Q: Is this the right document if I'm doing real repairs, not just oil changes?
A: Yes, this is the workshop-level service manual, meant for actual diagnostics and repair work, not routine operator maintenance.
Bottom line: If you've got an E35 in that B3K811001-B3K899999 range and you turn your own wrenches, this is the manual you want. If your serial is outside that range, don't buy this one.
📘 Show Index
Table of Contents:
- MAINTENANCE SAFETY
- CONTENTS
- FOREWORD
- FOREWORD
- SAFETY INSTRUCTIONS
- FIRE PREVENTION
- Maintenance
- Operation
- Electrical
- Hydraulic System
- Fueling
- Starting
- Spark Arrester Exhaust System
- Welding And Grinding
- Fire Extinguishers
- SERIAL NUMBER LOCATIONS
- Excavator Serial Number
- Engine Serial Number
- DELIVERY REPORT
- EXCAVATOR IDENTIFICATION
- SAFETY AND MAINTENANCE
- LIFTING AND BLOCKING THE EXCAVATOR
- LIFTING THE EXCAVATOR
- OPERATOR CAB (ROPS / TOPS)
- Description
- Cab Door
- Front Window
- Front Wiper
- Window Washer Reservoir
- Right Side Window
- OPERATOR CANOPY (ROPS / TOPS)
- TRANSPORTING THE EXCAVATOR ON A TRAILER
- Loading And Unloading
- Fastening
- TAILGATE
- Opening And Closing
- Adjusting The Latch
- RIGHT SIDE COVER
- SERVICE SCHEDULE
- AIR CLEANER SERVICE
- Daily Check
- Replacing The Filter Elements
- CAB FILTERS (S/N A93K11001 – A93K17999 AND AC2P11001 – AC2P14999)
- CAB FILTERS (S/N A93K18000 & ABOVE, AC2P15000 & ABOVE, B3GR11001 & ABOVE AND B3K811001 & ABOVE)
- ENGINE COOLING SYSTEM
- Cleaning
- Checking Level
- Removing And Replacing Coolant
- FUEL SYSTEM
- Fuel Specifications
- Biodiesel Blend Fuel
- Filling The Fuel Tank
- Fuel Filters
- Draining The Fuel Tank
- Removing Air From The Fuel System
- ENGINE LUBRICATION SYSTEM
- Checking And Adding Engine Oil
- Oil Chart
- Removing And Replacing Oil And Filter
- HYDRAULIC SYSTEM
- Checking And Adding Hydraulic Fluid
- Hydraulic / Hydrostatic Fluid Chart
- Removing And Replacing Hydraulic Filters
- Removing And Replacing Hydraulic Fluid
- LUBRICATION OF THE HYDRAULIC EXCAVATOR
- PIVOT PINS
- Inspection And Maintenance
- TRAVEL MOTOR
- Checking And Adding Oil
- Removing And Replacing Oil
- SPARK ARRESTER MUFFLER
- EMERGENCY EXIT
- Right Side Rear Window
- Front Window
- SEAT BELT
- Inspection And Maintenance
- CONTROL CONSOLE LOCKOUTS
- Inspection And Maintenance
- TOWING THE EXCAVATOR
- REMOTE START TOOL KIT – MEL1563
- Remote Start Tool – MEL1563
- Service Tool Harness Control – MEL1565
- Service Tool Harness Communicator – MEL1566
- REMOTE START TOOL (SERVICE TOOL) KIT – 7217666
- Description
- Remote Start Tool (Service Tool) – 7022042
- Excavator Service Tool Harness – 6689747
- Computer Service Tool Harness – 6689746
- HYDRAULIC SYSTEM
- HYDRAULIC / HYDROSTATIC SCHEMATICS
- HYDRAULIC SYSTEM INFORMATION
- Glossary Of Hydraulic / Hydrostatic Symbols
- Troubleshooting The Hydraulic Circuit
- Troubleshooting The Cylinder Circuit
- Troubleshooting The Swing (Upperstructure Slew) Circuit
- Troubleshooting The Travel Circuit
- CYLINDER (BOOM) (S/N A93K13096 & ABOVE, AC2P13032 & ABOVE, B3GR11001 & ABOVE, AND B3K811001 & ABOVE)
- Testing
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- CYLINDER (BOOM) (S/N A93K13095 & BELOW, AC2P13031 & BELOW)
- Testing
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- CYLINDER (ARM)
- Testing
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- CYLINDER (BOOM SWING)
- Testing
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- CYLINDER (BUCKET)
- Testing
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- CYLINDER (BLADE)
- Testing
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- CYLINDER (CLAMP)
- Testing
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- CYLINDER (ANGLE BLADE)
- Testing
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- CYLINDER (EXTENDABLE ARM)
- Testing
- Parts Identification
- Disassembly
- Assembly
- VALVE (MAIN RELIEF)
- VALVE (PORT RELIEF)
- VALVE (CROSS PORT RELIEF)
- Testing
- Removal And Installation
- Disassembly And Assembly
- VALVE (PILOT PRESSURE RELIEF)
- HYDRAULIC CONTROL VALVE
- Description
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- Inlet Valve Section Disassembly And Assembly
- Boom Swing Valve Section Disassembly And Assembly
- Slew Valve Section Disassembly And Assembly
- Blade Valve Section Disassembly And Assembly
- Right And Left Travel Valve Section Disassembly And Assembly
- Boom Valve Section Disassembly And Assembly
- Auxiliary, Arm, Bucket And Angle Blade Valve Section Disassembly And Assembly
- Outlet Valve Section Disassembly And Assembly
- HYDRAULIC PUMP
- Hydraulic Pump Work Sheet
- Pump Testing
- Description
- Removal And Installation
- Coupler Removal And Installation
- Hydraulic Pump Startup
- Gear Pump Disassembly And Assembly
- Piston Pump Parts Identification
- Piston Pump Disassembly And Assembly
- MANIFOLD ASSEMBLY / ACCUMULATOR (WITHOUT ANGLE BLADE)
- Description
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- MANIFOLD ASSEMBLY / ACCUMULATOR (WITH ANGLE BLADE)
- Description
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- TRAVEL MOTOR
- Removal And Installation
- Parts Identification Hydraulic Motor
- Parts Identification Gear Reduction Hub
- Disassembly
- Assembly
- SWIVEL JOINT
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- SWING MOTOR
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- SWING MOTOR (DRIVE CARRIER)
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- CONTROL PATTERN SELECTOR VALVE
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- RIGHT CONTROL LEVER (JOYSTICK) (S/N A93K11001 – A93K17999 AND AC2P11001 – AC2P14999)
- Testing
- Handle Removal And Installation
- Joystick Assembly Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- RIGHT CONTROL LEVER (JOYSTICK) (S/N A93K18001 & ABOVE, AC2P15001 & ABOVE, B3GR11001 & ABOVE AND B3K811001 & ABOVE)
- Testing
- Handle Removal And Installation
- Joystick Assembly Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- LEFT CONTROL LEVER (JOYSTICK) (S/N A93K11001 – A93K17999 AND AC2P11001 – AC2P14999)
- Testing
- Handle Removal And Installation
- Joystick Assembly Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- LEFT CONTROL LEVER (JOYSTICK) (S/N A93K18001 & ABOVE, A2CP15001 & ABOVE, B3GR11001 & ABOVE AND B3K811001 & ABOVE)
- Testing
- Handle Removal And Installation
- Joystick Assembly Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- HYDRAULIC FILTER MOUNT
- HYDRAULIC RESERVOIR
- OIL COOLER
- DIRECT TO TANK VALVE
- BLADE CONTROL LEVER
- Handle Removal And Installation
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- CASE DRAIN FILTER MOUNT
- TRAVEL CONTROL VALVE
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- REMOVING AIR FROM THE HYDRAULIC SYSTEM
- HYDRAULIC X-CHANGE MANIFOLD (EARLY MODELS)
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- HYDRAULIC X-CHANGE MANIFOLD (LATER MODELS)
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- SECONDARY AUXILIARY VALVE (EARLY MODELS)
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- SECONDARY AUXILIARY VALVE (LATER MODELS)
- Removal And Installation
- Parts Identification
- VALVE (BOOM LOCK)
- VALVE (ARM LOCK)
- UNDERCARRIAGE
- BLADE
- ANGLE BLADE
- TRACK UNDERCARRIAGE COMPONENTS (RUBBER TRACK)
- Description
- Track Lug Height
- Checking Tension
- Adjusting Tension
- Track Removal And Installation
- Idler Removal And Installation
- Parts Identification
- Idler Disassembly
- Idler Assembly
- Track Tensioner Removal And Installation
- Track Tensioner Parts Identification
- Track Tensioner Disassembly And Assembly
- Roller Removal And Installation
- Sprocket Removal And Installation
- TRACK UNDERCARRIAGE COMPONENTS (STEEL TRACK)
- Description
- Checking Tension
- Adjusting Tension
- Track Removal And Installation
- Idler Removal And Installation
- Idler Parts Identification
- Idler Disassembly
- Idler Assembly
- Track Tensioner Disassembly And Assembly
- Track Tensioner Cylinder Parts Identification
- Track Tensioner Disassembly And Assembly
- Roller Removal And Installation
- Sprocket Removal And Installation
- Guide Plate Removal And Installation
- TRACK MAINTENANCE
- Track Damage Identification
- SWING CIRCLE GEAR
- Swing Bearing Removal
- Swing Bearing Installation
- UPPERSTRUCTURE AND SWING SECTION
- UPPERSTRUCTURE
- ROPS CANOPY
- CAB
- Removal And Installation
- Door Removal And Installation
- Front Window Removal And Installation
- Right Side Rear Sliding Window Removal And Installation
- Right Side Front Sliding Window Removal And Installation
- Right Side Front And Rear Sliding Window Weather Strip Removal And Installation
- Right Side Front And Rear Sliding Window Wiper Strip Removal And Installation
- Glass Removal
- Glass Installation
- SEAT
- Removal And Installation
- Seat Mount Removal And Installation
- RIGHT CONSOLE (S/N A93K11001 – A93K17999 AND AC2P11001 – AC2P14999)
- Console Cover Removal And Installation
- RIGHT CONSOLE (S/N A93K18000 & ABOVE, AC2P15000 & ABOVE, B3GR11001 & ABOVE AND B3K811001 & ABOVE)
- Console Cover Removal And Installation
- LEFT CONSOLE
- Lower Console Cover Removal And Installation
- Upper Console Cover Removal And Installation
- Compression Spring Removal And Installation
- Lock Lever Removal And Installation
- Console Removal And Installation
- LEFT UPPERSTRUCTURE COVER
- RIGHT UPPERSTRUCTURE COVER
- COUNTERWEIGHT
- Removal And Installation
- Long Arm Counterweight Removal And Installation
- TRAVEL LEVERS AND PEDALS
- Removal And Installation
- Disassembly And Assembly
- FLOOR MAT
- FUEL TANK
- Removal And Installation (Canopy Equipped Excavator)
- Removal And Installation (Cab Equipped Excavator)
- HORN
- SWING FRAME
- Removal And Installation
- Boom Swing Frame Hose Routing
- Bushing Removal
- Bushing Installation
- BOOM
- ARM (STANDARD AND LONG)
- Removal And Installation
- Arm To Boom Bushing Removal And Installation
- Arm To Bucket And Bucket Link Bushing Removal And Installation
- ARM (EXTENDABLE)
- Removal And Installation
- Arm To Boom Bushing Removal And Installation
- Arm To Bucket Bushing Removal And Installation
- Disassembly And Assembly
- Shimming Procedure
- BUCKET
- Bucket Teeth Removal And Installation
- Bucket Side Cutting Edge Removal And Installation
- CLAMP
- TAILGATE
- Removal And Installation
- Latch Removal And Installation
- X-CHANGE
- Removal And Installation
- Disassembly
- Assembly
- X-CHANGE (HYDRAULIC)
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- QUICK COUPLER (KLAC™ SYSTEM)
- Troubleshooting
- Daily Inspection
- Removal And Installation
- Parts Identification
- Disassembly
- Assembly
- QUICK COUPLER (LEHNHOFF® SYSTEM)
- Troubleshooting
- Daily Inspection
- Removal (MS03 And MS08)
- Installation (MS03 And MS08)
- Parts Identification (MS03)
- Disassembly And Assembly (MS03)
- Parts Identification (MS08)
- Disassembly (MS08)
- Assembly (MS08)
- QUICK COUPLER (PIN GRABBER)
- Troubleshooting
- Daily Inspection
- Removal And Installation
- Parts Identification
- Disassembly And Assembly
- RIGHT SIDE COVER
- Removal And Installation
- Latch Removal And Installation
- Latch Adjustment
- TOOL BOX
- ELECTRICAL SYSTEM AND ANALYSIS
- ELECTRICAL SCHEMATICS
- ELECTRICAL SYSTEM INFORMATION
- Troubleshooting Chart
- Description
- Fuse And Relay Location / Identification
- BATTERY
- Servicing
- Removal And Installation
- Using A Booster Battery (Jump Starting)
- ALTERNATOR
- Belt Adjustment
- Belt Replacement
- Charging System Inspection
- Alternator Voltage Testing
- Low Voltage Testing
- High Voltage Testing
- Removal And Installation
- Parts Identification
- STARTER
- Testing
- Removal And Installation
- Parts Identification
- LIGHTS
- Removal And Installation
- Boom Light Removal And Installation
- Boom Light Bulb Replacement
- MAGNETIC LOCKOUT SENSOR
- FUEL LEVEL SENDER
- Removal And Installation
- Testing
- DIAGNOSTICS SERVICE CODES (S/N A93K11001 – A93K17999 AND AC2P11001 – AC2P14999)
- DIAGNOSTIC SERVICE CODES (S/N A93K1800 & ABOVE, AC2P1500 & ABOVE, B3GR11001 & ABOVE, B3K811001 & ABOVE)
- Viewing Service Codes
- Service Codes List
- DELUXE INSTRUMENT PANEL SETUP (S/N A93K11001 – A93K17999 AND AC2P11001 – AC2P14999)
- Passwords
- Password Entry (For Starting And Operating The Machine)
- Changing The Operator Password
- Password Lockout Feature
- Job Clock
- RPM
- CONTROL PANEL SETUP (S/N A93K18000 & ABOVE, AC2P15000 & ABOVE, B3GR11001 & ABOVE AND B3K811001 & ABOVE)
- Panel Setup (Deluxe Instrument Panel)
- Password Setup (Keyless Start Panel)
- Password Setup (Deluxe Instrument Panel)
- Maintenance Clock
- INSTRUMENT PANEL / CONTROLLER (S/N A93K11001 – A93K17999 AND AC2P11001 – AC2P14999)
- INSTRUMENT PANEL (S/N A93K18000 & ABOVE, AC2P15000 & ABOVE, B3GR11001 & ABOVE AND B3K811001 & ABOVE)
- CONTROLLER (S/N A93K18000 & ABOVE, AC2P15000 & ABOVE, B3GR11001 & ABOVE AND B3K811001 & ABOVE) (GATEWAY AND AUXILIARY)
- Description
- Gateway Controller Removal And Installation
- Auxiliary Controller Removal And Installation
- KEY SWITCH
- WIPER MOTOR
- MOTION ALARM SYSTEM
- Description
- Inspecting
- Adjusting Switch Position
- SERVICE PC (LAPTOP COMPUTER)
- Connecting The Remote Start Tool
- Connecting Remote Start Tool (Service Tool)
- Operation
- SHUT-OFF SWITCH
- Description
- Removal And Installation
- ENGINE SERVICE
- ENGINE INFORMATION
- Description
- Specifications
- Crankshaft Re-Grind Data
- Torque For Kubota® Metric Bolts
- Troubleshooting
- Engine Removal And Installation
- Compression – Checking
- ENGINE SPEED CONTROL
- Removal And Installation
- Auto Idle Description
- Auto Idle Controller Removal And Installation
- Calibration
- Actuator Removal And Installation
- MUFFLER
- AIR CLEANER
- Housing Removal And Installation
- ENGINE COOLING SYSTEM
- Radiator Removal And Installation
- Fan Removal And Installation
- Water Pump Removal And Installation
- Water Pump Disassembly And Assembly
- Thermostat Housing Removal And Installation
- Thermostat – Testing
- LUBRICATION SYSTEM
- Oil Pan Removal And Installation
- Oil Pump Removal And Installation
- Oil Pump Inspection
- Engine Oil Pressure – Testing
- FUEL SYSTEM
- Fuel Shutoff Solenoid – Checking
- Fuel Shut-off Solenoid Removal And Installation
- Fuel Injection Pump – Checking
- Fuel Injection Pump Removal And Installation
- Fuel Injection Pump – Timing
- Fuel Camshaft Removal And Installation
- Fuel Camshaft Governor
- Fuel Injector Removal And Installation
- Fuel Injector Nozzle Pressure – Checking
- Nozzle Spray Condition
- Valve Seat Tightness
- CYLINDER HEAD
- Glow Plugs – Testing
- Glow Plugs Removal And Installation
- Valve Clearance Adjustment
- Valve Timing – Checking
- Cylinder Head Removal And Installation
- Cylinder Head Disassembly And Assembly
- Cylinder Head – Servicing
- Cylinder Head Top Clearance
- Valve Guide – Checking
- Valve Guide Removal And Installation
- Reconditioning The Valve And Valve Seat
- Valve Spring
- Valve Tappets
- Rocker Arm And Shaft – Checking
- Push Rod Alignment – Checking
- CRANKSHAFT AND PISTONS
- Piston And Connecting Rod Removal And Installation
- Piston And Connecting Rod – Servicing
- Cylinder Bore – Checking
- Connecting Rod Alignment
- Crankshaft Gear Removal And Installation
- Crankshaft And Bearings Removal And Installation
- Crankshaft And Bearings – Servicing
- CAMSHAFT AND TIMING GEARS
- Timing Gearcase Cover Removal And Installation
- Timing Gears Backlash – Checking
- Idle Gear And Camshaft Removal And Installation
- Camshaft – Servicing
- Idle Gear And Shaft – Servicing
- FLYWHEEL AND HOUSING
- Hydraulic Pump Coupler Removal And Installation
- Flywheel Removal And Installation
- Flywheel Ring Gear
- HEATING, VENTILATION AND AIR CONDITIONING (HVAC) S/N A93K11001 – A93K17999 AND AC2P11001 – AC2P14999
- AIR CONDITIONING SYSTEM FLOW
- Description
- Chart
- Components
- Safety Equipment
- REGULAR MAINTENANCE
- Cab Filters
- Fan Belt Adjustment
- Fan Belt Replacement
- Condenser
- Air Conditioning Lubrication
- Evaporator / Heater Coil
- Air Conditioning Service Chart
- TROUBLESHOOTING
- Blower Motor Does Not Operate
- Blower Motor Operates Normally, But Air Flow Is Insufficient
- Insufficient Cooling Although Air Flow And Compressor Operation Are Normal
- The Compressor Operates Improperly Or Not At All
- Gauge Pressure Related Troubleshooting
- Temperature / Pressure Chart
- Poor A/C Performance
- HVAC Repair And Leaks
- Electrical System
- Engine Coolant Bypassing The Heater Valve
- SYSTEM CHARGING AND RECLAMATION
- Refrigerant Identification
- Reclamation And Charging With Recovery / Charging Unit
- COMPRESSOR
- Removal And Installation
- Oil
- Oil Check
- CONDENSER
- RECEIVER / DRIER
- Receiver / Drier Removal And Installation
- Pressure Relief Valve Removal And Installation
- Pressure Switch Removal And Installation
- EVAPORATOR / HEATER UNIT
- THERMOSTAT
- Description
- Removal And Installation
- EXPANSION VALVE
- EVAPORATOR COIL
- HEATER COIL
- BLOWER FAN
- HEATER VALVE
- HVAC DUCT
- HEATING, VENTILATION AND AIR CONDITIONING (HVAC) S/N A93K18000 & ABOVE, AC2P15000 & ABOVE, B3GR11001 & ABOVE AND B3K811001 & ABOVE
- AIR CONDITIONING SYSTEM FLOW
- Description
- Chart
- Components
- Safety Equipment
- REGULAR MAINTENANCE
- Cab Filters
- Air Conditioning Compressor Belt Adjustment
- Air Conditioning Compressor Belt Replacement
- Condenser
- Air Conditioning Lubrication
- Evaporator / Heater Coil
- Air Conditioning Service Chart
- TROUBLESHOOTING
- Blower Motor Does Not Operate
- Blower Motor Operates Normally, But Air Flow Is Insufficient
- Insufficient Cooling Although Air Flow And Compressor Operation Are Normal
- The Compressor Operates Improperly Or Not At All
- Gauge Pressure Related Troubleshooting
- Temperature / Pressure Chart
- Poor A/C Performance
- HVAC Repair And Leaks
- Electrical System
- Engine Coolant Bypassing The Heater Valve
- SYSTEM CHARGING AND RECLAMATION
- Refrigerant Identification
- Reclamation And Charging With Recovery / Charging Unit
- COMPRESSOR
- Removal And Installation
- Oil
- Oil Check
- CONDENSER
- RECEIVER / DRIER
- Receiver / Drier Removal And Installation
- Pressure Relief Valve Removal And Installation
- Pressure Switch Removal And Installation
- EVAPORATOR / HEATER UNIT
- THERMOSTAT
- Description
- Removal And Installation
- EXPANSION VALVE
- EVAPORATOR COIL
- HEATER COIL
- BLOWER FAN
- HEATER VALVE
- HVAC DUCT
- SPECIFICATIONS
- EXCAVATOR SPECIFICATIONS
- Excavator Machine Dimensions
- Excavator Machine Dimensions – Standard Arm
- Excavator Machine Dimensions – Long Arm
- Excavator Machine Dimensions – Extendable Arm
- Excavator Machine Dimensions – Angle Blade
- Performance
- Controls
- Engine
- Hydraulic System
- Hydraulic Cylinders
- Hydraulic Cycle Times
- Drive System
- Slew System
- Undercarriage
- Electrical
- Capacities
- Tracks
- Ground Pressure
- TECHNICAL SERVICE GUIDE SPECIFICATIONS
- Engine
- Engine Torques
- Cooling System
- Excavator Torques
- TORQUE SPECIFICATION FOR BOLTS
- Torque For General SAE Bolts
- Torque For General Metric Bolts
- HYDRAULIC CONNECTION SPECIFICATIONS
- O-ring Face Seal Connection
- Straight Thread O-ring Fitting
- Tubelines And Hoses
- Flare Fitting
- O-ring Flare Fitting
- Port Seal Fitting
- Push To Connect Fittings
- HYDRAULIC FLUID SPECIFICATIONS
- CONVERSIONS
- Decimal And Millimeter Equivalent Chart
- U.S. To Metric Conversion Chart
- SERVICE TOOLS REQUIRED
- Remote Start Tools
- Hydraulic Tools
- Engine Tools
- Electrical Tools
- HVAC Tools
- ALPHABETICAL INDEX
Bobcat Software
Bobcat PDF Manuals
