Case 424 International Harvester Service Manual (IH-201)

These old Case/International tractors usually live hard lives—feeding cattle, mowing ditches, dragging implements around dusty fields and muddy lots. This service manual’s there to walk you through how to trace a problem, verify what’s actually failed, and get it back working without throwing parts at it. Say the engine’s running rough and won’t pull; instead of guessing at fuel or ignition, you’ll follow a set path: inspect basics, test fuel delivery, check ignition, then isolate which system’s really at fault before you spend a dime.

Applications & Use Cases

• Track down hard-start or no-start issues by following the fuel and ignition checks in order, so you can isolate whether it’s spark, fuel, or compression.
• Chase overheating by checking thermostat, radiator, and water pump step by step, not just flushing and hoping.
• Verify brake or clutch problems by measuring free play, inspecting linkage, and testing engagement before you split the tractor.
• Route and align belts, linkages, and controls the right way after a teardown, so everything operates smoothly and doesn’t bind.
• Bleed and test hydraulic functions systematically to see if you’ve got air, a weak pump, or a control valve issue.

FAQ

Q: Is this a PDF I can search on my laptop or phone?

A: Yes, it’s typically a searchable PDF, so you can jump to sections fast instead of flipping pages for half an hour.

Q: Can I print just the pages I need to take to the barn?

A: Usually yes; most folks print the specific systems they’re working on and don’t worry about getting grease on them.

Safety Note

Always support raised equipment with proper stands and bleed off any stored hydraulic pressure before you put your hands in harm’s way.

Case 424 International Harvester Index:

BELT PULLEY
BRAKES
CARBURETOR (Gas)
CARBURETOR (LP-Gas)
CLUTCH, ENGINE

COOLING SYSTEM

Radiator

Water Pump

DIESEL FUEL SYSTEM

Injection Pump and Drive

Nozzles

System Checks

DIFFERENTIAL

DIRECTION REVERSER

ENGINE

Balancer

Cam Followers

Camshaft

Connecting Rod & Bearings

Crankshaft

Cylinder Head

Engine Removal

Flywheel

Ignition Timing

Main Bearings

Oil Pump

Oil Cooler

Piston & Rings

Piston Pins

Rear Oil Seal

Rocker Arms

Timing Gear Cover

Timing Gears

Valves and Seats

Valve Guides & Springs

Valve Timing

FINAL DRIVE

Bull Gears

FINAL DRIVE CONT.

Bull Pinions

Wheel Axle Shaft

FRONT SYSTEM

Axle Main Member

Steering Knuckles

Tie Rods and Drag Links

Tricycle Type

GOVERNOR (NON-DIESEL)

HYDRAULIC SYSTEM

Control Valves

Lubrication

Pump

Regulator & Safety Valve

System Adjustments

Testing

Trouble Shooting

POWER STEERING SYSTEM

Cylinder

Flow Control & Relief Valve

Lubrication and Bleeding

Power Unit

Pump

Rotary Valve

Steering Gear

Steering Valves

Testing

Trouble Shooting

Pilot Valve

Hand Pump

POWER TAKE-OFF

Adjustments (Clutch Type)

Adjustments (Planetary Type)

Overhaul (Clutch Type)

Overhaul (Planetary Type)

STEERING, MANUAL

TORQUE AMPLIFIER

Clutch Adjustment

Clutch Overhaul

Planetary Unit

TRANSMISSION OVERHAUL

Develon
