Case 580SV, 695SV Tractor Loader Backhoe Service Manual (92772389) (October 2025)

These 580SV / 695SV backhoes usually live in the rough stuff—construction sites, road crews, utility work, farm yards—mud, dust, cold starts, hot days. This service manual walks you through how to trace a problem, check it properly, and verify it’s actually failed before you start throwing parts at it. Say the machine won’t move but the engine runs fine: you’ll follow a sequence to isolate if it’s a transmission control issue, a power coupling problem, or something as simple as a linkage or low fluid, instead of guessing.

Applications & Use Cases

• Track down hydraulic issues by following step‑by‑step tests to bleed, test, and inspect circuits before you blame the pump.
• Chase electrical faults with guided checks so you route your meter leads correctly and don’t miss a bad ground or broken wire.
• Verify driveline problems by aligning the recommended checks on transmission, axles, and power coupling instead of just swapping assemblies.
• Plan big repairs by seeing what has to come off first, so you inspect access points and don’t tear apart more than you need.
• Confirm adjustments—steering, brakes, loader and hoe functions—so everything’s tested and working before the machine goes back to the job.

FAQ

Q: Is this a PDF I can search on my laptop or tablet?

A: Yes, it’s typically a searchable PDF, so you can jump to sections and find systems by keyword.

Q: Can I print just the pages I need for a job?

A: Usually yes; most folks print the relevant procedures, toss them in a plastic sleeve, and keep the full file on a device.

Safety Note

Always support and block raised components before you crawl under or inspect anything that could drop on you.

Case 580SV, 695SV Tractor Loader Backhoe Index:

• Contents
• INTRODUCTION
• Engine – 10
• Power coupling – 19
• Transmission – 21
• Front axle system – 25
• Rear axle system – 27
• Brakes and controls – 33
• Hydraulic systems – 35
• Frames and ballasting – 39
• Steering – 41
• Wheels – 44
• Cab climate control – 50
• Electrical systems – 55
• Front loader and bucket – 82
• Booms, dippers, and buckets – 84
• Platform, cab, bodywork, and decals – 90
• SPECIAL TOOL INDEX
