Case 595SLE, 595LSP Backhoe Loaders Parts Catalog (7-5160+R1_int_USN)

These 595SLE and 595LSP backhoes usually live in mud, rock, and tight jobsite corners, loading trucks and trenching all day, so hardware gets bent, worn, or lost. This parts catalog is what I’d pull up when I need to identify exactly which components belong where, and in what sequence, before ordering anything. Say you’ve got a sloppy front axle or a cracked structural bracket—this book lets you see the full breakdown, match each pin, bushing, and seal, and make sure you’re getting the right revision for your machine.

Applications & Use Cases

• Trace how axle, frame, and undercarriage parts tie together so you don’t miss shims, spacers, or small retainers.
• Cross-check wheel and driveline components when a hub or shaft is damaged and you only have partial numbers.
• Verify support brackets and structural pieces after a collision or weld repair to restore original alignment.
• Compare similar parts between 595SLE and 595LSP variants to confirm correct fitment before ordering.
• Build complete parts lists for a planned teardown, including all seals, bushings, and fasteners that are easy to overlook.

FAQ

Q: Can I use this catalog on a tablet in the field?

A: Yes, it’s practical to run it on a tablet so you can zoom into exploded views right next to the machine.

Q: Is it worth printing pages from this catalog?

A: Many techs print just the relevant assemblies to mark up, carry to the bench, and staple to the parts pick ticket.

Safety Note

Always verify parts visually on the machine and follow the official service and safety procedures when installing anything.
