Case CK15 Crawler Excavators Parts Catalog (8-8632r1)

On a CK15 crawler excavator that spends its life trenching, loading trucks, or working in tight, muddy sites, this parts catalog is what you use to nail down exactly which pieces bolt together on your machine. When you’ve got play in the undercarriage or a leaking swivel joint and need to order parts, this book lets you trace each component in the assembly, confirm the right revision, and avoid guessing at hardware or seals.

Applications & Use Cases

• Cross-check undercarriage components—track rollers, idlers, and frame pieces—so replacements match your specific CK15 build.
• Trace drivetrain and axle unit assemblies to verify which shafts, bearings, and couplings belong together before placing an order.
• Identify small wear items like bushings, shims, and O-rings that are easy to miss when rebuilding support structures or wheel sets.
• Compare variant parts when Case supersedes a component, ensuring the new number still fits your serial range and sub-assembly.
• Plan a job by printing exploded views so you can lay out parts on the bench and confirm everything is on hand before teardown.

FAQ

Q: Can I use this catalog on a tablet in the field?

A: Yes, it’s practical to zoom in on exploded views and part numbers directly on a tablet or laptop next to the machine.

Q: Is it worth printing sections of this catalog?

A: Many techs print the specific pages they need for a job, mark them up with notes, and keep them with the work order for quick reference.

Safety Note

Always lock out, support, and relieve stored energy on the excavator before inspecting or handling any components identified in this catalog.
