Case CX145E SR Crawler Excavator Service Parts Catalogue (92756614) (January 2026)
Out on sites, this CX145E usually lives in mud, rock, and tight spaces around utilities or roadwork, swinging all day in dust and rain. This Service Parts Catalogue helps you plan a job before you crack a single fitting—so you can trace every hose, pin, and seal on paper first, then pull parts once, not three times. Say you’re planning a boom cylinder reseal: you can sit at the bench, match the exploded view to your machine, and know which seal kit, wear rings, and snap rings you’ll need on the shelf before you pull the cylinder.
Applications & Use Cases
- Line up a full parts order before a weekend shutdown, so you don’t stop mid-teardown waiting on one odd-sized bushing.
- Trace hydraulic lines on the diagram, then verify each clamp and bracket on the machine so you route replacements correctly.
- Isolate the exact pivot pin and shim stack during disassembly, matching item numbers so you don’t mix left/right or front/rear hardware.
- Inspect wear items on the machine, then cross-check the catalogue to decide what you’ll replace now versus what can wait.
- Test your parts guy: match suffixes and revisions in the book so you don’t get the “almost right” filter or seal kit.
FAQ
Q: Is this something I can search on a laptop, or is it just a scanned book?
A: It’s typically a proper digital catalogue, so you can search by part number or description instead of flipping pages.
Q: Can I print pages to take out to the machine?
A: Yes, most folks print only the systems they’re working on, then mark them up with notes during teardown and reassembly.
Safety Note
Before you inspect or remove any part you’ve traced in the catalogue, make sure the machine is parked solid, locked out, and all pressure is bled off.
