Case DV23CC Vibratory Roller Service Parts Catalogue (547150235PC) (September 2025)

Out on paving jobs, this DV23CC roller’s usually running hot asphalt, tight spaces, and short shutdown windows. This service parts catalogue helps you plan the job before you ever crack a fitting—so you can trace every hose, bushing, and seal, then order right the first time. Say you’re scheduling a vibration drum leak repair: you can sit down, match the exploded view to your machine, and have every O-ring, bearing, and snap ring on the shelf so you don’t park the roller for half a week waiting on one tiny part.

Applications & Use Cases

• Lay out a full parts list before teardown, so you can check shelves, tag what you’ve got, and order what you don’t.
• Use the exploded diagrams to visually trace hydraulic lines and route replacements exactly like factory, instead of guessing clamp locations.
• During disassembly, match part numbers to the pictures to verify each bushing or spacer, avoiding those “almost the same” wrong suffix orders.
• When you’re rebuilding a subassembly, isolate every wear item from the diagram and pre-buy kits, seals, and hardware so you can work straight through.
• Inspect machine changes over time by comparing what’s on the roller to the catalog notes, which usually flag superseded or alternate parts.

FAQ

Q: Is this something I can search on a laptop, or just a scanned book?

A: It’s generally a searchable PDF, so you can jump by part number or section instead of flipping pages all night.

Q: Can I print just the pages I need to take to the jobsite?

A: Yes, most folks print the relevant assemblies, stick them in a sleeve, and mark them up as they test, strip, and rebuild.

Safety Note

Before you inspect or test any component you’ve identified in the catalog, lock out the machine and bleed off stored hydraulic and drum energy.

Case DV23CC Vibratory Roller Index:

00.000.00 PICTORIAL INDEX – MAIN SECTIONS
00.000.10 PICTORIAL INDEX – ENGINE
00.000.29 PICTORIAL INDEX – HYDROSTATIC TRANSMISSION
00.000.33 PICTORIAL INDEX – BRAKES & CONTROLS
00.000.35 PICTORIAL INDEX – HYDRAULIC SYSTEMS
00.000.39 PICTORIAL INDEX – FRAMES
00.000.41 PICTORIAL INDEX – STEERING
00.000.44 PICTORIAL INDEX – DRUMS
00.000.55 PICTORIAL INDEX – ELECTRICAL SYSTEMS
00.000.64 PICTORIAL INDEX – CHOPPING
00.000.78 PICTORIAL INDEX – SPRAYERS
00.000.90 PICTORIAL INDEX – PLATFORM, CAB, BODYWORK AND DECALS
00.100.03 [01] SERIAL NUMBER PLATE LOCATIONS / INFORMATION
00.100.03 [02] SERIAL NUMBER PLATE LOCATIONS / INFORMATION
00.100.03 [03] SERIAL NUMBER PLATE LOCATIONS / INFORMATION
05.100.01 [01] INITIAL STOCKING LIST ”A” (ISL)
05.100.02 [01] INITIAL STOCKING LIST ”B” (ISL)
05.100.03 [01] FILTERS, DV23
05.100.03 [02] CAPACITIES
10.000.00 PICTORIAL INDEX – ENGINE
10.001.AK [01] ENGINE AND ATTACHING PARTS; (SN Break) Before NFNTT0186
10.001.AK [02] ENGINE MOUNT; (SN Break) Before NFNTT0186
10.202.AB [01] ENGINE, AIR INTAKE
10.216.AI [01] FUEL TANK
10.254.AD [01] EXHAUST SYSTEM W/ MUFFLER; (SN Break) Before NFNTT0186
10.400.AE [01] RADIATOR GRILLE; (SN Break) Before NFNTT0186
29.000.00 PICTORIAL INDEX – HYDROSTATIC TRANSMISSION
29.218.AC [01a] DRIVE, HOSE ASSY.
29.218.AC [01b] DRIVE, HOSE ASSY.
29.218.AC [02a] RETURN, HOSE ASSY.
29.218.AC [02b] RETURN, HOSE ASSY.
29.218.AC [02c] RETURN, HOSE ASSY.
33.000.00 PICTORIAL INDEX – BRAKES & CONTROLS
33.202.AP [01] BRAKE RESERVOIR & LINES, FRONT
33.202.AP [02] BRAKE RESERVOIR & LINES, REAR
33.202.BT [01] BRAKE VALVE ASSEMBLY
35.000.00 PICTORIAL INDEX – HYDRAULIC SYSTEMS
35.104.AA [01] HYDRAULIC PUMP; (SN Break) Before NFNTT0186
35.104.AA [02] HYDRAULIC PUMP; (SN Break) Before NFNTT0186
35.204.BE [01] TRACTION ASSIST
35.300.AB [01] HYDRAULIC OIL COOLER
35.300.AD [01] HYDRAULIC OIL RESERVOIR & FILTER
35.300.AD [03] HYDRAULIC OIL RESERVOIR, TEMPERATURE SENDER, KIT
35.300.AQ [099] HYDRAULIC FLUID RESERVOIR, FLUID TEMPERATURE SENSOR RELOCATION KIT; (SN
Break) Before NKWTX3168
35.903.AD [01] VIBRATION CONTROL VALVE
35.903.AE [01] VIBRATION DAMPER, HOSE
35.903.AE [01a] VIBRATION DAMPER, HOSE
35.903.AE [01b] VIBRATION DAMPER, HOSE

35.995.AC [01] EDGE CUTTER CONTROLS
35.995.AC [02] EDGE CUTTER HYDRAULIC HOSES
39.000.00 PICTORIAL INDEX – FRAMES
39.100.AH [01] FRAME, COVERS
39.100.AN [01] ARTICULATION, SUPPORT JOINT
39.100.AN [02] ARTICULATION JOINT
39.100.AN [05] ARTICULATION JOINT LOCK – OFFSET DRUMS
39.100.AN [06] ARTICULATION JOINT LOCK – IN-LINE DRUMS
39.100.AS [01] FRAME, REAR; (SN Break) Before NFNTT0186
39.100.AY [01] FRAME, FRONT; (SN Break) Before NFNTT0186
39.101.AC [01] LIFT HOOKS
39.500.AP [01] EDGE CUTTER MOUNTING
41.101.AB [01] STEERING WHEEL, AND IGNITION SWITCH; (SN Break) Before NFNTT0186
41.101.AB [01a] STEERING WHEEL, AND IGNITION SWITCH; (SN Break) After NDRT25600
41.216.AN [01] STEERING CYLINDER
41.216.AN [02] STEERING HOSE ASSY
44.510.AE [01] DRUM, MOUNTING; (SN Break) Before NFNTT0170
44.510.AE [02] DRUM HUB, VIBRATION; (SN Break) Before NFNTT0170
44.510.AE [03] LOWER DRUM, SCRAPER
44.510.EA [05] DRUM TILTABLE SCRAPER, LOWER
44.510.EA [06] DRUM SCRAPER TILTABLE UPPER W-SPRINKLER
44.510.EA [22] SCRAPER, UPPER ASSEMBLY W/SPRINKLER
55.000.00 PICTORIAL INDEX – ELECTRICAL SYSTEMS
55.035.AG [01] CONTROL LEVER, RIGHT SIDE; (SN Break) Before NFNTT0186
55.035.AG [03] CONTROL LEVER, LEFT SIDE
55.100.DO [01] FUSE BOX, ENGINE; (SN Break) Before NFNTT0186
55.202.AE [01] STARTER & ALTERNATOR
55.302.AI [01] BATTERY CUT-OUT
55.302.AI [01] BATTERY CUT-OUT
55.302.AK [01] BATTERY – TRAY & CABLES; (SN Break) Before NFNTT0186
55.302.AK [02] CHASSIS, WIRE HARNESS
55.404.AC [01] WORK LIGHT & ROTATING BEACON
55.404.AC [02] ROTATING BEACON
55.404.AC [02a] ROTATING BEACON
55.404.AC [02a] ROTATING BEACON ROPS W-CANOPY
55.404.AC [04] WORK LIGHT & ROTATING BEACON
55.404.AX [01] FRONT & REAR LIGHT
55.404.AX [02] ROAD WORK LIGHTS
55.404.BS [01] WORK LIGHT & WIRING, ROPS
55.408.BG [01] BACKUP ALARM
55.512.BQ ASPHALT TEMPERATURE SENSOR
55.512.BQ [01] INSTRUMENT PANEL; (SN Break) Before NFNTT0186
55.512.BQ [02] FUSE HOLDER; (SN Break) Before NFNTT0186
55.952.AC ACE INSTALLATION
78.000.00 PICTORIAL INDEX – SPRAYERS
78.110.AA [01] SPRINKLING SYSTEM
78.110.AH [01] WATER TANK; (SN Break) Before NFNTT0186
88.100.010 SERVICE, TOOLS
90.000.00 PICTORIAL INDEX – CAB CLIMATE CONTROL
TABLE OF CONTENTS
90.100.BJ [01] ENGINE HOOD
90.108.AB [01] MODEL DECALS; (SN Break) Before NHNTT0306
90.108.AC [01] WARNING DECAL
90.108.AC [02] DECALS; (SN Break) Before NHNTT0306
90.110.AP [01] PLATFORM OPERATORS; (SN Break) Before NFNTT0186
90.110.AP [02] OPERATOR PLATFORM PARTS
90.114.AQ [01] FOLDING ROPS
90.114.AQ [02] FOLDING ROPS – FOPS
90.120.AA [01] ARMREST
90.120.AD OPERATOR SEAT; (SN Break) Before NJNTT0582
90.150.BG [01] CANOPY, WEATHER

CNH
