Case DV23E, DV23CE, DV26E, DV26CE Vibratory Roller Operators Manual

These DV23E / DV23CE / DV26E / DV26CE rollers spend their lives on paving jobs, tight parking lots, and patch work where you’re right up against curbs, structures, and fresh mat. This operators manual is what I lean on to show a new operator how to run the controls correctly, warm the machine up, and shut it down without beating up the engine, hydraulic system, or drums. If, for example, vibration won’t engage after a move, this is the guide I use to walk them through the basic checks and proper startup sequence before we assume something is broken.

Applications & Use Cases

• Train new operators on what each switch does so they don’t abuse the vibration or drive system.
• Set up proper startup/shutdown routines to avoid hard stops, false alarms, and premature wear.
• Walk through daily inspections so leaks, loose scrapers, or drum issues are caught before a shift.
• Verify safe operating habits on slopes, near edges, and around other paving equipment.
• Confirm correct use of vibration and travel modes to prevent over-compaction or drum flat-spotting.

FAQ

Q: Can I keep this manual on a tablet in the cab?

A: Yes, it’s practical to use digitally; you can zoom diagrams and search terms while you’re on the job.

Q: Is it worth printing certain pages?

A: I’d print the startup, shutdown, and daily check pages, laminate them, and keep them with the machine.

Safety Note

Always follow the manual’s startup, shutdown, and inspection steps before moving the roller, especially around people and traffic.
