On a DV23E roller that spends its life compacting asphalt and base in hot, dusty jobsites, this Service Parts Catalogue is what I’d pull out any time I’m matching up components. It lets me see how every piece of the machine is laid out and which part numbers belong together. For example, if the vibration stops on one drum and I find a damaged bearing housing, I use this book to trace the whole assembly, confirm the correct housing, seals, and hardware before I order anything.
Applications & Use Cases
FAQ
Q: Can I use this on a tablet in the field?
A: Yes, it’s well-suited for a tablet or laptop so you can zoom in on exploded views right next to the machine.
Q: Is it still worth printing pages?
A: Many techs print the specific assemblies they’re working on, mark them up during teardown, and file them with the work order.
Safety Note
Always lock out, block, and support the roller per the main service manual before inspecting or matching parts on the machine.
00.000.00 PICTORIAL INDEX – MAIN SECTIONS
05.000.01 SERIAL NUMBER PLATE LOCATIONS / INFORMATION
05.000.02 SERIAL NUMBER PLATE LOCATIONS / INFORMATION
05.000.03 SERIAL NUMBER PLATE LOCATIONS / INFORMATION
05.100.01 INITIAL STOCKING LIST (LIST A)
05.100.02 INITIAL STOCKING LIST (LIST B)
05.100.03 FILTERS & CAPACITIES
10.000.000 SECTION INDEX – ENGINE
10.001.AL [001] ENGINE MOUNT
10.001.AL [002] ENGINE MOUNT
10.102.AW [001] ENGINE OIL, DRAIN LINE
10.202.AB [001] AIR INTAKE, AIR CLEANER
10.216.AI [001] FUEL TANK & ASSOCIATED PARTS
10.400.BE [001] RADIATOR & RELATED PARTS
10.501.AD [001] EXHAUST SYSTEM W/ MUFFLER
29.218.AH [001] DRUM, DRIVE, MOTOR, MOUNTING
33.000.000 SECTION INDEX – BRAKES & CONTROLS
33.110.AT [001] BRAKE CONTROL VALVE, ASSY
33.110.BS [001] HYDRAULIC HOSE, BRAKE
35.000.000 SECTION INDEX – HYDRAULIC SYSTEMS
35.106.AD [001] HYDRAULIC PUMP – W/ DIFF LOCK
35.106.AD [002] HYDRAULIC PUMP – W/O DIFF LOCK; (Var) 423405018
35.300.AB [001] HYDRAULIC OIL COOLER
35.300.AD [001] HYDRAULIC HOSE, PUMP
35.300.AQ [001] HYDRAULIC FLUID RESERVOIR, MOUNTING
35.300.AQ [011] HYDRAULIC FLUID RESERVOIR, ASSY; (SN Break) After NKWTU3095
35.995.AA [001] DRUM, MOTOR, VIBRATION
35.995.AB [010] HYDRAULIC LINE, FRONT, DRUM
35.995.AB [020] HYDRAULIC LINE, REAR, DRUM
35.995.AD [010] VIBRATION CONTROL VALVE, ASSY
39.000.000 SECTION INDEX – FRAMES AND BALLASTING
39.100.AN [001] ARTICULATION JOINT
39.100.AN [002] ARTICULATION JOINT
39.100.AN [003] ARTICULATION JOINT
39.100.AN [004] FRAME, REAR, STEERING CYLINDER, MOUNTING
39.100.AS [001] FRAME, REAR, DRUM
39.100.AY [001] FRAME, FRONT
39.100.AY [002] FRAME, FRONT
39.500.AQ [001] WATER TANK, FILLER CAP – LOCKABLE; (Var) 449501007
39.500.AQ [010] WATER TANK, MOUNTING
39.500.AQ [020] DRUM, SPRINKLING SYSTEM
41.000.000 SECTION INDEX – STEERING
41.101.AB [001] STEERING WHEEL
41.200.AO [001] HYDRAULIC HOSE, STEERING
41.200.CJ [001] STEERING VALVE, MOUNTING
41.216.AT [001] STEERING CYLINDER, ASSY
44.000.000 SECTION INDEX – WHEELS
44.160.AA [001] DRUM
44.160.AA [021] UPPER, SCRAPER, TILTABLE, DRUM; (Var) 423473009; (SN Break) After NM3001671
TABLE OF CONTENTS
44.160.AB [001] FRAME, DRUM, MOUNTING
44.160.AC [001] DRUM, ECCENTRIC
44.160.AD [020] LOWER, SCRAPER, TILTABLE, DRUM; (Var) 423473009
55.000.000 SECTION INDEX – ELECTRICAL SYSTEMS
55.000.AA [001] CABLE, EST
55.100.DO [001] RELAY, PANEL, ENGINE
55.100.DO [002] FUSE, PANEL, ASSY
55.100.DP [001] FUSE, PANEL, MOUNTING, WIRE HARNESS
55.100.DP [010] WIRE HARNESS, ASSY
55.201.AE [001] ENGINE, STARTER
55.201.AH [001] IGNITION SWITCH
55.301.AA [001] ALTERNATOR
55.302.AG [001] BATTERY TRAY
55.404.AC [001] BEACON, ROPS; (Var) 786059034
55.404.CL [001] WORK LIGHT & WIRING, TURN SIGNAL; (Var) 423436011
55.405.CF [001] INSTRUMENT PANEL
55.405.CF [002] HAZARD LIGHT SWITCH, TURN SIGNAL; (Var) 423436011
55.408.BE [001] HORN, MOUNTING
55.408.BE [002] BACKUP ALARM, MOUNTING; (Var) 784273013
55.408.CA [001] DASHBOARD, PANEL
55.408.CM [001] SWITCH, OPERATOR PLATFORM
55.512.BU [001] SWITCH ASSY, EMERGENCY STOP
55.512.CL [001] JOYSTICK, LEFT SIDE; (Var) 423345016
55.512.CL [002] JOYSTICK, RIGHT SIDE; (Var) 423345016
55.640.AG [001] CONTROLLER, MACHINE
55.952.AC [001] SPRINKLING SYSTEM, SWITCH ASSY
90.000.000 SECTION INDEX – PLATFORM, CAB, BODYWORK & DECALS
90.100.AU [001] ENGINE HOOD
90.110.AH [001] INSTRUMENT PANEL, COVER
90.110.AP [001] PLATFORM, OPERATOR
90.110.AP [002] STAND, OPERATOR
90.110.CA [002] 3” SEAT BELT; (Var) 423460022; (SN Break) After NKWTU3078
90.114.AQ [001] ROPS, FOLDABLE; (Var) 734125000
90.118.BX [001] FRAME, REAR, STEP
90.120.AA [001] ARMREST; (Var) 423343012
90.120.AD [001] OPERATOR SEAT, W/O HEATER; (Var) 543100001
