Case L113, L114, L115, L116, L117, L118, L119 Farm Loader Service Manual

These Case L113–L119 farm loaders spend their lives moving manure, feed, gravel, and silage around the yard and in the field, so they see a lot of abuse in tight spaces. This service manual is what I’d grab when a loader starts lifting slow on one side or the boom won’t stay up and I need to trace whether it’s a cylinder issue, a valve problem, or a linkage misadjustment. It walks you through a logical way to inspect, test, and reassemble so you’re not just throwing parts at it.

Applications & Use Cases

• Diagnose weak or uneven lift by following step-by-step checks on hydraulics and linkage to isolate the fault.
• Strip and rebuild loader subassemblies so pins, bushings, and cylinders go back in correctly aligned.
• Verify control function after cable, lever, or valve work so the loader responds cleanly and predictably.
• Adjust bucket and boom geometry after wear or welding repairs to restore proper crowd and dump angles.
• Plan safe removal and refit of the loader from the tractor without twisting frames or hoses.

FAQ

Q: Can I use this manual on a tablet in the shop?

A: Yes, it’s practical to keep it open on a tablet; you can zoom diagrams and keep your hands free while working.

Q: Is it worth printing parts of this manual?

A: Many techs print the procedures and diagrams for the job they’re on, then mark notes and oil spots without risking their device.

Safety Note

Always depressurize hydraulics, support raised components securely, and lock out the tractor before loosening any loader hardware or hoses.

Case L113, L114, L115, L116, L117, L118, L119 Farm Loader Index:

TABLE OF CONTENTS
1. Introduction
2. Description and definitions
3. Safety instructions
4. Installation – subframe
5. Installation – Front Loaders
6. Installation – Control system
7. Service – general
8. Service – subframe
9. Service – Front loaders
10. Service – Loader hydraulics
11. Service – Cylinders
12. Service – control system
13. Tightening torques
14. Storage
15. Troubleshooting
16. Specifications
17. Wiring diagram
