Format: PDF (Printable Document)
File Language: English
File Pages: 720
File Size: 75.28 MB (Speed Download Link)
Brand: Case
Model: Optum 270CVX, 300CVX AFS Connect CVX Drive Tractor
Part No: 91802310
Date: April 2023
Type of Document: Operator Manual
$ 45
These Optum AFS Connect tractors usually live on big tillage, planting, and heavy transport jobs, often running long days in dusty, changing conditions. This operator manual is what I keep handy to run the CVX drive and AFS controls the right way, so we don’t cook transmissions, starve hydraulics, or chase electrical “faults” that are really just wrong settings. If an operator calls saying the tractor won’t move after a headland turn, this is the book I use to walk them through the start-up sequence, check the right interlocks, and get them rolling without a service call.
Applications & Use Cases
FAQ
Q: Can I keep this manual on a tablet in the cab?
A: Yes, a PDF on a tablet or laptop works well; you can zoom diagrams and use search to find controls and procedures fast.
Q: Is it worth printing pages from this manual?
A: I’d print the startup/shutdown, daily checks, and key control layouts and keep them in a plastic sleeve right in the cab.
Safety Note
Always follow the manual’s startup, lockout, and parking instructions before you inspect, adjust, or work around this tractor.
