Case Precision Air 2355 Air Cart Service Manual (92080200) (July 2023)

Out in small grains or canola, this air cart spends its life in dust, fertilizer, and long days chasing seeding windows. This service manual helps you trace hydraulic, brake, and metering problems step by step, so you can isolate what’s actually wrong before you start throwing parts at it. Say your fan speed keeps hunting: with this, you’ll follow a set sequence—check power and grounds, verify hydraulic flow, inspect sensors—so you find the weak link instead of guessing.

Applications & Use Cases

• Track down uneven seed or fertilizer rates by tracing the system from the tank, through meters and drives, to the outlets, and testing each stage.
• Chase a hydraulic issue by isolating circuits, checking pressures with a gauge you already own, and verifying valves before you replace anything.
• Sort out brake or axle problems by following alignment and inspection steps so you know if it’s adjustment, wear, or a cracked component.
• Use the wiring and hose routing info to route and secure replacements cleanly, so you don’t rub through a line halfway through the season.
• Plan winter work: inspect known wear points, test key functions, and bleed or service components so the cart’s ready when the drill hooks up.

FAQ

Q: Is this a PDF I can search on my laptop or phone?

A: Yes, it’s typically a searchable PDF, so you can jump to sections by keyword instead of scrolling forever.

Q: Can I print just the pages I need for the shop?

A: You usually can; most folks print the relevant procedures and wiring or hydraulic diagrams so they can get them greasy without wrecking the whole manual.

Safety Note

Always depressurize hydraulics and air systems and chock the cart before you crawl under it or crack any lines.

Case Precision Air 2355 Air Cart Index:

• Contents
• INTRODUCTION
• Front axle system – 25
• Rear axle system – 27
• Brakes and controls – 33
• Hydraulic systems – 35
• Frames and ballasting – 39
• Wheels – 44
• Electrical systems – 55
• Metering system – 61
• Seeding – 77
• Platform, cab, bodywork, and decals – 90
• SPECIAL TOOL INDEX
