Case Puma 200 Tier 4B Final Tractor Service Manual (51666845) (March 2021)

Out in the field, this Puma 200’s usually hauling grain carts, running tillage, or on a baler all day, dust blowing, hydraulics hot, and electronics getting rattled. This service manual walks you through how to trace faults step by step so you don’t just throw parts at it. Say the tractor drops power under load: you’d follow the guide to check fuel supply, verify boost, test sensors, and isolate whether it’s a fuel issue, turbo control, or an electrical glitch before you order anything.

Applications & Use Cases

• Track down warning lights by following the diagnostic tree so you can isolate if it’s a real failure or just a bad connector.
• Chase hydraulic problems: you’ll bleed, test, and inspect circuits in order, instead of guessing at pumps and valves.
• Sort out transmission complaints by checking linkages, pressures, and calibrations in a set sequence that usually prevents repeat tear-downs.
• Verify sensor and wiring issues with guided trace steps so you route your checks logically and don’t miss a hidden break.
• Align and set up components after repairs—clutch, 4WD, steering—so the tractor runs straight and doesn’t eat parts early.

FAQ

Q: Is this a searchable PDF I can keep on a laptop or tablet in the shop?

A: Yes, it’s typically a PDF you can search by keyword, which makes finding the right test or wiring trace a lot faster.

Q: Can I print just the sections I need to take out to the field?

A: You usually can; most folks print the relevant procedures and diagrams so they don’t risk a tablet in the mud.

Safety Note

Always depressurize hydraulics and let hot components cool before you crack a line or start pulling parts.

Case Puma 200 Tier 4B Final Tractor Index:

• Link Product / Engine
• Contents
• INTRODUCTION
• Engine – 10
• Clutch – 18
• Transmission – 21
• Four-Wheel Drive (4WD) system – 23
• Front axle system – 25
• Rear axle system – 27
• Power Take-Off (PTO) – 31
• Brakes and controls – 33
• Hydraulic systems – 35
• Hitches, drawbars, and implement couplings – 37
• Frames and ballasting – 39
• Steering – 41
• Wheels – 44
• Cab climate control – 50
• Electrical systems – 55
• Platform, cab, bodywork, and decals – 90
