Case Puma 220 CVX Stage 5 Tractor Service Manual (91798748)

Case Puma 220 CVX Stage 5 Tractor Service Manual (91798748) (May 2022)

Out in the field, this Puma 220 CVX is usually pulling heavy tillage gear, running carts, or on the road with decent loads, so it’s working hard in dust, mud, and cold starts. This service manual helps you trace and isolate faults instead of just guessing, so you can check, verify, then fix it once. Say the tractor won’t move right but the engine sounds fine—this book walks you through what to test in the transmission and 4WD system before you start throwing parts at it.

Applications & Use Cases

• Track down hydraulic issues by tracing circuits, checking pressures with the right ports, and verifying if it’s a valve, pump, or just a misrouted line.
• Chase electrical gremlins by following proper diagrams so you can isolate a bad sensor, broken wire, or dodgy ground instead of swapping modules.
• Inspect and align driveline components so when you’ve got it split, you test and re-check clearances instead of reopening it a week later.
• Bleed and route fuel and DEF lines correctly, avoiding air locks and weird derates that usually waste half a day to sort out.
• Plan bigger jobs—you’ll see what actually has to come off first so you don’t backtrack and redo half the teardown.

FAQ

Q: Is this a PDF I can search on a laptop or tablet?

A: Yes, it’s typically a searchable PDF, so you can jump straight to sections and keywords instead of scrolling forever.

Q: Can I print just the pages I need for the shop?

A: You usually can; most folks print the key procedures, mark them up, and keep the clean master file on their computer.

Safety Note

Always verify the machine is properly supported and all pressures are relieved before you inspect, loosen, or remove any hydraulic or driveline components.

Case Puma 220 CVX Stage 5 Tractor Index:

• Contents
• INTRODUCTION
• Engine – 10
• Clutch – 18
• Transmission – 21
• Four-Wheel Drive (4WD) system – 23
• Front axle system – 25
• Rear axle system – 27
• Power Take-Off (PTO) – 31
• Brakes and controls – 33
• Hydraulic systems – 35
• Hitches, drawbars, and implement couplings – 37
• Frames and ballasting – 39
• Steering – 41
• Wheels – 44
• Cab climate control – 50
• Electrical systems – 55
• Platform, cab, bodywork, and decals – 90
• SPECIAL TOOL INDEX
