Case Puma 240 CVX Tier 4B Final Tractor Service Manual (51666845)

Case Puma 240 CVX Tier 4B Final Tractor Service Manual (51666845) (March 2021)

Out in the field this Puma 240 CVX is usually on heavy tillage, hauling big grain carts, or running road work—dust, mud, cold starts, the whole mix. This service manual’s there to help you trace faults logically, check systems in order, and verify what’s actually failed before you throw parts at it. Say the tractor won’t pull right under load: instead of guessing at the transmission, you’d isolate whether it’s engine management, CVX control, or a hydraulic issue by following the test sequence.

Applications & Use Cases

• Track down a no-start by following the electrical and fuel checks step by step, so you test each circuit before blaming the ECU.
• Chase hydraulic problems by routing through the pressure, flow, and control valve checks, helping you bleed and inspect the system properly.
• Sort transmission or CVX drive issues by using the manual’s diagnostic order to align sensor checks, calibration routines, and road tests.
• Verify service work after a repair—use the listed inspections to check clearances, linkages, and settings so you don’t have to tear it back down.
• Plan bigger jobs like clutch or engine work by tracing what must come off first, so you don’t strip half the tractor for no reason.

FAQ

Q: Is this a PDF I can search on my laptop or tablet?

A: Yes, it’s typically a searchable PDF, so you can jump to sections and fault codes instead of flipping pages for an hour.

Q: Can I print just the pages I need to take to the field?

A: You usually can; most folks print the key procedures, throw them in a plastic sleeve, and keep the full manual on a device in the shop.

Safety Note

Always isolate the machine—engine off, key out, hydraulics de-pressurized—before you get your hands near any moving or suspended components.

Case Puma 240 CVX Tier 4B Final Tractor Index:

• Link Product / Engine
• Contents
• INTRODUCTION
• Engine – 10
• Clutch – 18
• Transmission – 21
• Four-Wheel Drive (4WD) system – 23
• Front axle system – 25
• Rear axle system – 27
• Power Take-Off (PTO) – 31
• Brakes and controls – 33
• Hydraulic systems – 35
• Hitches, drawbars, and implement couplings – 37
• Frames and ballasting – 39
• Steering – 41
• Wheels – 44
• Cab climate control – 50
• Electrical systems – 55
• Platform, cab, bodywork, and decals – 90
