Case TX130-40, TX130-43, TX130-45 TX140-43, TX140-45 TX170-45 Telehandlers Parts Catalog (6-95120_int_USN)

These Case TX telehandlers spend their lives loading, stacking, and placing materials on construction sites and in yards, so knowing exactly what’s on the boom, carriage, and frame matters when something gets bent or worn. This parts catalog is what I use to visually break down assemblies, match what I see on the machine to the exploded views, and then pull the correct part numbers. If a carriage is damaged or a main-frame pivot bushing is sloppy, I use this book to trace every pin, shim, seal, and bracket so nothing gets missed on the order.

Applications & Use Cases

• Cross-check TX130, TX140, and TX170 variants to verify which carriage or frame components actually fit your specific unit.
• Use the exploded views to trace sub-assemblies and confirm all related hardware when replacing a bent carriage or damaged boom attachment points.
• Identify small wear items—bushings, spacers, seals, snap rings—that are easy to overlook when building a parts list.
• Compare different revision levels of brackets or linkages so you don’t mix old and updated parts in the same assembly.
• Print key pages to take to the machine and visually match components before placing a large order.

FAQ

Q: Can I use this catalog on a tablet in the field?

A: Yes, it’s practical to zoom in on the exploded views and part callouts while you’re standing at the machine.

Q: Is this useful if I only need one small pin or seal?

A: Definitely; you can isolate the exact location in the assembly and avoid guessing from generic hardware bins.

Safety Note

Always confirm parts against the machine’s ID plate and follow the official safety procedures before inspecting or disassembling any components.
