CNH REAR RIPPER Installation Instructions (90386697)

Out in the dirt, this rear ripper’s working in hard-packed soil, roots, maybe old gravel drives—stuff that’ll shake anything that’s not mounted right. This installation manual walks you through how to hang the CNH rear ripper on the machine so it’s aligned, secure, and actually tracks straight behind you. Say you’ve just bought a used ripper kit off an auction; with this, you can trace the mounting points, route the hoses where they won’t get pinched, and verify the frame’s square before you ever drop the shanks in the ground.

Applications & Use Cases

• Install a new or used ripper kit by following the step order, so you don’t have to guess which bracket or pin goes on first.
• Check an existing install when something looks off; you can inspect each mount and test fit to isolate where it was done wrong.
• Route and secure hydraulics the way CNH intended, so hoses don’t rub, kink, or get ripped off when you curl or raise the implement.
• Align the ripper to the tractor frame, then verify clearances so it won’t hit tires, drawbar gear, or PTO shields under load.
• Bleed and test hydraulic functions after hookup, making sure the ripper raises, lowers, and floats like it should.

FAQ

Q: Is this a PDF I can search on my laptop or phone?

A: It’s typically a PDF, so you can search by keyword—handy when you’re trying to find a specific bracket or hose layout.

Q: Can I print just a few pages to take to the shop?

A: Yes, most folks print the key install and torque pages so they can get them greasy without worrying about the whole manual.

Safety Note

Always support the implement with proper stands or a hoist and relieve hydraulic pressure before you get under or behind the ripper during installation.

CNH REAR RIPPER Index:

1 SAFETY INFORMATION
Basic instructions – Important notice regarding equipment servicing. . . . . . . . . . . . . . . . . . . . . . . 1-1
2 KIT CONTENT
Kit overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
3 PRE-ASSEMBLY
PREPARING FOR ASSEMBLY
Machine preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
4 ASSEMBLY
Moldboard control
Ripper assembly – Assemble . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Ripper assembly – Install . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

CNH

90386695 – REAR RIPPER
CASE CONSTRUCTION
856C Grader 856C TIER4B New Livery
[FNH856C0NHHF01012 – ]
856C AWD Grader 856C TIER4B
ALL WHEEL DRIVE New Livery
[FNH856CANGHF01003 – ]
856C AWD STAGE V Grader 856C AWD
Stage V [FNH856CANKHF01192 – ]
856C AWD STAGE V GRADER
ELECTRO HYDRAULIC CONTROLS
[FNH856CANNHF01489 – ]
856C STAGE V Grader 856C Stage V
[FNH856C0NLHF01312 – ]
856C STAGE V GRADER
ELECTRO HYDRAULIC CONTROLS
[FNH856C0NNHF01492 – ]
856D Electro-Hydraulic Controls, Stage V
[FNH856D0NPHF01689 – ]
856D Mechanical Controls, Stage V
[FNH856D0NRHF01714 – ]
856D Electro-Hydraulic Controls, Stage V –
ZF EC4 Transmission Control Unit
856D Mechanical Controls, Stage V
– ZF EC4 Transmission Control Unit
[FNH856D0NZHF01814 – ]
856D AWD Electro-Hydraulic Controls,
Stage V [FNH856DANPHF01629 – ]
856D AWD Mechanical Controls, Stage V
[FNH856DANPHF01682 – ]
856D AWD Electro-Hydraulic Controls,
Stage V – ZF EC4 Transmission Control
Unit [FNH856DANZHF01778 – ]
856D AWD Mechanical Controls, Stage V –
ZF EC4 Transmission Control Unit
