Format: PDF (Printable Document)
File Language: English
File Pages: 177
File Size: 12.99 MB (Speed Download Link)
Brand: Cubex
Model: QXR 1320 10258 Surface Drill
Type of Document: Operators Manual
$ 45
Out on a bench or quarry face, this Cubex surface drill is there to put straight, clean holes into hard rock while sitting on uneven, chewed‑up ground. This operators manual is what I’d keep handy to understand exactly how the controls should respond under load, what “normal” sounds and movements are, and how to treat the drill so it doesn’t beat itself to death. If, for example, the feed feels jumpy when you collar the hole or the rotation is stalling in a tight pattern, I’d use this manual to verify proper operating steps before assuming there’s a hydraulic or mechanical failure.
Applications & Use Cases
FAQ
Q: Can I keep this manual on a tablet in the cab?
A: Yes, as long as you can zoom and search easily; just protect the device from dust and vibration.
Q: Is it worth printing certain pages?
A: I’d print the control layout and daily checks and laminate them for quick reference on the jobsite.
Safety Note
Always follow the manual’s procedures and stay clear of the mast, rotation, and high‑pressure lines while the drill is energized.
