Description

Daewoo DB58, DB58S, DB58, TDB58TI, DB58TIS Diesel Engine Operation and Maintenance Manual

Daewoo DB58, DB58S, DB58, TDB58TI, DB58TIS Diesel Engine Index:

CONTENTS
1. GENERAL INFORMATION
1.1 Engine specifications 1
1.2. Engine power 2
1.3. Performance curve 3
1.4. Engine assembly 7
1.5. Safety regulations 13
2. TECHNICAL INFORMATION
2.1. Engine model and serial number 17
2.2. Engine type 18
2.3. Engine timing 18
2.4. Valves 18
2.5. Lubrication system 18
2.6. Air cleaner 21
2.7. Fuel system 22
2.8. Cooling system 25
2.9. V-belt tension check and adjust 28
2.10. Valve clearance and adjustment 29
2.11. Cylinder compression pressure 30
2.12. Injection nozzle 31
2.13. Battery 31
2.14. Starting motor 31
2.15. Diagnosis and remedy 32
3. MAINTENANCE
3.1. Engine Disassembly 42
3.2. Engine Inspection 63
3.3. Reassembly 88
3.4. Electrical Equipments 107
4. Commissioning and Operation
4.1. Preparation 114
4.2. Starting and operation 115
4.3. Inspections after starting 117
4.4. Operation in winter time 117
4.5. Maintenance and care 119
4.6. Cooling system 121
4.7. Valve clearance and adjustment 122
4.8. Injection timing 124
4.9. Tightening the cylinder head bolts 127
4.10. Cylinder compression pressure 128
4.11. Injection nozzle 128

4.12. Fuel injection pump 129
4.13. Feed pump strainer 129
4.14. Separator 129
4.15. Air bleeding 130
4.16. Belts 130
5. Maintenance of Major Components
5.1. Lubrication system 133
5.2. Cooling system 137
5.3. Fuel system 142
5.4. Turbocharger 172
5.5. Air Intake System 180
6. Special Tool List 183
● Appendix 184
