Description
Fendt 14055 PRO DB Former Rotary Rake Operator’s Manual
Fendt 14055 PRO DB Former Rotary Rake Index:
Contents
Introduction
1.1
Warranty and liability
1.2
Conventions
1.2.1
Illustrations
1.2.2 Pictograms used
1.2.3 Text symbols
1.2.4 Abbreviations
1.3
Other applicable documentation
1.4
Storage of documentation
1.5
Applicability of the Operator’s Manual
1.6
Sign plate and serial number
1.7
EIJ Declaration of Conformity
Safety
2
2.1
Intended use
2.2
Reasonably foreseeable misuse
2.3
User qualifications
2.4
Warning notices
2.4.1 Warning notices in the Operator’s Manual
2.4.2 Warning notices on the machine
2.5 Safety instructions
Operating and maintenance personnel
Protective work wear
Personal protective equipment
Preparing the machine for use
Coupling/uncoupling the machine to/from the tractor
Machine operation
Driving on public roads and lanesMaintenance work
Working with hydraulics
Work in the vicinity of high-voltage power lines
Unauthorized modifications or alterations
What to do in an emergency
Fire prevention
Machine description
.1 Product features
.2 Machine positions
3.2.1 Transport position
3.2.2 Working position
3.2.3 Headland position
3.2.4 Parking position
Notices on the machine
Machine components
Position of the machine sensors
ISOBUS control system
4.1 Display layout
42 General buttons
4.3 Menus
Menu structure
“Main menu”
“Transport” menu
“Lifting/Lowering” menu
“Working Height” menu
“Working Width” menu
“On-Board Computer” menu
“User Setup” menu
“Manual Transport Operation” menu
“Manual Operation” menu
“Headland position” menu
“Calibrations” menu
“Diagnostics” menu
“Factory Settings” menu
4.4 Description of the joystick
4.5 Error messages
5 Technical data
5.1 Machine data
5.2 Tires
5.3 Noise information
5.4 Axle loads, gross weight and minimum ballast required
6
Initial start-up
6.1 Assembling the machine
62 Adjusting the transmission shaft
7 Using the machine
7.1 Attachment to the tractor
Start-up
Couplinb the machine
Fitting the transmission shaft
Connect the hydraulics
Connect the lighting
Connecting the ISOBIJS
Connect the air pressure brake
Releasing the parking brake
7.2 Road travel
7.3 Driving the machine on field tracks
7.4 Switching the machine to working position
7.5 Using the machine
7.5.1 Turning at the end of the field
T6 Switching the machine to transport position
07.2019
FEL16881704 EN03
