Description

Fendt 260 FP, 260 FPS Slicer Operator’s Manual (FEL1719640401)

Fendt 260 FP, 260 FPS Slicer Index:

Contents
Introduction
Warranty and liability
Conventions
I I Illustrations
I , 2 Pictograms used
I , 2 Text symbols
I , Abbreviations
Other applicable documentation
Storage Of documentation
Applicability Of the Operator’S Manual
Sign plate and serial nurnber
EU Declaration Of Conformity
Safety
m is use
user qualifications
Warning notices
Waming notices in the Operator’s Manual
2,42 Waming notices on the machine
Safety instructions
Operating and maintenance personnel
Protective work wear
Personal protective equipment
Preparing the machine for use
Coupling/uncoupling the machine to/from the tractor
Machine operation
Driving on public roads and lanes
%intenance work
Working with hydraulics
Unauthorized modifications or alterations
What to do in an emergency
Fire prevention
3 Machine description
Product features
32 Notices on tho machine
Machine components
4
Technical data
Machine data
42 Noise information
Axle loads, gross weight and minimum ballast required
5 Initial start-up
Assembling the machine
Adjusting the transmission shaft

6
Using the machine
6. I Attachment to the tractor
6.1.1 Start-up
6.1.2 Couple the machine
6.1.3 Fitting the transmisson shaft
6.1.4 Connect the SLICER 260 FPS hydraulics
6.2 Road travel
6.3 Switching the machine to working position
6.4 using the machine
6.4.1 Tuming at the end 01 the field
6.5 Switching the machine to transport position
6.6 Machine storage
6.7 Settings
6.7.1 Adjusting cutting height
6.7.2 Adjusting the SLICER 260 FPS side shift
6.7.3 Adjusting the oscillating linkage distributor
Special equipment
7.1 Spring relief
7.1.1 Instructions for attaching to the tractor
7.1.2 Instructions for parking the machine
7.2 Swath guiding device
7.2.1 Adjusting the swath guiding device
7.22 Instructions on rectifying faults
7.3 driveGUARD
7.3.1 Instructions on rectifying faults
7.4 Lamp holder
7.5 Other special equipment
8 Rectifying faults
8.1 After hitting an obstacle
9 Maintenance
Maintenance intervals
Accessing the maintenance points
Cleaning
Tightening torques for nuts and bolts
Decals
Transmission shaft maintenance
Servicing the hydraulics
Gearbox maintenance
9.8.1 GT-30 gearbox
9.8.2 Input gearbox and cutter bar
9.9 Cutter blade maintenance
Checking cutter blades
Checking the cutter-blade bolt
Replacing cutter blades and/or cutter-blade bolts
