Fendt 270P Slicer Operator’s Manual (FEL1390620401)

Fendt 270P Slicer Index:

1
2
Introduction
Safety
Intended use
Reasonably foreseeable misuse
Warranty and liab•lity
user qualifications
Warnings and symbols
Warning notices on the machine
Safety instructions
2, , 1 General safety instructions
2, 72 Special safety instructions
3
Machine description
3, 1 Product features
32 Notices on the machine
33 Special equiprnent
Machine components
4 Specifications
4, 1 Machine data
42 Noise information
Axle loads, gross weight and minimum ballast required
5 Before initial operation
Assembling the machine
52 Adjusting the PTO shaft
6 Attachment to the tractor
62
Initial operation
Coupling the machine
Connecting the PTO shaft to the tractor
Connect hydraulics
Pull cable
7
Transport position and working position
7.1 Switching the machine to transport position
7.2 Switching the machine to working position
8 Using the machine
9 Settings
9. I Adjusting cutting height
9.2 Adjusting the spring relief
9.3 Adjusting the lowering speed
9.4 Adjusting the swath guiding assembly
9.5 Adjusting the V-belt tension
IO Optional functions
10.1 Greater cutting height using anti-twear skids
10.2 Greater cutting height usng contact wheels
11 Machine storage

12 Rectifying faults
12. I If the machine runs an obstacle
12.2 Adjusting the impact guard
12.3 Replacing the
I preparatory work
12 , 3.2 Mower disc without feed drum
12 , 3.3 Mower disc With feed drum
12,3.4 Checks after replacing a element
13 Servicing
Maintenance intervals
Accessing the maintenance points
Cleaning
Tightening torques for nuts and bolts
Adhesive notices on the machine
PTO shaft
Hydraulic system
Gearbox
13,8.1 Entry gearbox and cutter bar
13.9 Cutter blades
13,9.1 Checking the cutter blades
13,9.2 Checking the cutter-blade bolt
13,9.3 Replacing the cutter blades and./or cutter-blade bolt
13,9.4 Optional for retrofitted quick-change blade system
13.10 Check the protective covers
13.11 Lubrication instruction
14 Index
