Fendt 3080 TL Slicer Operator’s Manual (FEL1374550401)
Fendt 3080 TL Slicer Index:
2 Safety
Intended use
Reasonably foreseeable misuse
Warranty and liability
user qualifications
Warnings and symbols
Warning notices on the machine
Safety instructions
2.7.1 General safety instructions
2,72 Special safety instructions
3 Machine description
3. I Product features
3.2 Notices on the machine
3.3 Special equipment
3.4 Machine components
4
Specifications
4.1 Machine data
4.2 Noise information
4.3 Axle loads, gross weight and minimum ballast required
5 Before initial operation
5.1 Assembling the machine
5.2 Adjusting the PTO shaft
6 Attachment to the tractor
Initial operation
Coupling the machine
Connecting the PTO shaft to the tractor
Connect hydraulics
Connecting the lighting
7 Transport position and working position
7.1 Switching the machine to transport position
7.2 Switching the machine to working position
8
Using the machine
Settings
9.1 Adjusting cutting height
9.2 Adjusting the ground pressure
9.3 Adjusting the tine rotor conditioner (KC)
9.3, 1 Adjusting the conditioner intensity
9, Adjusting the swath guiding assembly
10 Optional functions
IO. 1 Greater cutting height using Skids
10,2 Swath guiding disc
10,3 KC spreader
11 Machine storage
12 Rectifying faults
12,1 If the machine runs over an obstacle
12.2 Adjusting the impact guard
123 Replacing the driveGUARD
12.3, 1 Preparatory work
12.32 Mower disc without feed drum
Mower disc with feed drum
12.3,4 Checks after replacing a driveGUARD element
12.4 Overload protection system for the conditioner
12.5 Blockages at the conditioner
13 Servicing
Maintenance intervals
Accessing the maintenance points
Cleaning
Tightening torques for nuts and bolts
Adhesive notices on the machine
PTO shaft
Hydraul iC system
Gearbox
13.8, 1 Angle drive
13.82 Entry gearbox and cutter bar
13.9 Cutter blades
Checking the cutter blades
Checking the cutter-blade bolt
Checking the blade retaining bolt
Checking the holding spring
Replacing the cutter blades and/or cutter-blade bolt
Replacing the cutter blades
Replacing the blade retaining bolt and/or the holding spring
13.10 Screen element of the TurboLift system
13.11 Check the protective covers
13.12 Lubric
