Description
Fendt 3280 ISL Slicer Operator’s Manual (FEL1377020401)
Fendt 3280 ISL Slicer Index:
Introduction
1
I , I Warranty and liability
1.2 Conventions
Illustrations
I .2,2 Pictograms used
1.23 Text symbols
12.4 Abbreviations
I ,3 Other applicable documentation
I Storage Of documentation
1 Applicability of the Operator’s Manual
I Sign plate and serial number
I , 7 EU Declaration Of Conformity
Safety
Intended use
Reasonably foreseeable misuse
23 User qualifications
Warning notices
2, 4.1 Warning notices in the Operator’s Manual
24,2 Warning notices on the machine
2.5 Safety instructions
Operating and maintenance personnel
Protective work wear
Personal protective equipment
Preparing the machine for use
Coupling/uncoupling the machine toffrom the tractor
Machine operation
Driving on public roads and lanes
Maintenance work
Working with hydraulics
Work in the vicinity of high-voltage power lines
Unauthorized modifications or alterations
What to do in an emergency
Fire prevention
3 Machine description
3, I Product features
3.2 Machine positions
3.2.1 Transport position
3, 2.2 Working position
32.3 Parking position
3.3 Notices on the machine
3,4 Machine components
4
Technical data
4, 1 Machine data
Noise information
Axle loads, gross weight and minimum ballast required
5
Initial start-up
5, 1 Assembling the machine
Adjusting the transmission Shaft
6
Using the machine
6, 1 Attachment to the tractor
Start-up
Couple the machine
Fitting the transmission shaft
Connect the hydraulics
Laying the pull cable
Road travel
Switching the machine to working position
using the machine
6.4, I Turning at the end Of the field
6.5 Switching the machine to transport position
6.6 Machine storage
Settings
6.7, I Adjusting cutting height
6.72 Adjusting the contact pressure
6.7 Adjusting the impact guard
7
Special equipment
7 , I Swath guiding device. right
7 Left swath disc
7.3 Lamp holder
7.4 Other special equipment
8 Rectifying faults
8.1 After hitting an obstacle
9 Maintenance
Maintenance intervals
Accessing the maintenance points
Cleaning
Tightening torques for nuts and bolts
Decals
Transmission Shaft maintenance
Servicing the hydraulics
Gearbox maintenance
9 Gearbox
9.82 Cutter bar
9.9 V-belt drive maintenance
9.9, I V-belt drive from transmission shaft to gearbox
9.9.2 V-belt drive from gearbox to cutter bar
9, IO Cutter blade maintenance
Checking cutter blades
Checking retaining bolts for cutter blades
Checking the holding spring
Replacing the cutter blades
Replacing the retaining bolt and/or the holding spring
9.11 Check the protective covers
9.12 Lubrication instructions
9.12.1 Lubrication points
10 Decommissioning
10.1 Storage
10.2 Disposal
