Description
Fendt 7850 Former Operator’s Manual (FEL1688960401)
Fendt 7850 Former Index:
Introduction
Safety
Intended use
Reasonably foreseeable misuse
Warranty and liability
user qualifications
Warnings and symbols
Warning notices on the machine
Safety instructions
2,7. I General safety instructions
2,7.2 Special safety instructions
3
Machine description
3.1 Product features
3.2 Notices on the machine
3.3 Special accessories
3.4 Machine components
4
Specifications
4.1 Machine data
4.2 Tyres
4.3 Noise information
4.4 Axle loads, gross weight and minimum ballast required
5 Before initial operation
5 I Assembling the machine
5.2 Adjusting the PTO shaft
6 Attachment to the tractor
Initial operation
Coupling the machine
Connecting the PTO shaft to the tractor
Connecting the hydraulics
Pull cables
Connecting the lighting
Transport position and working position
7. I Switching the machine to transport position
7.2 Switching the machine to working position
Using the machine
Settings
Setting the operating mode
Adjusting the working height of the rotors
Adjusting the height Of the swath former
Setting the swath deposit
Setting the sequential control
Adjusting the lowering speed Of the right rotor
Adjusting the swivelling speed of the swath former
Adjusting the longitudinal inclination of the rotor
Adjusting the lateral inclination of the rotor
10 Machine storage
11 Optional functions
1 1.1 Two-swath deposit with mechanical swath former
11.2 Two-swath deposit with the hydraulic two-swath deposit package
12 Rectifying faults
13 Servicing
Maintenance intervals
Cleaning
Tightening torques for nuts and bolts
Adhesive notice
PTO shaft
Hydraulic system
Gearbox
Tyres
13.8.1 Tyre changes
13.8.2 Tyre pressure
13.9 Lubrication instruction
14 Index
