Description
Hitachi R100-301HD Parts Catalog
Hitachi R100-301HD Index:
68024 01-01 FRAME 804523 85 68024 05-02 LOCK-UP CLUTCH & TORQUE CONVE 804595 283
68024 01-04 SHEET METAL 806062 99 68024 05-02 SCAVENGE PUMP 803639 231
68024 01-04 MUD FLAPS AND MTG. 805869 97 68024 05-02 TRANS. POWER TAKE-OFF 805601 293
68024 01-08 ROCK EJECTOR AND MOUNTING 804525 103 68024 05-02 TORQUE CONV. HSG. ASSY. 803638 229
68024 02-01 COOLING LINES & FITTINGS 804527 107 68024 05-02 INPUT BEARING RETAINER 803640 233
68024 02-02 RADIATOR 804794 123 68024 05-02 MAIN HOUSING 803644 241
68024 02-02 RADIATOR MOUNTING 804285 119 68024 05-02 OIL PAN 803655 263
68024 03-01 FUEL LINES & FITTINGS 806477 133 68024 05-02 CONTROL VALVE ASSY. 805817 297
68024 03-02 TANK & MOUNTING 804528 135 68024 05-02 RETARDER VALVE ASSY. 804358 275
68024 03-05 ACCELERATOR CONTROLS 805770 149 68024 05-02 MAIN REGULATOR VALVE & OIL FI 803656 265
68024 03-05 THROTTLE POTENTIOMETER 802840 141 68024 05-02 LOCK-UP CLUTCH VALVE 805816 295
68024 03-05 ACCELERATOR 805293 147 68024 05-02 FIRST RANGE CLUTCH 803651 255
68024 04-01 ENGINE & MOUNTING 804704 163 68024 05-02 SECOND RANGE CLUTCH 803649 251
68024 04-01 ORDERING INSTRUCTIONS 802086 161 68024 05-02 3RD & 4TH CLUTCH GRP. 803647 247
68024 04-01 ENGINE BASIC ADDITIONS 806324 171 68024 05-02 5TH & 6TH RANGE CLUTCH 803645 243
68024 04-02 FAN, MOUNTING & DRIVE 805717 175 68024 05-02 REVERSE RANGE CLUTCH 803653 259
68024 04-04 STARTER 803371 177 68024 05-02 SPLITTER LOW RANGE CLUTCH 803641 235
68024 04-04 STARTER LUBRICATORLINES & FIT 806460 189 68024 05-02 SPLITTER HI RANGE CLUTCH 803642 237
68024 04-04 LUBRICATOR 803372 179 68024 05-02 SPLITTER HI RANGE & SPLITTER 803643 239
68024 04-06 FLYWHEEL COVER & MTG. 804270 197 68024 05-02 1ST RANGE PLANET. 803650 253
68024 04-08 DRIVE COUPLING & MTG. 803499 199 68024 05-02 2ND RANGE PLANET. 803648 249
68024 04-12 EXHAUST & MOUNTING 805712 205 68024 05-02 3RD & 4TH RANGE PLANET. 803646 245
68024 04-13 AIR CLEANER PIPING & MTG. 806325 213 68024 05-02 REVERSE RANGE PLANET. 803652 257
68024 04-13 AIR CLEANER 804317 207 68024 05-02 REAR CVR. & SPEEDOMETER 803654 261
68024 05-01 TRANSMISSION MTG. 806456 221 68024 05-02 BREATHER 806077 301
68024 05-02 TRANSMISSION 804554 277 68024 05-03 TRANSMISSION SHAFT CONTROL 805778 311
68024 05-02 FRONT COVER & CONV. DRIVE 803635 223 68024 05-03 ELECT. SHIFT CONTROL ASSY. 802839 305
68024 07-01 DRIVELINE & MTG. (FRONT) 804302 319 68024 13-01 AIR START LINES & FTGS. 804545 409
68024 07-02 DRIVELINE & MTG. (REAR) 804314 321 68024 13-01 MOISTURE EJECTOR LINES & FITT 804547 413
68024 08-02 DIFFERENTIAL-REAR 804548 327 68024 13-02 START TANK & MTG. 804380 413
68024 08-06 DIFFERENTIAL MTG.-REAR 802730 329 68024 13-03 COMPRESSOR 804819 441
68024 08-07 YOKE/FLANGE & MOUNTING 804218 331 68024 13-05 STARTER 800542 451
68024 09-01 AXLE 804274 335 68024 13-05 CHECK 805814 467
68024 09-03 SUSPENSION 808216 339 68024 13-05 CONTROL 800129 447
68024 09-04 WHEEL,RIM & MTG. 804299 341 68024 13-05 CONTROL 802884 463
68024 09-05 BRAKE PARTS 806165 349 68024 13-05 SOLENOID VALVE 800547 453
68024 09-05 BRAKE PARTS 806166 351 68024 13-05 MOISTURE EJECTOR VALVE 801130 461
68024 09-05 BRAKE MTG. 804378 343 68024 13-06 PARKING BRAKE CHAMBER 800140 469
68024 10-01 AXLE 806258 359 68024 13-06 TORQMATIC BRAKE CONTROL 802090 471
68024 10-01 BREATHER 805819 357 68024 13-09 HORN 803565 475
68024 10-02 PLANETARY 805724 367 68024 13-10 WIPER 801909 477
68024 10-03 SUSPENSION 808040 371 68024 14-01 CABLES & HARNESSES 806341 501
68024 10-04 WHEEL, RIM & MTG. 804243 373 68024 14-01 BATTERY CABLES & HARNES. 804600 485
68024 10-05 BRAKE PARTS 806174 383 68024 14-02 HEADLIGHT 800288 507
68024 10-05 BRAKE MOUNTING 804376 377 68024 14-02 BACK-UP LIGHT 800813 509
68024 12-01 LINKAGE 801329 389 68024 14-02 TAILLIGHT 804004 513
68024 12-02 PARKING BRAKE 800778 391 68024 14-03 GENERATOR/ALTERNATOR 803910 525
68024 12-02 PARKING BRAKE 805273 395 68024 14-03 MOUNTING PARTS 803884 523
68024 12-02 PARTING BRAKE MTG. 804377 393 68024 14-04 BATTERY & MOUNTING 802917 527
68024 13-01 AIR LINES & FITTINGS 806335 421 68024 15-01 CAB OR OPERATOR’S COMPART. 805792 561
68024 13-01 WIPER LINES & FTGS. 802197 399 68024 15-01 DOOR 805790 557
68024 13-01 HORN LINES & FTGS. 804233 401 68024 15-01 DOOR 805791 559
68024 13-01 PARK BRAKE LINES & FTGS. 804546 411 68024 15-01 VENT-WINDOW 800336 537
68024 15-01 VENT-WINDOW 800346 539 68024 17-08 BREATHER 804277 675
68024 15-01 DOMELIGHT 804894 547 68024 17-09 FILTER 804995 691
68024 15-01 WINDSHIELD & MTG. 805765 555 68024 17-12 ACCUMULATOR 804604 693
68024 15-01 SUN VISOR 803503 543 68024 18-01 LINES & FITTINGS 804606 697
68024 15-02 MTG. & ATTACHING PARTS 806512 569 68024 18-02 TANK & MOUNTING 806039 707
68024 15-03 DRIVER’S SEAT 804047 575 68024 18-02 BREATHER 805121 705
68024 15-04 PASSENGER’S SEAT & MTG. 801967 579 68024 18-03 PUMP 804586 709
68024 15-05 SEAT BELT & MOUNTING 800224 581 68024 18-03 MOUNTING 804615 711
68024 15-06 HEATER & MOUNTING 803716 585 68024 18-04 CYLINDER & MTG. 806337 717
68024 15-06 HEATER MOUNTING 805518 589 68024 18-05 CONTROL VALVE 804609 719
68024 15-07 ASH RECEIVER & MTG. 801965 591 68024 18-05 FLOAT DOWN VALVE 804718 721
68024 15-08 SIDE VIEW MIRROR 806261 597 68024 18-05 MOTION CONTROL VALVE 804845 723
68024 15-12 AIR CONDITIONER 804953 605 68024 18-06 HYDRAULIC CONTROL LINKAGE 804616 725
68024 15-12 AIR CONDITIONER LINES & FITTI 804796 601 68024 19-01 BODY & MOUNTING 805558 733
68024 15-12 COMPRESSOR 802549 599 68024 19-06 BODY DOWN INDICATOR 803178 737
68024 15-13 WINDSHIELD WASHER 800908 607 68024 21-01 POWER TAKE-OFF & MTG. 804227 743
68024 15-13 WINDSHIELD WASHER MTG. 806457 613 68024 21-02 LUBE LINES & FITTINGS 803537 745
68024 16-01 SWITCHES & INSTRUMENTS 806223 623 68024 24-01 BRAKE LINES & FTGS. 806043 765
68024 17-01 LINES & FITTINGS 806135 639 68024 24-04 BRAKE MANIFOLD VALVE 805827 789
68024 17-04 STEER VALVE 804574 649 68024 24-04 BRAKE VALVE 805828 791
68024 17-04 SHUT-OFF VALVE 805824 651 68024 24-04 SOLENOID VALVE 805826 787
68024 17-04 R.C.B. VALVE 804550 643 68024 40-01 DECALS & INSTRUCTION PLATES 806234 797
68024 17-05 STEERING COLUMN MTG. 806336 661
68024 17-06 STEERING CYLINDER 805127 665
68024 17-07 PUMP 804598 671
68024 17-07 MOUNTING 804259 669
68024 17-08 TANK & MOUNTING 806432 689
