Hyster H800, H900, H1050HD, H800, H900, H970, H1050HDS (A917) Forklift Parts Manual
These big Hyster H800–H1050HD series forklifts live in steel yards, ports, and heavy industrial plants, where they spend their days handling oversized loads and containers. This parts manual is what I keep beside me when I’m tearing into one of these trucks and need to be sure I’m calling a component by the right name and ordering the correct variant. If I’m chasing a bent frame cover or replacing damaged body panels after a collision, this book lets me match what’s on the truck to the proper part number and related hardware, so I don’t end up with the wrong subassembly.
Applications & Use Cases
- Confirm exact part numbers for frame covers, brackets, and related hardware before placing an order.
- Cross-check component versions between H800, H900, H970, and H1050HDS units built on the A917 series.
- Trace how parts group together so you don’t miss seals, fasteners, or small fittings during reassembly.
- Identify unfamiliar components during teardown when the old tags or decals are missing or unreadable.
- Verify superseded or updated parts by comparing current listings to what’s actually on the machine.
FAQ
Q: Can I use this manual on a tablet in the yard?
A: Yes, it works well digitally; you can zoom diagrams and search part descriptions while standing at the truck.
Q: Is it worth printing certain pages?
A: Many techs print the views they use most, mark them with notes, and keep them with the work order for quick reference.
Safety Note
Always lock out, support, and secure the forklift before inspecting or removing any components referenced in this manual.
📘 Show Index
Hyster H800, H900, H1050HD, H800, H900, H970, H1050HDS (A917) Forklift Parts Manual Index:
- Frame
- COVERS H1050HD (→ S/N A917E01578H)
- COVERS H1050HD (S/N A917E01579H →)
- COVERS H800HD, H900HD, H970HDS, H1050HDS (→ S/N A917E01578H)
- COVERS H800HD, H900HD, H970HDS, H1050HDS (S/N A917E01579H →)
- DUST SHIELD
- FLOORPLATES, STEPS, AND RAILS H1050HD
- FLOORPLATES, STEPS, AND RAILS H800HD, H900HD, H970HDS, H1050HDS
- COUNTERWEIGHT
- OVERHEAD GUARD WIRE MESH
- CAB DOOR RIGHT HAND (→ S/N A917E01548F)
- CAB DOOR RIGHT HAND (S/N A917E01549F →)
- CAB DOOR LEFT HAND (→ S/N A917E01548F)
- CAB DOOR LEFT HAND (S/N A917E01549F →)
- CAB MAIN DOOR WINDOW – RIGHT AND LEFT HAND
- CAB AND ATTACHING PARTS
- CAB DOOR ATTACHING PARTS
- CAB WINDOWS INSTALLATION
- CAB DASH AND AIR DUCT ASSEMBLY
- WINDOW WIPER SYSTEM WASHER BOTTLE KIT
- WINDOW WIPER SYSTEM REAR AND ROOF WIPER KITS – AND FRONT WIPER OPTIONS
- CAB PANELS
- CAB SUNSHADE TOP
- CAB SUNSHADE REAR
- CAB SOUND REDUCTION
- CAB FLOORMATS
- CAB RECIRCULATING FAN
- TILT PLATFORM ASSEMBLY H1050HD
- TILT PLATFORM ASSEMBLY H800HD, H900HD, H970HDS, H1050HDS
- TILT CYLINDER CAB
- DELUXE SUSPENSION SEAT
- SUSPENSION KIT ASSEMBLY
- SEAT ASSEMBLY WITH FABRIC COVER (→ 3/2010)
- SEAT ASSEMBLY WITH FABRIC COVER (3/2010 →)
- SEAT ASSEMBLY WITH VINYL COVER
- SEAT BACKREST EXTENSION OPTIONAL
- SEAT AND SUSPENSION MOUNTING
- SEAT SUSPENSION ASSEMBLY MECHANICAL
- SEAT SUSPENSION ASSEMBLY AIR
- ARMREST ASSEMBLY HYDRAULIC LEVERS
- ARMREST ASSEMBLY JOYSTICK
- PIVOT ARM ASSEMBLY
- HEATER AND AIR CONDITIONER HOSES
- HEATER AND AIR CONDITIONER HOSES
- HEATER AND AIR CONDITIONER HOSES
- AIR CONDITIONER ASSEMBLY AURORA (→ S/N A917E01504E)
- HEATER ASSEMBLY WITH THREE-FAN CONDENSER SYSTEM – AURORA
- HEATER AND AIR CONDITIONER ASSEMBLY WITH THREE-FAN CONDENSER SYSTEM – AURORA
- HEATER AND AIR CONDITIONER MOUNTING WITH THREE-FAN CONDENSER SYSTEM – AURORA
- HEATER AND AIR DUCT ASSEMBLY WITH TWO-FAN CONDENSER SYSTEM – MCC
- HEATER SYSTEM WITH TWO-FAN CONDENSER SYSTEM – MCC
- HEATER ASSEMBLY WITH TWO-FAN CONDENSER SYSTEM – MCC
- AIR DUCT ASSEMBLY HEATER – WITH TWO-FAN CONDENSER SYSTEM, MCC
- CONDENSER TWO-FAN SYSTEM – MCC
- CONDENSER SYSTEM WITH TWO-FAN CONDENSER – MCC
- AIR CONDITIONER SYSTEM ASSEMBLY WITH TWO-FAN CONDENSER SYSTEM – MCC
- AIR CONDITIONER SYSTEM WITH TWO-FAN CONDENSER SYSTEM – MCC
- AIR CONDITIONER ASSEMBLY WITH TWO-FAN CONDENSER SYSTEM – MCC
- AIR DUCT ASSEMBLY AIR CONDITIONING – MCC
- CONTROL PANEL ASSEMBLY WITH TWO-FAN CONDENSER SYSTEM – MCC
- LABELS EXTERIOR
- LABELS INTERIOR
- AIR HORN
- AIR HORN
- INSULATION MATS AND AIR DUCT CLIMATE CONTROL CAB
- AIR DUCT LOUVER, CLIMATE CONTROL CAB
- SEAT ASSEMBLY CLIMATE CONTROL CAB
- CLIMATE CONTROL SYSTEM MCC
- AIR CONDITIONER SYSTEM CLIMATE CONTROL CAB – MCC
- AIR CONDITIONER CLIMATE CONTROL CAB – MCC
- CAB ASSEMBLY CLIMATE CONTROL CAB
- TRAINING SEAT
- CAB TILT ELECTRIC PUMP
- HAND PUMP CAB TILT
- CAB MOUNTING AND TILT
- RADIO CONSOLE AND ATTACHING PARTS
- ENGINE ASSEMBLY
- ENGINE MOUNTS
- ENGINE ASSEMBLY
- ACCESSORY DRIVE PULLEY
- ACCESSORY DRIVE PULLEY
- LIFTING BRACKET
- VALVE COVER
- THERMOSTAT HOUSING
- THERMOSTAT
- CAMSHAFT
- CAM FOLLOWER LEVERS
- ROCKER LEVERS
- FAN DRIVE AND SPACER
- IDLER GEAR
- CYLINDER HEAD
- CYLINDER BLOCK
- CYLINDER LINER
- PISTON AND CONNECTING ROD
- PISTON COOLING NOZZLE
- CYLINDER BLOCK PLUMBING
- CRANKSHAFT
- CRANKSHAFT AND MAIN BEARINGS
- CRANKSHAFT AND MAIN BEARINGS OPTIONAL
- AIR CLEANER PLUMBING
- AIR TRANSFER CONNECTION
- BREATHER PLUMBING
- COOLANT HEATER STARTING AID
- TURBOCHARGER
- TURBOCHARGER
- TURBOCHARGER PLUMBING
- COMPRESSOR MOUNTING
- AIR COMPRESSOR INTAKE CONNECTOR
- FRONT DRIVE TRAIN
- FLYWHEEL
- FLYWHEEL HOUSING
- OIL FILTER AND COOLER HEAD
- OIL FILLER
- OIL LEVEL GAUGE
- OIL FILTER
- OIL COOLER WATER PLUMBING
- WATER PUMP
- WATER PUMP
- GEAR HOUSING
- FRONT GEAR COVER
- OIL PAN
- OIL PAN
- OIL PUMP AND ATTACHING PARTS
- VIBRATION DAMPER
- CORROSION RESISTOR
- RADIATOR PLUMBING
- INTAKE MANIFOLD
- EXHAUST MANIFOLDS
- EXHAUST OUTLET CONNECTION
- NOISE PANEL
- FRONT ENGINE SUPPORT
- HAND HOLE COVER
- EXHAUST SYSTEM
- COOLING SYSTEM
- RADIATOR ASSEMBLY
- FUEL SYSTEM
- FUEL SYSTEM H800HD, H900HD, H970HDS, H1050HDS (→ S/N A917E01551F)
- FUEL SYSTEM H800HD, H900HD, H970HDS, H1050HDS (S/N A917E01552F →)
- FUEL SYSTEM H1050HD (→ S/N A917E01551F)
- FUEL SYSTEM H1050HD (S/N A917E01552F →)
- FUEL PUMP DRIVE
- FUEL PUMP INTAKE FITTING
- FUEL PUMP ASSEMBLY
- FUEL PUMP COUPLING
- FUEL PUMP PLUMBING
- FUEL INJECTOR
- FUEL FILTER PLUMBING
- FUEL FILTER AND WATER SEPARATOR
- THROTTLE PEDAL LINKAGE
- AIR FILTER SYSTEM H1050HD
- AIR FILTER ASSEMBLY H1050HD (→ S/N A917E01504E)
- AIR FILTER ASSEMBLY H1050HD (S/N A917E01505E →)
- AIR FILTER SYSTEM H800HD, H900HD, H970HDS, H1050HDS
- AIR FILTER ASSEMBLY H800HD, H900HD, H970HDS, H1050HDS
- ELECTRICAL SYSTEM
- ELECTRICAL SYSTEM
- DC-DC CONVERTER AND ATTACHING PARTS
- MAP LIGHT
- LIGHT SWITCHES
- TRANSMISSION CONTROLLER AND SHIFT LEVER
- INDICATOR DISPLAY AND CONTROLS
- HEATER CONTROL PANEL
- CONTROL PANEL ASSEMBLY CLIMATE CONTROL
- AIR CONDITIONER CONTROL PANEL
- ARMREST SWITCHES HYDRAULIC LEVERS
- ARMREST SWITCHES JOYSTICK
- ENGINE CONTROL SYSTEM
- ELECTRICAL ACCESSORIES
- WIRING ACCESSORIES ELECTRONIC CONTROL MODULE
- ALTERNATOR
- ALTERNATOR MOUNTING
- LIGHT BAR AND MOUNT TWISTLOCK MODULE
- ALTERNATOR DRIVE PULLEY
- STARTER MOTOR
- STARTER MOTOR
- FUSE BOX
- RELAYS AND FUSES
- RELAYS AND FUSES
- RELAYS AND FUSES
- RELAYS AND FUSES
- WIRE HARNESS CAB, SIDE CONSOLE, PAGE 1 OF 3 (→ S/N A917E01501D)
- WIRE HARNESS CAB, SIDE CONSOLE, PAGE 2 OF 3 (→ S/N A917E01501D)
- WIRE HARNESS CAB, SIDE CONSOLE, PAGE 3 OF 3 (→ S/N A917E01501D)
- WIRE HARNESS CAB SIDE CONSOLE – PAGE 1 OF 3 (S/N A917E01502D ↔ 2/2008)
- WIRE HARNESS CAB SIDE CONSOLE – PAGE 2 OF 3 (S/N A917E01502D ↔ 2/2008)
- WIRE HARNESS CAB SIDE CONSOLE – PAGE 3 OF 3 (S/N A917E01502D ↔ 2/2008)
- WIRE HARNESS CAB SIDE CONSOLE – PAGE 1 OF 3 (2/2008 ↔ 3/2010)
- WIRE HARNESS CAB SIDE CONSOLE – PAGE 2 OF 3 (2/2008 ↔ 3/2010)
- WIRE HARNESS CAB SIDE CONSOLE – PAGE 3 OF 3 (2/2008 ↔ 3/2010)
- WIRE HARNESS CAB SIDE CONSOLE – PAGE 1 OF 3 (3/2010 →)
- WIRE HARNESS CAB SIDE CONSOLE – PAGE 2 OF 3 (3/2010 →)
- WIRE HARNESS CAB SIDE CONSOLE – PAGE 3 OF 3 (3/2010 →)
- WIRE HARNESS CAB, CALIBRATION SWITCH
- WIRE HARNESS CHASSIS, PAGE 1 OF 2 – H1050HD (→ S/N A917E01501D)
- WIRE HARNESS CHASSIS, PAGE 2 OF 2 – H1050HD (→ S/N A917E01501D)
- WIRE HARNESS CHASSIS, PAGE 1 OF 2 – H1050HD (S/N A917E01502D ↔ S/N A917E01548F)
- WIRE HARNESS CHASSIS, PAGE 2 OF 2 – H1050HD (S/N A917E01502D ↔ S/N A917E01548F)
- WIRE HARNESS CHASSIS, PAGE 1 OF 2 – H1050HD (S/N A917E01549F →)
- WIRE HARNESS CHASSIS, PAGE 2 OF 2 – H1050HD (S/N A917E01549F →)
- WIRE HARNESS CHASSIS, PAGE 1 OF 2 – H800HD, H900HD, H970HDS, H1050HDS (→ S/N A917E01548F)
- WIRE HARNESS CHASSIS, PAGE 2 OF 2 – H800HD, H900HD, H970HDS, H1050HDS (→ S/N A917E01548F)
- WIRE HARNESS CHASSIS, PAGE 1 OF 2 – H800HD, H900HD, H970HDS, H1050HDS (S/N A917E01549F →)
- WIRE HARNESS CHASSIS, PAGE 2 OF 2 – H800HD, H900HD, H970HDS, H1050HDS (S/N A917E01549F →)
- WIRE HARNESS POWERTRAIN
- WIRE HARNESS MAST
- WIRE HARNESS CLOSED CAB (→ S/N A917E01501D)
- WIRE HARNESS CLOSED CAB (S/N A917E01502D →)
- WIRE HARNESS REAR WIPER EXTENSION
- WIRE HARNESS CAB LIGHT
- WIRE HARNESS STEERING COLUMN
- WIRE HARNESS UNDERFLOOR
- WIRE HARNESS ARMREST – CLOSED CAB
- WIRE HARNESS HYDRAULIC RELAYS
- WIRE HARNESS STAIR LIGHT
- WIRE HARNESS LIGHT SWITCH
- WIRE HARNESS ENGINE COMPARTMENT
- WIRE HARNESS CARRIAGE – STANDARD
- WIRE HARNESS CARRIAGE – SIDE-SHIFT
- WIRE HARNESS REAR
- WIRE HARNESS POWERED CAB TILT
- START AID
- SECOND 12V SOCKET OPTION CLIMATE CONTROL CAB
- ELECTRIC HORN
- WIRE HARNESS WINDOW WASH PUMPS
- WIRE HARNESS FRONT LIGHTS
- WIRE HARNESS FRONT LIGHTS – ALTERNATE PART
- WIRE HARNESS HYDRAULIC LEVERS SWITCHES
- WIRE HARNESS TWIST MODULE
- TRANSMISSION
- TRANSMISSION LINES AND ATTACHING PARTS – H1050HD (→ S/N A917E01564G)
- TRANSMISSION LINES AND ATTACHING PARTS – H1050HD (S/N A917E01565G →)
- TRANSMISSION LINES AND ATTACHING PARTS – H800HD, H900HD, H970HDS, H1050HDS (→ S/N A917E01564G)
- TRANSMISSION LINES AND ATTACHING PARTS – H800HD, H900HD, H970HDS, H1050HDS (S/N A917E01565G →)
- TRANSMISSION ASSEMBLY
- TRANSMISSION PUMP DRIVE
- TRANSMISSION INPUT DRIVE GEARS
- TRANSMISSION TURBINE SHAFT, STATOR SUPPORT, AND OIL BAFFLE
- TRANSMISSION CASE AND REAR COVER
- TRANSMISSION SPEED SENSORS
- TRANSMISSION FORWARD, REVERSE AND SECOND, – AND THIRD OR FOURTH CLUTCH SHAFTS
- TRANSMISSION FORWARD CLUTCH SHAFT
- TRANSMISSION REVERSE AND SECOND CLUTCH SHAFT
- TRANSMISSION FIRST SPEED GEARS
- TRANSMISSION FIRST SPEED SHAFT AND IDLER GEAR
- TRANSMISSION FIRST SPEED CLUTCH SHAFT
- TRANSMISSION THIRD SPEED GEARS
- TRANSMISSION THIRD SPEED CLUTCH SHAFT
- TRANSMISSION FOURTH SPEED CLUTCH SHAFT
- TRANSMISSION OUTPUT SHAFT
- TRANSMISSION REGULATOR VALVE AND HYDRAULIC PUMP ARRANGEMENT
- TRANSMISSION TORQUE CONVERTER AND DRIVE PLATE
- TRANSMISSION TORQUE CONVERTER HOUSING
- TRANSMISSION CONTROL VALVE MOUNTING
- TRANSMISSION CONTROL VALVE ASSEMBLY
- TRANSMISSION REMOTE FILTER AND ADAPTOR
- TRANSMISSION UNIVERSAL SHAFT
- Drive Axle
- AXLE HOUSING
- DIFFERENTIAL AND CARRIER
- DIFFERENTIAL AND CARRIER ALTERNATE PART
- HUB AND SHAFT
- HUB AND SHAFT
- PARK BRAKE ASSEMBLY
- STEERING SYSTEM
- STEER AXLE AND ATTACHING PARTS
- STEER AXLE ASSEMBLY
- STEER CYLINDER
- STEER CYLINDER
- STEERING COLUMN AND ATTACHING PARTS
- STEER COLUMN ASSEMBLY
- STEERING COLUMN
- STEERING CONTROL UNIT
- STEERING CONTROL VALVE
- BRAKE SYSTEM
- BRAKE SYSTEM
- BRAKE ASSEMBLY SERVICE BRAKES (S/N A917E01502D → (TE-27)) (S/N A917E01505E → (TE-32))
- BRAKE AND INCHING PEDAL LINKAGE
- BRAKE VALVE AND ATTACHING PARTS
- BRAKE VALVE AND ATTACHING PARTS ALTERNATE CONFIGURATION
- HYDRAULIC SYSTEM
- HYDRAULIC SUPPLY AND RETURN PAGE 1 OF 5
- HYDRAULIC SUPPLY AND RETURN PAGE 2 OF 5
- HYDRAULIC SUPPLY AND RETURN PAGE 3 OF 5
- HYDRAULIC SUPPLY AND RETURN PAGE 4 OF 5 (→ 11/2009)
- HYDRAULIC SUPPLY AND RETURN PAGE 4 OF 5 (11/2009 →)
- HYDRAULIC SUPPLY AND RETURN PAGE 5 OF 5
- HYDRAULIC CONTROLS MOUNTING
- HYDRAULIC TANK AND ATTACHING PARTS
- HYDRAULIC CONTROL VALVE AUXILIARY SECTION ASSEMBLY
- HYDRAULIC CONTROL VALVE LIFT SECTION ASSEMBLY
- HYDRAULIC CONTROL VALVE LIFT AND TILT SECTION ASSEMBLY
- HYDRAULIC CONTROL VALVE CAP AND SUPPORT KIT
- HYDRAULIC CONTROL VALVE ATTACHING PARTS
- ACCUMULATOR LIFT
- ACCUMULATOR BRAKE
- MAIN MANIFOLD
- MAIN MANIFOLD
- MAIN MANIFOLD AND ATTACHING PARTS
- MAIN MANIFOLD AND ATTACHING PARTS
- MAIN MANIFOLD ASSEMBLY PAGE 1 OF 2 (S/N A917E01586J →)
- MAIN MANIFOLD ASSEMBLY PAGE 2 OF 2 (S/N A917E01586J →)
- MANIFOLD LIFT AND TILT
- MANIFOLD LIFT AND TILT – ATTACHING PARTS
- MANIFOLD CAB
- MANIFOLD CAB – ATTACHING PARTS
- MANIFOLD BRAKE
- HYDRAULIC PUMP MAIN
- SECONDARY HYDRAULIC PUMP STEERING
- FLOW AMPLIFIER AND ATTACHING PARTS
- JOYSTICK INSTALLATION FORKLIFT TRUCK
- JOYSTICK INSTALLATION CONTAINER HANDLER
- JOYSTICK ASSEMBLY
- HYDRAULIC HOSE ASSEMBLY
- PILOT VALVE ASSEMBLY JOYSTICK
- HAND LEVER INSTALLATION FORKLIFT TRUCK AND CONTAINER HANDLER
- TILT CYLINDER
- TILT CYLINDER AND ATTACHING PARTS
- SOLENOID VALVE ASSEMBLY
- Attachments
- MAST INSTALLATION
- MAST 4267 MM, 7010 MM, 8534 MM LIFT HEIGHTS
- MAST 9144 MM, 9754 MM, 12650 MM LIFT HEIGHTS
- FORKS
- FORK POSITIONER SIDE-SHIFT CARRIAGE
- FORK POSITIONER STANDARD CARRIAGE
- FORK POSITIONING CYLINDER
- CARRIAGE ASSEMBLY STANDARD
- CARRIAGE ASSEMBLY SIDE-SHIFT
- CARRIAGE HYDRAULICS STANDARD
- CARRIAGE HYDRAULICS SIDE-SHIFT
- HEADER HOSES 4267 MM, 7010 MM, 8534 MM LIFT HEIGHTS (→ S/N A917E01542F)
- HEADER HOSES 4267 MM, 7010 MM, 8534 MM LIFT HEIGHTS (S/N A917E01543F →)
- HEADER HOSES 9144 MM, 9754 MM, 12650 MM LIFT HEIGHTS (→ S/N A917E01542F)
- HEADER HOSES 9144 MM, 9754 MM, 12650 MM LIFT HEIGHTS (S/N A917E01543F →)
- LIFT CYLINDER MAST – 4267 MM, 8534 MM, 9144 MM LIFT HEIGHTS
- LIFT CYLINDER MAST – 7010 MM AND 9754 MM LIFT HEIGHTS
- LIFT CYLINDER MAST – 12650 MM LIFT HEIGHT
- SIDE-SHIFT CYLINDER ASSEMBLY
- FORK MOUNTED CONTAINER HANDLER
- FORK MOUNTED CONTAINER HANDLER INSTALLATION
- HYDRAULIC ATTACHMENT STOPS
- BUMPERS
- OPTIONS
- OPTIONAL MOUNTING EQUIPMENT (HANDLE)
- OPTIONAL MOUNTING EQUIPMENT (HANDLE) ALTERNATE ASSEMBLY
- SOUND REDUCTION 5385WB (→ S/N A917E01578H)
- SOUND REDUCTION 5385WB (S/N A917E01579H →)
- SOUND REDUCTION 5900WB (→ S/N A917E01578H)
- SOUND REDUCTION 5900WB (S/N A917E01579H →)
- WORK LIGHTS HALOGEN AND HID
- ENGINE COMPARTMENT AND STAIR LIGHTS
- FRONT LIGHTS
- STROBE LIGHT WITHOUT AIR CONDITIONING
- STROBE LIGHT WITH AIR CONDITIONING
- TAIL LIGHTS AND BACK-UP ALARM
- TIRES AND WHEELS DRIVE – 18.00 X 25
- TIRES AND WHEELS STEER – 16.00 X 25 AND 18.00 X 25
- DRIVE TIRES AND WHEELS 18.00 X 33
- HEATED TOP WINDOW CLIMATE CONTROL CAB
- EMPTY SEAT ENGINE SHUTDOWN
- ENGINE BLOCK HEATER 240V
- 3-POINT SEAT BELT
- DIAGNOSTICS INTERFACE CABLE
- FIELD CONVERSION KITS
- WATER COOLED TURBOCHARGER
- MAST HOSE SHEAVE KIT
- BRAKE TEMPERATURE SWITCH
- LOUVER – HEAVY DUTY AIRCO
- EMPTY SEAT ENGINE SHUTDOWN OVERRIDE
- DRIVE AXLE CONVERSION KIT 18 X 33 – SHORT WHEEL BASE
- DRIVE AXLE CONVERSION KIT 18 X 25 – SHORT WHEEL BASE
- DRIVE AXLE CONVERSION KIT 18 X 33 – LONG WHEEL BASE
- DRIVE AXLE CONVERSION KIT 18 X 25 – LONG WHEEL BASE
- TELEMETRY KITS
- PARK BRAKE KIT
- NUMERICAL INDEX
Hyster
