John Deere 7200 Front-Fold MaxEmerge2 Drawn Conservation Planter, 24-Row Flex-Fold Operator’s Manual (OMA54952)
John Deere 7200 Front-Fold MaxEmerge2 Drawn Conservation Planter, 24-Row Flex-Fold INDEX:
Operating the Planter
General
Raising and Lowering the Planter
Leveling the Planter
Half-Width Plantng Drive Disconnect .
Raising and Lowering Markers
Marker Length
Marxer Float Range
Marker Breakaway Bolt
Changing Planting Depth
Closing Wheel Attachment
When Planting Small Seeds at Shallow
Depths
Adjusting Closing Wheel Down Force
Centering (Align) Closing Wheels
Gauge Wheels
Filling Seed Hoppers
Emptyng Seed Hoppers
Vacuum Meter
Inspection and Cleanout Of Seed
Hoppers/Metering units
HOW to Planting Rate Charts
How to use Planting Rate Charts
Changing Input Sprocket Cornbinations
Changing Planting Rate Sprocket
Combinations
Operating the Vacuum Meter
Meter Operating Characteristics
Use of Talc Lubricant . . . . . . .
Vacuum Level for Corn
Level for Oil
Vacuum Level for Confectionary
Sunflower
for Sweet Corn
Vacuum Level for Peanuts
Vacuum Level for Sugar Beet Seed
Vacuum Seed Chart – Flat Edible Bean
Disk
Vacuum Meter Seed Charts
Decal Seed Charts
Vacuum Meter Seed Charts
Corn and Sunflower, 30 Cells
Oil Sunflower, 30 Cells
Confectionary Sunflower. 40 Cells
Sweet Corn, 40 Cells .
Cotton. 64 Cells .
Cotton Hilldrop, 48 Cells
Vacuum Meter Seed Charts—Continued
Sorghum, 45 Cells
High-Rate Sorghum, 90 Cells
Soybeans. 108 Narrow ROWS
Soybeans. 108 Cells. 22 In. Rows
Soybeans, 108 Ceus, Regular Rows
Sugar Beets, 45 Cells, 22 In. ROWS
Small Edible Beans. 108 Cells. Regular
Medium Edible Beans, 56 cells,
Regular Rows
Large Beans, 50 Cells, Regular
Runner and Spanish Peanuts
Virginia Peanuts
Small Edible Beans, 108 Cells, 22 In,
ROWS
Medium Edible Beans. 56 Cells. 22 In.
Large Edible Beans, SO cells, 22 In.
Rows .
Edible Beans, Flat Type Disk. 50 Holes ,
Operating the Plateless Meter
Finger Pickup Metering unit Operating
Characteristics
Feed Cup Operating Characteristics
Plateless Meter Seed Charts
Finger—pickup
Soybean Feed Cup (Soybeans)
(15 to 20 in, rows)
(30 to 40 in. rows)
Soybeans, Beans Per FtJLb. Per Acre
(IS to 20 in. rows)
(30 to 40 in. rows)
Soybean Feed Cup (Edible Beans)
(15 to 20 in. rows)
(30 to 40 in. rows)
Soybean Feed cup and A4800S Seed
Gude (Small Soybeans)
(15 to 20 in,
(30 to 40 in. rows)
Planting Small Soybeans
Small Soybeans. Beans Per Ft./Lb. Per
(IS to 20 in. rows)
(30 to 40 in. rows)
Soybean Feed Cup and A48005 Seed Guide
(Acid-Delinted Cotton)
(15 to 20 in. rows) .
(30 to 40 in. rows)
Planting Acid-Debnted Cotton
W/SOybean Feed Cup
Low—Rate Sorghutn Feed Cup (Sorghum)
(15 to 20 in. rows)
(30 to 40 in rows)
Regular-Rato Sorghum Feed Cup
(Sorghum)
(15 to 20 in_ rows)
(30 to 40 in_ rows)
Edible Bean Feed Cup (Edible Beans or
Large Soybeans)
(15 to 20 in. rows)
(30 to 40 in, rows)
Checking Seed Population
Seed Population .
Drive Wheel Slippage
General Attachments
Wheel Chain Trash Deflector
Drive Wheel Rock Guard .
Unit Down-Force Springs
Heavy-Duty Down Force Springs
Unit Mounted Coulter .
Rotary Scraper
Coulter;Row Cleaner Height Adjustment
Row unit Gauge Wheel Cover
Row Leveler Chain
Granular Chemical Attachment
Granular Chemical Attachment
U.S. Measurement
Insecticide Application Rates (Clay
Granules )
Insecticide Application Rates (Sand
Granules)
Herbicide Application Rates (Clay
Granules)
Calibrating Insecticide/Herbicide Meter
Seed Furrow Insecticide Placement
Bracket
Rear Mount Insecticide Spreader
Herbicide Diffuser
Windshield
Spring-Tooth Incorporator
Liquid Chemical Attachment
Liqu•d Herbicide
Pre—Emerge Spray Attachment
Troubleshooting
Planter Unfolded
Vacuum Meter .
Plateless Meter
Checking Solenoids
Checking Valves
Setting Switch Cams for Master Cylinder
Switches
Adjusting “J” Switch
Adjusting Switch
Adjustmg “L” Switch .
Replacing Switch
Bleeding the Hydraulic Lit System
Filllng Marker Hydraulic Cylinders
Lubrication
Grease
Multiluber Grease
Lubrication Symbols
Roller Chain and Pesticide Gear
Lubrication
Alternative Lubricants
Special Lubricants for Vacuum Seed
Meters
Special Lubricants for Finger Pickup
Service
Practice Safe Maintenance
Metric Bolt and Scap Screw Torque
Values
Service Tires Safely
Install Service Locks
Drill Shaft Cotter Shear Pins
Ratchet Drive
Aligning Jackshaft Couplers
Replacing Marker Shear Bolt
Drive Wheels
Coulter Maintenance .
Cleaning Insecticide and/or Herbicide
Hoppers
Vacuum Gauge Filter
Clean Vacuum Pump Motor Guard
Clean Manifold System .
Clean Vacuum Meter Drive
Vacuum Meter Inspection and Service
Vacuum Motor Inspection
Installing New Vacuum Seal
Finger Pickup Mechanism
Adjusting Gauge Wheels
Storage
Ser•nce at Beginning of Season
Service at End of Season
Crime Prevention Tips
Specifications
Metric Bolt and Cap Screw Torque
Values
Record Planter Serial Number
Index
