Description

Komatsu S6D95L-1L SN 169575-UP Parts Catalog

Product includes high-quality images, diagrams, and instructions to help you understand and repair spare part numbers and arrangements. This document can be printed without any restrictions and contains searchable text and bookmarks for easy navigation.

TABLE OF CONTENT

CYLINDER HEAD ASS’Y,VALVE LESS …………… 1 22170—
1 j .HEAD, CYLINDER …………………….. 1 22170—
2 6204-19-1310 .GUIDE,VALVE ………………………. 12 22170—
3 6207-11-1431 .SEAT,INTAKE VALVE (STD) ………………… 6 168130—
􀂅6207-11-1430 .SEAT,INTAKE VALVE (STD) ………………… 6 22170-168129
6207-19-1431 .SEAT, 0.25MM,INTAKE VALVE (OS) ……………. 6 168130—
􀂅6207-19-1430 .SEAT, 0.25MM,INTAKE VALVE (OS) ……………. 6 22170-168129
6207-18-1430 .SEAT, 0.50MM,INTAKE VALVE (OS) ……………. 6 168130—
􀂅6207-18-1430 .SEAT, 0.50MM,INTAKE VALVE (OS) ……………. 6 22170-168129
4 6207-11-1440 .SEAT,EXHAUST VALVE (STD) ………………. 6 22170—
6207-19-1440 .SEAT, 0.25MM,EXHAUST VALVE (OS) ………….. 6 22170—
6207-18-1440 .SEAT, 0.50MM,EXHAUST VALVE (OS) ………….. 6 22170—
5 07046-41008 .PLUG …………………………… 6 22170—
6 07046-41810 .PLUG …………………………… 13 22170—
7 07046-42216 .PLUG …………………………… 5 22170—
8 07046-42516 .PLUG …………………………… 15 42401—
07046-42516 .PLUG …………………………… 16 22170-42400
9 02720-40104 .PLUG …………………………… 1 22170—
10 6207-41-4110 VALVE,INTAKE ………………………. 6 22170—
11 6204-41-4210 VALVE,EXHAUST ……………………… 6 22170—
12 6204-41-4510 SEAT,SPRING ……………………….. 12 22170—
13 6204-41-4520 COTTER ………………………….. 24 22170—
14 6204-41-4550 CAP,VALVE ………………………… 12 22170—
15 6204-41-4410 SPRING,OUTER ………………………. 12 22170—
16 6204-41-4420 SPRING,INNER ………………………. 12 22170—
17 6204-41-4540 SEAL,VALVE (K1) …………………….. 6 22170—
18 6206-11-1930 HANGER,FRONT ……………………… 1 22170—
19 6206-11-1920 HANGER,REAR ………………………. 1 22170—
20 01435-01020 BOLT ……………………………. 4 22170—
21 6206-11-1830 GASKET,HEAD (K1) ……………………. 1 168130—
⌧6207-11-1822 GASKET,HEAD (K1) ……………………. 1 22170-168129
􀂋6207-11-1820 GASKET,HEAD (K1) ……………………. 1 38221-41622
􀂅6207-11-1810 GASKET,HEAD (K1) ……………………. 1 22170-38220
22 6204-13-1610 BOLT,HEAD ………………………… 25 41623—
􀂄6142-11-1611 BOLT,HEAD ………………………… 25 22170-41622
