Kubota KX101-3 Compact Excavator Parts Manual (BKIDA0217)

The Kubota KX101-3 is a rubber-track compact excavator, same family of orange iron as my BX and L-series, just built for digging instead of mowing. The Kubota KX101-3 parts manual is what I reach for when I’m trying to see how a cylinder, track motor, or boom joint is built before I tear into it. Folks use this kind of book to ID the exact part, plan a repair, and order everything from pins and bushings to seal kits in one shot so the machine isn’t sitting half apart.

What this manual helps you do

• Identify every component in the KX101-3 assemblies (engine, hydraulics, undercarriage, cab, electrical) using exploded diagrams and callouts.
• Locate the correct OEM Kubota part number for things like bucket pins, boom bushings, travel motor seals, and hardware before you call the dealer.
• Look up quantity-per-machine for bolts, shims, O-rings, and gaskets so you order enough to do the job once.
• Cross-reference older Kubota part numbers to their updated superseded numbers shown in the catalog.
• Verify that an aftermarket or used part you found actually matches the original KX101-3 part number listed in this BKIDA0217 parts manual.

Who this is for

This fits a farm owner-operator, independent mechanic, or small contractor who does their own wrenching and wants dealer-level part number info without guessing. If you’re after torque specs, hydraulic pressures, step-by-step teardown, or adjustment procedures, you need the Workshop/Service Manual, not this parts catalog.

FAQ

Q: Does this cover the engine, hydraulics, and undercarriage on the KX101-3?

A: Yes, a Kubota KX101-3 parts manual like BKIDA0217 normally breaks down engine assemblies, hydraulic pumps and cylinders, swing and travel drives, and undercarriage components.

Q: Are the part numbers in here current, or will it show superseded numbers?

A: These parts manuals usually list the original Kubota part numbers and note superseded numbers where Kubota has updated a component.

Bottom line: If you need diagrams and OEM part numbers for a Kubota KX101-3, this parts manual is the right book; if you need how-to repair steps, keep looking for the WSM.
