Kubota MD1000M Mounted Seed Drill Parts Manual

The Kubota MD1000M is a mounted seed drill that hangs on the back of a tractor, like my L3901 does with my tiller. Folks who reach for a Kubota MD1000M parts manual are usually the ones doing their own maintenance, running a small fleet, or trying to keep an older drill in the ground without paying dealer shop rates. They’re mostly trying to name the exact part that failed, see how it fits in the assembly, and order everything they need before they tear it apart in the yard.

What this manual helps you do

• Identify every wear part in the metering system, openers, seed tubes, and drive components using exploded diagrams and callouts.
• Locate the correct OEM Kubota part numbers for bearings, chains, sprockets, springs, scrapers, and hardware on the MD1000M.
• Look up how many of each bolt, nut, washer, seal, or bushing the drill uses in a given assembly so you can order a full set at once.
• Cross-reference older Kubota MD1000M part numbers to their superseded numbers when Kubota has updated a component.
• Verify that the parts you’re about to buy (or that a dealer is quoting) actually match the MD1000M assemblies on your machine.

Who this is for

This fits an owner-operator, independent ag mechanic, or dealer parts person who needs accurate diagrams and OEM numbers to keep a Kubota MD1000M seed drill working. If you’re after torque specs, adjustment procedures, or step-by-step repair instructions, you want the Workshop/Service Manual instead, not this parts catalog.

FAQ

Q: Does this cover the whole drill, including metering, hydraulics, and the 3‑point mounting frame?

A: Yes, a Kubota MD1000M parts manual typically includes exploded views and parts lists for the complete seed drill assemblies, including frame, metering, drive, and related hydraulics.

Q: Are the part numbers in this manual current, or will the dealer have different numbers?

A: The manual shows the OEM numbers used by Kubota and usually notes superseded numbers, but your dealer’s system is the final word on the latest replacements.

Bottom line: If you already know how to wrench and just need diagrams and Kubota MD1000M part numbers, this parts manual is exactly what you want; if you need “how-to” repair steps, keep looking for the service manual instead.
