Link Belt 460LX Tier3 Excavator Index:

1 GENERAL INFORMATION
Safety, general information and standard torque data ……………………………….1001 7-27691NA
General specifications and special torque setting……………………………………..1002 SC4601002-0NA
2 ENGINE
Radiator and oil-cooler………………………………………………………………………….2001 SM4602001-0NA
Engine specifications ………………………………………………………………………………… *
Disassembly and assembly of the engine…………………………………………………….. *
3 FUEL SYSTEM
Fuel tank …………………………………………………………………………………………….3001 SM4603001-0NA
Fuel engine system…………………………………………………………………………………… *
4 ELECTRICAL SYSTEM
Electrical system, electrical and electronic troubleshooting………………………..4001 SC4604001-0NA
Main and engine electronic control boxes………………………………………………..4003 SM4604003-0NA
5 UNDERCARRIAGE
Removal and installation of tracks ………………………………………………………….5001 SM160B5001-0NA
Rollers ……………………………………………………………………………………………….5003 SM4605003-0NA
Sprocket ……………………………………………………………………………………………..5004 SM160B5004-0NA
Idler wheel and tension shock absorber ………………………………………………….5005 SM4605005-0NA
6 DRIVE TRAIN
Drive motor and final drive transmission removal and installation ……………….6001 SM4606001-0NA
Swing reduction gear, removal and installation…………………………………………6003 SM4606003-0NA
Swing reduction gear, disassembly and assembly…………………………………….6004 SM4606004-0NA
Travel reduction gear disassembly and assembly …………………………………….6005 SM4606005-0NA
7 UNDERCARRIAGE HYDRAULICS
8 UPPERSTRUCTURE HYDRAULICS
Depressurising and decontaminating the hydraulic system, use of the
vacuum pump and bleeding the components ……………………………………….8000 SM4608000-0NA
Specifications, troubleshooting, checks and hydraulic pressure settings………8001 SC4608001-0NA
Hydraulic reservoir removal and installation ……………………………………………8002 SM4608002-0NA
Main and hydraulic pilot pumps, removal and installation …………………………8003 SM4608003-0NA
Main hydraulic control valve, removal and installation ………………………………8004 SM4608004-0NA
Attachment cylinders, removal and installation ………………………………………..8005 SM4608005-0NA
Hydraulic swivel, removal and installation ……………………………………………….8006 SM4608006-0NA
Pilot blocs, removal and installation ………………………………………………………..8007 SM4608007-0NA
Swing motor, removal and installation……………………………………………………..8008 SM4608008-0NA
Main hydraulic pump, disassembly and assembly …………………………………….8010 SM4608010-0NA
Main hydraulic control valve, disassembly and assembly …………………………..8011 SM4608011-0NA
Attachment cylinders, disassembly and assembly…………………………………….8012 SM4608012-0NA
Hand control levers, disassembly and assembly ………………………………………8013 SM4608013-0NA
Foot control levers, disassembly and assembly ………………………………………..8014 SM4608014-0NA
Six-solenoid valves, disassembly and assembly……………………………………….8015 SM4608015-0NA
Caution valve, disassembly and assembly……………………………………………….8016 SM4608016-0NA
Safety valves……………………………………………………………………………………….8017 SM4608017-0NA
Hydraulic swivel, disassembly and assembly……………………………………………8018 SM4608018-0NA
Swing motor, disassembly and assembly ………………………………………………..8019 SM4608019-0NA
Hydraulic functions……………………………………………………………………………….8020 SC4608020-0NA
Travel hydraulic motor, disassembly and assembly……………………………………8021 SM4608021-0NA
Fan motor, removal and installation ………………………………………………………..8022 SM4608022-0NA
Fan motor, disassembly and assembly ……………………………………………………8023 SM4608023-0NA
Fan pump, removal, disassembly, assembly and installation ………………………8024 SM4608024-0NA
Hydraulic component functions………………………………………………………………8030 SC4608030-0NA

9 UPPERSTRUCTURE
Upperstructure, turntable and counterweight…………………………………………….. 9002 SM4609002-0NA
Boom, dipper and bucket ……………………………………………………………………….. 9003 SM4609003-0NA
Seat, removal and installation…………………………………………………………………. 9004 SM4609004-0NA
Cab and cab equipment…………………………………………………………………………. 9005 SM4609005-0NA
Air conditioning unit disassembly and assembly………………………………………… 9007 SM4609007-0NA
Large size hydraulic schematics …………………………………………………………….Pocket 87574469A
Large size electrical schematics …………………………………………………………….Pocket 87574475A
* Consult the Engine Service Manua
