Link Belt LXS 65R Mobile Shear Parts Manual

Link Belt LXS 65R Mobile Shear Parts Manual

Link Belt LXS 65R Mobile Shear Parts Manual Index:

GENERAL ARRANGEMENT 3
ASSEMBLY PIVOT GROUP – RIGHT SIDE 5
ASSEMBLY PIVOT GROUP – LEFT SIDE 7
ASSEMBLY LOWER BLADES 9
ASSEMBLY UPPER BLADES 11
ASSEMBLY AUTO GUIDE 13
ASSEMBLY CYLINDER PINS 15
ASSEMBLY ACCESS COVERS 17
ASSEMBLY UPPER HEAD 19
ASSEMBLY ROTATION 21
ASSEMBLY ROTATION CIRCUIT 23
ROTATE CROSS-OVER / C’BAL SUB-ASSEMBLY 25
SUB-ASSEMBLY LINE MOUNT MANIFOLD 27
ASSEMBLY OPEN AND CLOSE CIRCUIT 29
ASSEMBLY CYLINDER SVX01126 – B14.0 R9.0 S32.75 31
ASSEMBLY CYLINDER PACKING KIT – SVX01129 33
ASSEMBLY SWIVEL MANIFOLD – SVX01042 35
ASSEMBLY SWIVEL MANIFOLD SEAL KIT -SVX01039 37
REGEN BLOCK SUB-ASSEMBLY – SVX01044 39
ASSEMBLY SLEWING RING LUBRICATION 41
WEAR PARTS KIT 43
WARRANTY 44
INDEX 45
