New Holland T7.230, T7.245, T7.260, T7.230 AutoCommand™, T7.245 AutoCommand™, T7.260 AutoCommand™, T7.270 AutoCommand™ Stage IV Tractor Service Manual (47936454)

These T7 Stage IV tractors spend their lives on big implements, road work, and heavy draft jobs, often running long days in dust and vibration. This service manual is what I’d keep open when I’m chasing an electrical fault, splitting the tractor, or dialing in the AutoCommand™ transmission. For example, if the tractor throws a transmission warning and won’t hold speed on the road, I’d use this book to trace the circuit, test the sensors in order, and confirm what needs adjustment or replacement instead of guessing.

Applications & Use Cases

• Systematic diagnostics of engine, transmission, and hydraulic issues by following the recommended test and verify steps.
• Disassembly and reassembly guidance when removing cabs, axles, or transmission components so everything goes back aligned and sealed correctly.
• AutoCommand™ troubleshooting, helping isolate whether a drivability problem is electronic control, hydraulic pressure, or mechanical wear.
• Hydraulic and PTO fault isolation, tracing oil flow and control signals to pinpoint sticking valves, weak pumps, or misadjusted linkages.
• Routine adjustment checks (linkages, clutches, brakes, steering) to keep the tractor tracking straight and working smoothly after repairs.

FAQ

Q: Can I use this manual on a tablet in the shop?

A: Yes, it’s well-suited to a tablet or laptop so you can zoom diagrams and search quickly while working on the tractor.

Q: Is it worth printing sections of this manual?

A: Many techs print just the pages they need for a job, then mark notes or oil stains without risking the whole manual.

Safety Note

Always follow the manual’s support, lockout, and depressurizing steps before loosening any component on these tractors.

New Holland T7.230, T7.245, T7.260, T7.230 AutoCommand™, T7.245 AutoCommand™, T7.260 AutoCommand™, T7.270 AutoCommand™ Stage IV Tractor Index:

• Contents
• INTRODUCTION
• Engine – 10
• Clutch – 18
• Transmission – 21
• Four-Wheel Drive (4WD) system – 23
• Front axle system – 25
• Rear axle system – 27
• Power Take-Off (PTO) – 31
• Brakes and controls – 33
• Hydraulic systems – 35
• Pneumatic system – 36
• Hitches, drawbars, and implement couplings – 37
• Frames and ballasting – 39
• Steering – 41
• Wheels – 44
• Cab climate control – 50
• Electrical systems – 55
• Platform, cab, bodywork, and decals – 90
• SPECIAL TOOL INDEX
