Sandvik DT1132i Drill Rig Service and Parts Diagrams (122D80078-1)

Original price was: $ 90,00.Current price is: $ 80,00.

Sandvik DT1132i Drill Rig Service and Parts Diagrams (122D80078-1)

Format: Interactive PDF (Printable Document, Speed Download Link)

File Language: English

Brand: Sandvik

Type of Document: Service and Parts Manual

Type of Machine: DT1132i

Serial No: (122D80078-1)



Sandvik DT1132i Drill Rig Service and Parts Diagrams (122D80078-1)

Sandvik DT1132i Drill Rig Index:

Technical tables; measurement conversions and
tightening torques
Rock drill maintenance card
Hydraulic rock drill RD535 Operation, maintenance and
repair instructions
Power Extractor RD500 -series, Maintenance and repair
Pressure accumulator for hydraulic rock drill,
maintenance instructions
Hydraulic motors OMSU, OM T andMTA Repair instructions
cylinder feed TF535i
SRH Rod changer
SB160i boom
Hydraulic cylinders

Drill carrier CIOOO
Tire change and rim inspection
Cummins engine fault codes
DT1132i Drilling hydraulics
Variable displacement pump
Symbols for hydraulic and pneumatic equipment

Flushing circuit DT1132i
SLU – DTi -series
Operating instructions CT 28 EA
Water booster pump WBP
DT1132i Electric System
Electrical drawings; reading and symbols
Protecting electrical and electronic components
Control System (SICA – DD,DT -rigs)
Basic adjustment of the cable reel and water hose reel
Operation and maintenance manual – Cable reels
Cabin air conditioner – DTi series
Hydraulic high pressure water pump
Hydraulic oil side flow fiter system
Access protector
Lincoln, Quicklub mobile chassis lubrication system
SUB5i utility boom
Tramming camera


Sandvik – Tamrock Toro
