Sumitomo SH200-3, SH220-3 Hydraulic Excavator Service Manual (WLSM2203-00W)
Sumitomo SH200-3, SH220-3 Hydraulic Excavator Index:
o EXPLANATION
L ,-_01 Contents and History of Editions
02 Safety
03 Introduction
04 Symbols Used
05 Precautions
06 Standard Torque Specifications
07 Numerical Value Conversion Table
2 SPECIFICATIONS
3 PERFORMANCE
21 Major Equipment Specifications C 22 Main Body Filters, Fluids and Lubricants
E31 Main Body Weight
32 New Machine Performance Judgment Table
33 Lifting Capacities
5 MAIN BODY DISASSEMBLYAND SERVICING PROCEDURES
I ~ 51 Lower Mechanism
52 Upper Mechanism
53 Attachment
54 Maintenance Standards
6 AJOR COMPONENTS DISASSEMBLYAND SERVICING PROCEDURES
61 Tightening Torque for Major Parts
62 Take-up RoUer
63 Upper RoUer
64 Lower RoUer
65 Grease Cylinder
66 Center Joint
68 Air Conditioner
7 MAJOR HYDRAULIC DISASSEMBLYAND SERVICING PROCEDURES
71 Hydraulic Pump
72 Traction Mechanism
73 Swing Mechanism
74 Control Valve
75 Cylinder
76 Remote Control Valve
77 Solenoid Valve
78 Cushion Valve
79 Holding Valve
