Description
Sumitomo SH300-3, SH300LC-3, SH350HD-3 Hydraulic Excavator Parts Manual (WCLA300A31BH)
Sumitomo SH300-3, SH300LC-3, SH350HD-3 Hydraulic Excavator Index:
ＡＲＥＡ ＮＡＭＥ PARTS PAGE CODE SERIAL NO. CHANGE
DA:ﾛﾜ- LOWERS
ｿｳﾁ;ｿｳｺｳ TRACTION EQUIPMENT DAA801L0012-00 002 300A3 01105- *
300L3 01101- *
350A3 01123- *
ﾌﾚ-ﾑ;ﾛﾜ- SH300/350HD-3 LOWER FRAME DAE901L0026-00 001 300A3 01105- *
350A3 01123- *
ﾌﾚ-ﾑ;ﾛﾜ- SH300LC-3 LOWER FRAME DAE901L0027-00 002 300L3 01101- *
ﾗｲﾝ;ｿｳｺｳﾓ-ﾀ TRACTION MOTOR LINE DAK301L0017-00 001 300A3 01105-
350A3 01123-
ﾗｲﾝ;ｿｳｺｳﾓ-ﾀ SH300LC-3 TRACTION MOTOR LINE DAK301L0018-00 001 300L3 01101-
ﾛ-ﾗ;ｱﾂﾊﾟ UPPER ROLLER DAN401L0010-00 001 300A3 01105- *
300L3 01101- *
350A3 01123- *
ﾛ-ﾗ;ﾃｲｸｱﾂﾌﾟ TAKE-UP ROLLER DAN701L0012-00 001 300A3 01105- *
300L3 01101- *
350A3 01123- *
ﾛ-ﾗ;ﾛﾜ- SH300/350HD-3 LOWER ROLLER DAP201L0016-00 000 300A3 01105-
350A3 01123-
ﾛ-ﾗ;ﾛﾜ- SH300LC-3 LOWER ROLLER DAP201L0017-00 001 300L3 01101-
ｼﾕ-(ｸﾞﾛ-ｻ800ｼ-ﾙｲﾘ) SH300-3 GROUSER SHOE 800 SEAL DA02A5L0001-00 001 OPT 300A3 01105- *
OPT 350A3 01123- *
ｼﾕ-(ｸﾞﾛ-ｻ800ｼ-ﾙｲﾘ) SH300LC-3 GROUSER SHOE 800 SEAL DA02A5L0002-00 001 OPT 300L3 01101- *
ｼﾕ-(ｸﾞﾛ-ｻ600ｼ-ﾙｲﾘ) SH300-3 GROUSER SHOE 600 SEAL DA0219L0005-00 003 300A3 01105- *
350A3 01123- *
ｼﾕ-(ｸﾞﾛ-ｻ600ｼ-ﾙｲﾘ) SH300LC-3 GROUSER SHOE 600 SEAL DA0219L0006-00 002 300L3 01101- *
ｶﾊﾞ-;ﾛﾜ-ｱﾝﾀﾞ SH300/400-3 LOWER UNDER COVER DA0301L0010-00 000 OPT 300A3 01105-
OPT 300L3 01101-
350A3 01123-
ｶﾞ-ﾄﾞ;ﾄﾗﾂｸ(ｼﾝｸﾞﾙ) SH300-3 TRACK GUARD(SINGLE) DA3802L0002-00 000 300A3 01105-
ｶﾞ-ﾄﾞ;ﾄﾗﾂｸ(ﾀﾞﾌﾞﾙ) SH300LC-3 TRACK GUARD(DOUBLE) DA3803L0004-00 000 300L3 01101-
ｶﾞ-ﾄﾞ;ﾄﾗﾂｸ(ﾌﾙ) SH350HD-3 TRACK GUARD(FULL) DA3804L0004-00 000 OPT 350A3 01123-
ｼﾞﾖｲﾝﾄ;ｾﾝﾀ CENTER JOINT DA8901L0014-00 001 300A3 01105-01325
300L3 01101-01143
350A3 01123-01139
ｼﾞﾖｲﾝﾄ;ｾﾝﾀ (SH300-3) CENTER JOINT DA8901L0025-00 000 300A3 01326- *
300L3 01144- *
350A3 01140- *
ｽﾌﾟﾘﾝｸﾞ;ﾘｺｲﾙ RECOIL SPRING DA9401L0014-00 001 300A3 01105- *
300L3 01101- *
350A3 01123- *
DB:ｾﾝｶｲﾌﾚ-ﾑ･ﾌﾟﾗｯﾄﾎ-ﾑ･ｶｳﾝﾀｳｴｲﾄSWING FRAMES & PLATFORMS
ﾌﾚ-ﾑ;ｾﾝｶｲ (SH300-3) REVOLVING FRAME DBA201L0024-00 003 300A3 01105-
300L3 01101-
ﾌﾚ-ﾑ;ｾﾝｶｲ (SH350HD-3) REVOLVING FRAME DBA201L0025-00 003 350A3 01123-
ﾎﾞﾙﾄ ﾒｸﾗ (ﾍｯﾄﾞｶﾞ-ﾄﾞﾎﾞﾙﾄｱﾅﾎｺﾞ) BOLT DBC201L0001-00 000 350A3 01123-
ﾎﾞﾙﾄ ﾒｸﾗ(ｽﾃｯﾌﾟﾎﾞﾙﾄｱﾅﾎｺﾞ) BOLT DBC201L0002-00 000 300A3 01105-
300L3 01101-
ｶｳﾝﾀｳｴｲﾄ SH300-3 COUNTER WEIGHT DB0199L0015-00 000 300A3 01105-0111
エリアﾊﾟｰﾂﾍﾟｰｼﾞｺｰﾄﾞ適用号機 変更
ＡＲＥＡ ＮＡＭＥ PARTS PAGE CODE SERIAL NO. CHANGE
300L3 01101-01103
ｶｳﾝﾀｳｴｲﾄ SH300-3 ﾋﾞﾋﾞｯﾄﾞｲｴﾛ- COUNTER WEIGHT DB0199L0038-00 002 300A3 01115- *
300L3 01104- *
ｶｳﾝﾀｳｴｲﾄ SH350HD-3 ﾋﾞﾋﾞｯﾄﾞｲｴﾛ- COUNTER WEIGHT DB0199L0039-00 000 350A3 01123-
ｶﾊﾞ-;ｱﾂﾊﾟｱﾝﾀﾞ (SH300-3) UPPER UNDER COVER DB0201L0024-00 001 300A3 01105- *
300L3 01101- *
350A3 01123- *
BRG;ﾀ-ﾝﾃ-ﾌﾞﾙ SH300-3/SH350HD-3 TURN TABLE BEARING DB1001L0013-00 000 300A3 01105-
300L3 01101-
350A3 01123-
DC:ﾘﾊﾞ-ｽｼｬﾌﾄ･ｸﾗｯﾁREV･SHAFTS & CLUTCH
ｿｳﾁ;ｾﾝｶｲ SH300-3 REVOLVING EQUIPMENT DC4501L0023-00 001 300A3 01105-01366 *
300L3 01101-01147 *
350A3 01123-01141 *
ｿｳﾁ;ｾﾝｶｲ SH300-3 REVOLVING EQUIPMENT DC4501L0041-00 000 300A3 01367- *
300L3 01148- *
350A3 01142- *
DH:ｴﾝｼﾞﾝ･ﾊﾟﾜ-ﾕﾆｯﾄENGINES & POWER UNITS
ﾗｲﾝ;ﾌﾕ-ｴﾙ SH300-3 EXP FUEL LINE DHE001L0019-00 001 300A3 01105- *
300L3 01101- *
350A3 01123- *
ｴﾝｼﾞﾝ(ｲｽｽﾞ) SH300-3 ENGINE(ISUZU) DH0101L0013-00 004 300A3 01105- *
300L3 01101- *
350A3 01123- *
ﾏﾌﾗ(ﾋﾖｳｼﾞﾕﾝ) SH300-3 MUFFLER(STANDARD) DH0201L0016-00 000 300A3 01105-
300L3 01101-
350A3 01123-
ﾗｼﾞｴﾀ(ﾋﾖｳｼﾞﾕﾝ) SH300-3 RADIATOR(STANDARD) DH0301L0021-00 002 300A3 01105- *
300L3 01101- *
350A3 01123- *
ｸﾘ-ﾅ;ｴｱ(Wｴﾚﾒﾝﾄ) SH300-3 AIR CLEANER(W ELEMENT) DH0602L0011-00 000 300A3 01105-
300L3 01101-
350A3 01123-
ｺﾝﾄﾛ-ﾙ;ｴﾝｼﾞﾝﾃｲｼ SH300-3 ENGINE STOP CONTROL DH4201L0004-00 001 300A3 01105-
300L3 01101-
350A3 01123-
ﾀﾝｸ;ﾌﾕ-ｴﾙ SH300-3 FUEL TANK DH8101L0015-00 001 300A3 01105-
300L3 01101-
350A3 01123-
DJ:ｺﾝﾄﾛ-ﾙ･ﾕｱﾂﾗｲﾝCONTROLS & HYD. LINES
ﾗｲﾝ;ﾄﾞﾚﾝ SH300-3 DRAIN LINE DJAH01L0028-00 000 300A3 01105-01130
300L3 01101-01107
ﾗｲﾝ;ﾄﾞﾚﾝ SH300-3 NA DRAIN LINE DJAH01L0059-00 000 300A3 01131-
エリアﾊﾟｰﾂﾍﾟｰｼﾞｺｰﾄﾞ適用号機 変更
ＡＲＥＡ ＮＡＭＥ PARTS PAGE CODE SERIAL NO. CHANGE
300L3 01108-
350A3 01123-
ﾗｲﾝ;ﾊﾞｹﾂﾄ&ｱ-ﾑ SH300-3 BUCKET & ARM LINE DJAQ01L0013-00 000 300A3 01105-
300L3 01101-
350A3 01123-
ﾗｲﾝ;ﾊﾟｲﾛﾂﾄｱﾂﾘﾖｸ&ﾘﾀ-ﾝ SH300-3 PILOT PRESS.& RETURN LINE DJBC01L0038-00 002 300A3 01105-01130
300L3 01101-01107
ﾗｲﾝ;ﾊﾟｲﾛﾂﾄｱﾂﾘﾖｸ&ﾘﾀ-ﾝ SH300-3 PILOT PRESS.& RETURN LINE DJBC01L0084-00 002 300A3 01131- *
300L3 01108- *
350A3 01123- *
ﾗｲﾝ;ﾌﾞ-ﾑ SH300-3 BOOM LINE DJBV01L0018-00 000 300A3 01105-
300L3 01101-
350A3 01123-
ﾗｲﾝ;ﾘﾀ-ﾝ&ｵｲﾙｸ-ﾗ SH300-3 RETURN & OIL COOLER LINE DJEE01L0024-00 001 300A3 01105-01130
300L3 01101-01107
ﾗｲﾝ;ﾘﾀ-ﾝ&ｵｲﾙｸ-ﾗ SH300-3 RETURN & OIL COOLER LINE DJEE01L0041-00 001 300A3 01131-
300L3 01108-
350A3 01123-
ﾀﾝｸ;ｻﾝﾌﾟ SH300-3 SUMP TANK DJE701L0016-00 001 300A3 01105-01130
300L3 01101-01107
ﾀﾝｸ;ｻﾝﾌﾟ SH300-3 SUMP TANK DJE701L0022-00 002 300A3 01131- *
300L3 01108- *
350A3 01123- *
ﾌｲﾙﾀ;ﾊﾞｲﾊﾟｽ SH300-3 BYPASS FILTER DJGJ01L0015-00 001 300A3 01105-
300L3 01101-
350A3 01123-
ﾊﾞﾙﾌﾞ;ｺﾝﾄﾛ-ﾙ SH300-3 CONTROL VALVE DJG201L0036-00 001 300A3 01105- *
300L3 01101- *
350A3 01123- *
ﾊﾞﾙﾌﾞ;ｻ-ﾋﾞｽ ﾎﾟ-ﾄﾘﾘ-ﾌ SERVICE VALVE DJG301L0002-00 000 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ﾗｲﾝ;ﾊﾟｲﾛﾂﾄｺﾝﾄﾛ-ﾙ SH300-3 PILOT CONTROL LINE DJHC01L0028-00 001 300A3 01105-
300L3 01101-
350A3 01123-
ｶｲﾛ;ﾌﾞﾚ-ｶ SH300-3 SINGLE ACTING CIRCUIT DJKX01L0014-00 002 OPT 300A3 01105- *
OPT 300L3 01101- *
OPT 350A3 01123- *
ｶｲﾛ;ｵｳﾌｸ SH300-3 DOUBLE ACTING CIRCUIT DJKY01L0018-00 001 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ｶｲﾛ;ﾍｲﾖｳ SH300-3 MULTI-PURPOSE+3WAY VALVE DJKZ01L0021-00 001 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ﾌﾟﾗｸﾞ ｸﾞﾙ-ﾌﾟ STD SH300-3 PLUG DJK401L0034-00 000 300A3 01105-01130
300L3 01101-01107
ﾌﾟﾗｸﾞ ｸﾞﾙ-ﾌﾟ ﾌﾞﾚ-ｶ SH300-3 PLUG DJK401L0035-00 000 OPT 300A3 01105-01130
OPT 300L3 01101-01107
ﾌﾟﾗｸﾞ ｸﾞﾙ-ﾌﾟ ﾍｲﾖｳ SH300-3 PLUG DJK401L0036-00 000 OPT 300A3 01105-01130
OPT 300L3 01101-01107
ﾌﾟﾗｸﾞ ｸﾞﾙ-ﾌﾟ ｵｳﾌｸ SH300-3 PLUG DJK401L0065-00 000 OPT 300A3 01105-01130
ﾌﾟﾗｸﾞ ｸﾞﾙ-ﾌﾟ ｵｳﾌｸ2ｿｸ SH300-3 PLUG DJK401L0066-00 000 OPT 300A3 01105-01130
OPT 300L3 01101-01107
ﾌﾟﾗｸﾞ ｸﾞﾙ-ﾌﾟ STD SH300-3 PLUG DJK401L0119-00 000 300A3 01131-
300L3 01108-
ﾌﾟﾗｸﾞ ｸﾞﾙ-ﾌﾟ ﾌﾞﾚ-ｶ SH300-3 PLUG DJK401L0120-00 000 OPT 300A3 01131-
OPT 300L3 01108-
ﾌﾟﾗｸﾞ ｸﾞﾙ-ﾌﾟ ﾍｲﾖｳ SH300-3 PLUG DJK401L0121-00 000 OPT 300A3 01131-
OPT 300L3 01108-
ﾌﾟﾗｸﾞ ｸﾞﾙ-ﾌﾟ ｵｳﾌｸ SH300-3 PLUG DJK401L0183-00 000 OPT 300A3 01131-
OPT 300L3 01108-
ﾌﾟﾗｸﾞ ｸﾞﾙ-ﾌﾟ ｵｳﾌｸ2ｿｸ SH300-3 PLUG DJK401L0184-00 000 OPT 300A3 01131-
OPT 300L3 01108-
ｶｲﾛ;2ｿｸｺﾞｳﾘﾕｳ (ｵｳﾌｸ) SH300-3 2-PUMP FLOW CIRCUIT DJLC01L0004-00 000 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ﾎﾟﾝﾌﾟ;ﾕｱﾂ SH300-3 HYDRAULIC PUMP DJL901L0024-00 000 300A3 01105-01130
300L3 01101-01107
ﾎﾟﾝﾌﾟ;ﾕｱﾂ SH300-3 HYDRAULIC PUMP DJL901L0048-00 001 300A3 01131-
300L3 01108-
350A3 01123-
ﾏﾂﾄ;ﾌﾛｱ (ﾋｮｳｼﾞｭﾝ) FLOOR MAT DJM101L0006-00 001 300A3 01105-
300L3 01101-
350A3 01123-
ﾏﾂﾄ;ﾌﾛｱ (ｻ-ﾋﾞｽVﾖｳ) FLOOR MAT DJM101L0007-00 001 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ﾗｲﾝ;ｱﾂﾘﾖｸ SH300-3 PRESSURE LINE DJP801L0017-00 000 300A3 01105-01130
300L3 01101-01107
ﾗｲﾝ;ｱﾂﾘﾖｸ SH300-3 NA PRESSURE LINE DJP801L0026-00 000 300A3 01131-
300L3 01108-
ﾗｲﾝ;ｻｸｼﾖﾝ SH300-3 SUCTION LINE DJW001L0021-00 001 300A3 01105-01130
300L3 01101-01107
ﾗｲﾝ;ｻｸｼﾖﾝ SH300-3LB-TL SUCTION LINE DJW001L0040-00 000 300A3 01131-
300L3 01108-
350A3 01123-
ﾗｲﾝ;ｾﾝｶｲ SH300-3 SWING LINE DJY601L0014-00 000 300A3 01105-
300L3 01101-
350A3 01123-
ﾗｲﾝ;ｿｳｺｳ SH300-3 TRACTION LINE DJY901L0012-00 000 300A3 01105-
300L3 01101-
350A3 01123-
ｺﾝﾄﾛ-ﾙ;ｻ-ﾋﾞｽﾊﾞﾙﾌﾞ SERVICE VALVE CONTROL DJ5801L0003-00 003 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ｺﾝﾄﾛ-ﾙ;ｼﾞﾖｲｽﾃｲﾂｸ SH120-3 EXP JOYSTICK CONTROL DJ6201L0010-00 002 300A3 01105- *
300L3 01101- *
DN:ｵﾍﾟﾚ-ﾀｷｬﾌﾞ･ﾊｳｽ･ｶﾊﾞ- OPERATOR’S CAB & HOUSE
ﾁｴ-ﾝ;ﾄﾞﾂｸﾞ DOG CHAIN DNB501L0002-00 000 300A3 01105-
ｻﾝﾊﾞｲｻﾞ SUNVISOR DNB801L0001-00 000 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ｶﾞ-ﾄﾞ;ｷﾔﾌﾞﾌﾛﾝﾄ (ｼﾀ) CAB FRONT GUARD DN0601L0002-00 000 OPT 350A3 01123-
ｶﾞ-ﾄﾞ;ｷﾔﾌﾞﾌﾛﾝﾄ (ｳｴ) CAB FRONT GUARD DN0601L0003-00 001 OPT 350A3 01123-
ｶﾞ-ﾄﾞ;ｷﾔﾌﾞﾍﾂﾄﾞ FOPS LEV2 ｺｸ/EX CAB HEAD GUARD DN4001L0003-00 001 OPT 350A3 01123-
ｷﾔﾌﾞ;ｵﾍﾟﾚ-ﾀ (HD-3) OPERATOR’S CAB DN4801L0037-00 002 350A3 01123- *
ｷﾔﾌﾞ;ｵﾍﾟﾚ-ﾀ OPERATOR’S CAB DN4801L0038-00 002 300A3 01105- *
300L3 01101- *
ｽﾀﾝﾄﾞ;ﾘﾔ REAR STAND DN5501L0001-00 002 300A3 01105- *
300L3 01101- *
350A3 01123- *
ｽﾃﾂﾌﾟ;ｷﾔﾌﾞﾖｺ CAB SIDE STEP DN5701L0001-00 000 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ﾊｳｽ SH300/LC-3 EXPORT HOUSE DN7301L0045-00 002 300A3 01105-01130
300L3 01101-01107
ﾊｳｽ SH300/LC/350HD-3 EXPｶﾜｼﾞｭｳHOUSE DN7301L0101-00 003 300A3 01131- *
300L3 01108- *
350A3 01123- *
ﾊｳｽ SH350HD-3 EXP ﾍｯﾄﾞ ｶﾜｼﾞｭｳ HOUSE DN7301L0105-00 002 OPT 350A3 01123- *
ﾍﾞﾙﾄ;ｼ-ﾄ 2ｲﾝﾁﾏｷﾄﾘｼｷ SEAT BELT DN9501L0005-00 002 300A3 01105-
300L3 01101-
350A3 01123-
ﾎﾞﾂｸｽ;ｺﾝｿ-ﾙ &ｼ-ﾄ ｻｽﾂｷ ｸﾛｽ CONSOLE BOX DN9901L0025-00 002 300A3 01105- *
300L3 01101- *
350A3 01123- *
DP:ｻﾞｯﾋﾟﾝ･ﾒｲﾊﾞﾝACCESSORIES & NAME PLATES
ﾄﾞｳｸﾞ (ｶｲｶﾞｲ)SH300-3/SH400-3 TOOLS DPF001L0005-00 000 300A3 01105-
300L3 01101-
350A3 01123-
ﾎﾟﾝﾌﾟ;ﾌﾕ-ｴﾙﾌｲ-ﾄﾞ SH300/400-3EX FUEL FEED PUMP DPL301L0003-00 000 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ﾒｲﾊﾞﾝ;ｿｳｻ ISO OPE NAME PLATE DPM801L0001-00 000 300A3 01105-
300L3 01101-
350A3 01123-
ﾎﾟﾝﾌﾟ;ｷﾕｳｼ (SH300/400-3) LUBRICATION PUMP DPU201L0002-00 000 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ﾄｿｳ(ｷｲﾛ) SH300-3 EXPORT PAINTING(YELLOW) DP0102L0012-00 001 300A3 01105-
ﾄｿｳ(ｷｲﾛ) SH300-3 CHINA PAINTING(YELLOW) DP0102L0013-00 001 OPT 300A3 01105-
ﾄｿｳ(ｷｲﾛ) SH300LC-3 EXPORT PAINTING(YELLOW) DP0102L0014-00 001 300L3 01101-
ﾄｿｳ(ｷｲﾛ) SH300LC-3 CHINA PAINTING(YELLOW) DP0102L0015-00 001 OPT 300L3 01101-
ﾄｿｳ(ｷｲﾛ) SH350HD-3 EXPORT PAINTING(YELLOW) DP0102L0018-00 001 350A3 01123- *
ﾄｿｳ(ｷｲﾛ) SH350HD-3 CHINA PAINTING(YELLOW) DP0102L0019-00 001 OPT 350A3 01123-
ＡＲＥＡ ＮＡＭＥ PARTS PAGE CODE SERIAL NO. CHANGE
ﾒｲﾊﾞﾝ ;ｿｳｻ (ﾍｲﾖｳ ｴｲﾌﾞﾝ) NAME PLATE DP0201L0006-00 001 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ﾒｲﾊﾞﾝ ｿｳｻ (ﾍｲﾖｳ ﾁｭｳｺﾞｸ) NAME PLATE DP0201L0007-00 000 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ﾒｲﾊﾞﾝ(ｴｲﾌﾞﾝ) NAME PLATE(ENGLISH) DP0210L0005-00 001 300A3 01105-
300L3 01101-
350A3 01123-
ﾒｲﾊﾞﾝ(ﾁﾕｳｺﾞｸ) NAME PLATE(CHINA) DP0221L0001-00 000 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ﾐﾗ-;ﾊﾞﾂｸ REAR VIEW MIRROR DP0701L0003-00 001 300A3 01105-01152
300L3 01101-01109
ﾐﾗ-;ﾊﾞﾂｸ REAR VIEW MIRROR DP0701L0006-00 001 OPT 300A3 01105-01152
OPT 300L3 01101-01109
ﾐﾗ-;ﾊﾞﾂｸ (ｶｲｶﾞｲ) REAR VIEW MIRROR DP0701L0012-00 000 300A3 01153-
300L3 01110-
350A3 01123-
ﾐﾗ-;ﾊﾞﾂｸ (ｵｵｶﾞﾀ ｶｲｶﾞｲ) REAR VIEW MIRROR DP0701L0013-00 000 OPT 300A3 01153-
OPT 300L3 01110-
OPT 350A3 01123-
ｷﾂﾄ;ｽﾍﾟｱﾊﾟ-ﾂ SH300/LC-3 EXPORT SPARE PARTS KIT DP5501L0012-00 001 300A3 01105-
300L3 01110-
ｷﾂﾄ;ｽﾍﾟｱﾊﾟ-ﾂ SH300/350HD-3 EXP SPARE PARTS KIT DP5501L0026-00 000 350A3 01123-
DR:ﾃﾞﾝｷﾋﾝELECTRIC PARTS
ｺﾝﾊﾞ-ﾀ;DC-DC DC-DC CONVERTER DRA801L0001-00 001 OPT 300A3 01105-
OPT 300L3 01110-
OPT 350A3 01123-
ﾓﾆﾀ;ｼｽﾃﾑ RV(ｲｯﾊﾟﾝﾕｼｭﾂ) SYSTEM MONITOR DRCC01L0004-00 001 300A3 01105-
300L3 01101-
350A3 01123-
ﾃﾞﾝｷﾋﾝ&ﾊｲｾﾝ (ｷｬﾌﾞ) ELEC.PARTS & WIRE HARNESS DRJ401L0025-00 002 300A3 01105-
300L3 01101-
350A3 01123-
ﾃﾞﾝｷﾋﾝ&ﾊｲｾﾝ (ｷｬﾌﾞ) SH120-3 LBX ELEC.PARTS & WIRE HARNESS DRJ401L0031-00 003 350A3 01123-
ﾃﾞﾝｷﾋﾝ&ﾊｲｾﾝ (ｷｬﾌﾞ) SH120-3 LBX ELEC.PARTS & WIRE HARNESS DRJ401L0031-00 003 300A3 01105-01104
300L3 01101-
ﾃﾞﾝｷﾋﾝ&ﾊｲｾﾝ (ｷｬﾌﾞ) ELEC.PARTS & WIRE HARNESS DRJ401L0053-00 001 OPT 300A3 01105-
OPT 300L3 01110-
OPT 350A3 01123-
ﾃﾞﾝｷﾋﾝ&ﾊｲｾﾝ (ﾌﾚ-ﾑ) SH300-3 ELEC.PARTS & WIRE HARNESS DRJ401L0060-00 001 300A3 01105-01130
300L3 01101-01107
ﾃﾞﾝｷﾋﾝ&ﾊｲｾﾝ (ﾌﾚ-ﾑ) SH300-3 K ELEC.PARTS & WIRE HARNESS DRJ401L0123-00 001 OPT 300A3 01131-
300L3 01108-
ﾊﾞﾂﾃﾘ (195G51) BATTERY DRV001L0008-00 000 OPT 300A3 01105-01262
OPT 300L3 01101-01125
OPT 350A3 01123-01128
ﾊﾞﾂﾃﾘ (180G51) BATTERY DRV001L0012-00 000 OPT 300A3 01263- *
OPT 300L3 01126- *
OPT 350A3 01129- *
ﾎ-ﾝ(ﾃﾞﾝｷ) HORN(ELECTRIC) DRY003L0003-00 000 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ｵﾝｷﾖｳ(AM/FMﾗｼﾞｵ<H>) AM/FM RADIO HIGH BAND DR0103L0001-00 001 300A3 01105-
300L3 01101-
350A3 01123-
ｵﾝｷﾖｳ(AM/FMﾗｼﾞｵ<L>) ｽﾃﾚｵ AM/FM RADIO LOW BAND DR0104L0002-00 000 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ｸｳﾁﾖｳ(ﾋ-ﾀ) ｷｬﾌﾞ CASE HEATER DR0201L0006-00 001 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ｸｳﾁﾖｳ(ﾋ-ﾀ) SH300-3LBX HEATER DR0201L0012-00 000 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123-
ｸｳﾁﾖｳ(ｴｱｺﾝ) ｷｬﾌﾞ SH400/450HD-3 AIR CONDITIONER DR0205L0019-00 002 OPT 300A3 01105- *
OPT 300L3 01101- *
OPT 350A3 01123- *
ｸｳﾁﾖｳ(ｴｱｺﾝ) ﾌﾚ-ﾑ AIR CONDITIONER DR0205L0022-00 001 OPT 300A3 01105- *
OPT 300L3 01101- *
OPT 350A3 01123- *
ｸｳﾁｮｳ (ﾅｼ) AIR CONDITIONER DR0299L0002-00 000 300A3 01105-
300L3 01101-
350A3 01123-
ﾗｲﾄ;ﾜ-ｷﾝｸﾞ WORKING LIGHT DR1801L0004-00 000 300A3 01105-01152
300L3 01101-01107
ﾗｲﾄ;ﾜ-ｷﾝｸﾞ (ｶｲｶﾞｲ) WORKING LIGHT DR1801L0009-00 000 OPT 300A3 01153-
OPT 300L3 01108-
OPT 350A3 01123-
ｳｵﾂｼﾔ;ｳｲﾝﾄﾞ WINDOW WASHER DR5001L0011-00 000 300A3 01105- *
300L3 01101- *
350A3 01123- *
ｶﾊﾞ-;ﾗｼﾞｵｱﾅ RADIO HOLE COVER DR6201L0001-00 000 OPT 300A3 01105-
OPT 300L3 01110-
OPT 350A3 01123-
ｺﾝﾄﾛ-ﾗ (ｲｽｽﾞｴﾝｼﾞﾝﾖｳ) CONTROLLER DR9901L0005-00 004 OPT 300A3 01105- *
OPT 300L3 01101- *
OPT 350A3 01123- *
DV:ｱﾀｯﾁﾒﾝﾄ(ﾊﾞｯｸﾎ-) ATTACHMENTS (BACKHOE)
ﾊﾞｹﾂﾄ (1.4M3) (STDｼﾖｳ) BUCKET DV0130L0002-00 000 300A3 01105-
300L3 01110-
ﾊﾞｹﾂﾄ (1.4M3)(HDｼﾖｳ) BUCKET DV0130L0003-00 000 OPT 300A3 01105-
OPT 300L3 01110-
OPT 350A3 01123-
ﾊﾞｹﾂﾄ (STD 1.6M3) BUCKET DV0130L0006-00 000 OPT 300A3 01105-
ﾞｹﾂﾄ (HD 1.6M3) BUCKET DV0130L0007-00 000 OPT 350A3 01123-
ﾊﾞｹﾂﾄ (STD 1.15M3) BUCKET DV0130L0016-00 000 OPT 300A3 01105-
OPT 300L3 01110-
ﾊﾞｹﾂﾄ (STD 1.8M3) BUCKET DV0130L0017-00 000 OPT 300A3 01105-
OPT 300L3 01110-
ｱ-ﾑ(ﾋﾖｳｼﾞﾕﾝ) (ｾﾐEMS) ARM(STANDARD) DV0201L0032-00 000 300A3 01105-
300L3 01110-
ｱ-ﾑ(ﾋﾖｳｼﾞﾕﾝ) (HD ｾﾐEMS) ARM(STANDARD) DV0201L0033-00 001 350A3 01123-
ｱ-ﾑ(ﾋﾖｳｼﾞﾕﾝ) ｾﾐEMS ｻﾞ+ﾎｷｮｳ ARM(STANDARD) DV0201L0052-00 000 OPT 300A3 01105-
OPT 300L3 01110-
ｱ-ﾑ(ﾋﾖｳｼﾞﾕﾝ) HD ｾﾐEMS ｻﾞ+ﾎｷｮｳ ARM(STANDARD) DV0201L0065-00 000 OPT 350A3 01123-
ｱ-ﾑ(ﾋﾖｳｼﾞﾕﾝ･ﾌﾞﾚ-ｶｻﾞﾂｷ) (ｾﾐEMS) ARM(STANDARD) DV0202L0016-00 001 OPT 300A3 01105-
OPT 300L3 01110-
ｱ-ﾑ(ﾋﾖｳｼﾞﾕﾝ･ﾌﾞﾚ-ｶｻﾞﾂｷ) HDｾﾐEMS ARM(STANDARD) DV0202L0017-00 001 OPT 350A3 01123-
ｱ-ﾑ(ﾛﾝｸﾞ) ｾﾐEMS ARM(LONG) DV0210L0026-00 000 OPT 300A3 01105-
OPT 300L3 01110-
ｱ-ﾑ(ﾛﾝｸﾞ) ｻﾞﾂｷ ｾﾐEMS ARM(LONG) DV0210L0027-00 000 OPT 300A3 01105-
OPT 300L3 01110-
ｱ-ﾑ(ｼﾖ-ﾄ) ｾﾐEMS ARM(SHORT) DV0230L0024-00 001 OPT 300A3 01105-
OPT 300L3 01110-
ｱ-ﾑ(ｼﾖ-ﾄ) ｻﾞﾂｷ ｾﾐEMS ARM(SHORT) DV0230L0025-00 001 OPT 300A3 01105-
OPT 300L3 01110-
ｱ-ﾑ(ｼﾖ-ﾄ) ｾﾐEMS ｻﾞ+ﾎｷｮｳ ARM(SHORT) DV0230L0031-00 000 OPT 300A3 01105-
OPT 300L3 01110-
OPT 350A3 01123-
ｱ-ﾑ(ｼﾖ-ﾄ) HD ｾﾐEMS ARM(SHORT) DV0230L0046-00 001 OPT 350A3 01123-
ｱ-ﾑ(ｼﾖ-ﾄ) ｻﾞﾂｷ HD ｾﾐEMS ARM(SHORT) DV0230L0047-00 001 OPT 350A3 01123-
ﾌﾞ-ﾑ(ﾊﾞｯｸﾎ-) (EMS) BOOM(BACK-HOE) DV0301L0023-00 001 300A3 01105- *
300L3 01110- *
ﾌﾞ-ﾑ(ﾊﾞｯｸﾎ-) (HD)(EMS) BOOM(BACK-HOE) DV0301L0024-00 001 350A3 01123- *
ﾌﾞ-ﾑ(ﾊﾞｯｸﾎ-) EMS ｻﾞ+ﾎｷｮｳ BOOM(BACK-HOE) DV0301L0037-00 001 OPT 300A3 01105- *
OPT 300L3 01110- *
ﾌﾞ-ﾑ(ﾊﾞｯｸﾎ-) HD EMS ｻﾞ+ﾎｷｮｳ BOOM(BACK-HOE) DV0301L0053-00 001 OPT 350A3 01123- *
ﾌﾞ-ﾑ(ﾊﾞｯｸﾎ- ﾌﾞﾚ-ｶｻﾞﾂｷ) HD EMS BOOM(BACK-HOE) DV0302L0014-00 001 OPT 350A3 01123- *
ﾌﾞ-ﾑ(ﾊﾞｯｸﾎ- ﾌﾞﾚ-ｶｻﾞﾂｷ) (EMS) BOOM(BACK-HOE) DV0302L0015-00 001 OPT 300A3 01105- *
OPT 300L3 01110- *
ﾘﾝｹ-ｼﾞ;ﾊﾞｹﾂﾄ(ﾋﾖｳｼﾞﾕﾝ) (ｷｭｳｼ) BUCKET LINKAGE(STANDARD) DV0401L0023-00 000 300A3 01105-
300L3 01110-
350A3 01123-
ﾘﾝｹ-ｼﾞ;ﾊﾞｹﾂﾄ(ｷﾖｳｶｶﾞﾀ) (ｷｭｳｼ) BUCKET LINKAGE(BUILD-UP) DV0402L0012-00 000 OPT 300A3 01105-
OPT 300L3 01110-
OPT 350A3 01123-
ﾗｲﾝ;ﾖﾋﾞ(ｻﾞﾂｷﾖｳ) OPTION LINE(BAR BASE) DV0601L0029-00 001 OPT 300A3 01105-
OPT 300L3 01110-
OPT 350A3 01123-
ﾗｲﾝ;ﾖﾋﾞ(ｻﾞﾂｷﾖｳ) ｼｮ-ﾄｱ-ﾑ OPTION LINE(BAR BASE) DV0601L0030-00 001 OPT 300A3 01105-
OPT 300L3 01110-
OPT 350A3 01123-
ﾗｲﾝ;ﾖﾋﾞ(ｻﾞﾂｷﾖｳ) ﾛﾝｸﾞｱ-ﾑ OPTION LINE(BAR BASE) DV0601L0031-00 001 OPT 300A3 01105-
OPT 300L3 01110-
ﾗｲﾝ;ｱ-ﾑｼﾘﾝﾀﾞ (ｷｭｳｼ) ARM CYLINDER LINE DV4601L0051-00 000 300A3 01105-
300L3 01110-
350A3 01123-
ﾗｲﾝ;ｱ-ﾑｼﾘﾝﾀﾞ (EMS) ARM CYLINDER LINE DV4601L0055-00 000 OPT 300A3 01105-
OPT 300L3 01110-
OPT 350A3 01123-
ﾗｲﾝ;ｸﾞﾘｽ GREASE LINE DV5001L0012-00 000 OPT 300A3 01105-
OPT 300L3 01110-
OPT 350A3 01123-
ﾗｲﾝ;ﾊﾞｹﾂﾄｼﾘﾝﾀﾞ (ｷｭｳｼ) BUCKET CYLINDER LINE DV5601L0057-00 001 300A3 01105- *
300L3 01110- *
350A3 01123- *
ﾗｲﾝ;ﾊﾞｹﾂﾄｼﾘﾝﾀﾞ ｼｮ-ﾄｱ-ﾑ BUCKET CYLINDER LINE DV5601L0058-00 001 OPT 300A3 01105- *
OPT 300L3 01110- *
OPT 350A3 01123- *
ﾗｲﾝ;ﾊﾞｹﾂﾄｼﾘﾝﾀﾞ ﾛﾝｸﾞｱ-ﾑ BUCKET CYLINDER LINE DV5601L0059-00 001 OPT 300A3 01105- *
OPT 300L3 01110- *
ﾗｲﾝ;ﾊﾞｹﾂﾄｼﾘﾝﾀﾞ (ｾﾐEMS) BUCKET CYLINDER LINE DV5601L0060-00 001 OPT 300A3 01105- *
OPT 300L3 01110- *
OPT 350A3 01123- *
ﾗｲﾝ;ﾊﾞｹﾂﾄｼﾘﾝﾀﾞ ｼｮ-ﾄｱ-ﾑ ｾﾐEMS BUCKET CYLINDER LINE DV5601L0072-00 001 OPT 300A3 01105- *
OPT 300L3 01101- *
OPT 350A3 01123- *
ﾗｲﾝ;ﾊﾞｹﾂﾄｼﾘﾝﾀﾞ ﾛﾝｸﾞｱ-ﾑ ｾﾐEMS BUCKET CYLINDER LINE DV5601L0073-00 001 OPT 300A3 01105- *
OPT 300L3 01101- *
ﾗｲﾝ;ﾌﾞ-ﾑｼﾘﾝﾀﾞ (ｷｭｳｼ) BOOM CYLINDER LINE DV6001L0025-00 000 300A3 01105-
300L3 01101-
350A3 01123-
ﾗｲﾝ;ﾌﾞ-ﾑｼﾘﾝﾀﾞ (EMS) BOOM CYLINDER LINE DV6001L0030-00 000 OPT 300A3 01105-
OPT 300L3 01101-
OPT 350A3 01123
