Takeuchi TB020, TB030, TB035 Compact Excavator Operators Manual (OE3-313E0)

Format: PDF (Printable Document)

File Language: English

File Pages: 116

File Size: 6.10 MB (Speed Download Link)

Brand: Takeuchi

Model: TB020, TB030, TB035 Compact Excavator

Book No: OE3-313E0

Type of Document: Operators Manual

Categories: PDF, Takeuchi PDF

$ 40

Takeuchi TB020, TB030, TB035 Compact Excavator Operators Manual (OE3-313E0)

On these TB020, TB030 and TB035 minis, you’re usually trenching around buildings, working on tight residential lots, or cleaning up on crowded commercial sites. This operator’s manual is what I keep handy to remind operators how the controls should feel, how the machine should react under load, and what to check every day before they start digging. If, for example, the boom feels jerky when you’re tracking on uneven ground, this book helps you confirm correct operating technique and basic checks before you call in a wrench.

Applications & Use Cases

Teach new operators proper control use so they don’t slam the swing or overwork the travel motors on rough ground.
Plan daily walk‑arounds to inspect fluids, track condition and attachment pins, reducing surprise downtime.
Verify correct operating habits when lifting near utilities or foundations, keeping loads stable and visibility good.
Adjust working style for soft soil, slopes or tight access so you don’t overstress the undercarriage or boom.
Confirm normal behavior of engine and hydraulics under load before assuming there’s a mechanical fault.

FAQ

Q: Can I keep this manual on my phone or tablet in the cab?

A: Yes, it’s practical to use a digital copy on a device, as long as the screen is readable in sunlight and protected from dust and vibration.

Q: Is it worth printing parts of this manual?

A: Many operators print the daily checklists and control layouts to laminate and keep in the cab for quick reference.

Safety Note

Always follow the manual’s operating guidance, especially on slopes and near people, to prevent rollovers and unintended machine movement.

📘 Show Index

Takeuchi TB020, TB030, TB035 Compact Excavator Index:

Introduction
Safety Instructions
Before Operation
3
During Operation
5
During Inspection and Maintenance
.. 11
Part Names and Functions
Part Names …….w……….
14
Levers and Instruments
14
Seat and seat belt
, 22
Rad10 . .
……„ 23
. 24
Operation
Before Starting Operation
25
Starting the Engine
, 26
Stopping the Engine .
• 27
Operating the Levers and Pedals „
.28
Operation: Travel .
29
Operation: Hoe Attachment
.30
Work Operations
32
Operating the Road Protector .
. 32
Blade Operation
33
Using the Auxiliary Ports
34
Cautions on Handling
a Hydraulic Breaker
, , 35
Transporting the Excavator 38
Peculiarities Hydraulic Equipment
, 39
Inspection and Maintenance
Tilting Up the Cab .
40
Greasing
40
Adjusting the Crawier Bett Tension .
41
Cautions on Handling
Rubber Crawlers .
, 41
Replacing Rubber Crawlers .
, 44
Changing the Hydraulic Oil —
, 45
Replacing the Return Filter .
46
Changing the Gear Oil
. 47
Inspecting and Servicing
the Fuet System
48
Cleaning and Replacing
the Air Cleaner Element
49
Changing the Engine Oil .
Replacing the Engine Oil Filter
Cleaning the Radiator and Replacing
the Coolant
Adjusting and Replacing the Fan Belt
Inspecting the Battery Fluid
Charging the Battery
Handling Booster Cables .
Replacing the Bucket Teeth
Adjusting the Bucket/Arm Gap
Replacing the Bucket
Cautions on Handling the Stay Dampers .
Handling in Cold Weather
Care in Long-term Storage
Inspection and Maintenance Chart
Troubleshooting
Tightening Torques
Lubricants Chart
Options
Ordering Parts
Ordering Parts and Notifying
of Problems
Expendables .
Standard Accessories
Main Specifications
Major Dimensions
Operating Ranges .
Unit Performance
Hydraulic System Diagram
Electrical System Diagram.
Lifting Capacities
Handling of Options
