Takeuchi TB070 Compact Excavator Operators Manual (0L1-107E0) (SN 1703004-)

On a TB070 that spends its days trenching, loading trucks, and digging around services on tight, uneven jobsites, this operators manual is what I keep handy to run the machine without abusing it. It helps you understand what every control does, how the excavator should feel under load, and what to check before and after a shift. If, for example, the machine feels unstable when you swing with a full bucket on a slope, this manual walks you through proper operating posture, travel direction, and attachment use so you can correct the issue instead of guessing.

Applications & Use Cases

• Set up daily walk‑around checks so you can spot leaks, loose hardware, or track issues before they stop the job.
• Learn proper control use for smooth trenching, backfilling, and lifting without shocking the hydraulics.
• Understand machine behavior on slopes to keep the TB070 stable when tracking or swinging on rough ground.
• Adjust operating habits to reduce premature wear on tracks, swing gear, and boom pins.
• Improve visibility and positioning around obstacles, traffic, and underground utilities.

FAQ

Q: Can I keep this manual on a tablet in the cab?

A: Yes, many techs use a PDF on a tablet or phone so they can zoom diagrams and search terms while sitting in the machine.

Q: Is it worth printing parts of it?

A: Printing the daily checks and basic control layouts is handy for laminating and keeping in the cab or workshop.

Safety Note

Always follow the manual’s procedures and limits, especially on slopes and near people or utilities.
